Chapter 10 — Adjustments
Adjusting for Narrow Media
Screw
98
Theprinterisfactory-adjustedforfullsizemediawidth.When
usingnarrowermedia,adjustthepressurearmsoitremains
centeredonthemediaandappliespressureevenly.
Apoorlyadjustedpressurearmmaybedetectedbyaweaker
printoutoneithersideofthemediapath.
Center of media
Pressure arm
A dedicated direct thermal EasyCode PF4i Printer
To adjust the pressure arm for narrow media
1Removetheribbon,ifany.
2Loosentheknobthatholdsthepressurearm.
