TOSHIBA Bar Code Printer
B-SX4 Series, B-SX5 Series
Key Operation Specification
First Edition:
Second Edition: February 21, 2003
Third Edition:
Fourth Edition:
Fifth Edition:
Sixth Edition:
Seventh Edition: February 8, 2005
Eighth Edition:
Ninth Edition:
Tenth Edition:
November 18, 2002
June 6, 2003
August 22, 2003
February 27, 2004
January 14, 2005
May 9, 2005
April 4, 2006
May 23, 2007

Advertisement

Table of Contents
loading

Related Manuals for Toshiba B-SX4 Series

Summary of Contents for Toshiba B-SX4 Series

  • Page 1 TOSHIBA Bar Code Printer B-SX4 Series, B-SX5 Series Key Operation Specification First Edition: November 18, 2002 Second Edition: February 21, 2003 Third Edition: June 6, 2003 Fourth Edition: August 22, 2003 Fifth Edition: February 27, 2004 Sixth Edition: January 14, 2005...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page 1. SCOPE............................2. OUTLINE ............................. 3. OPERATION PANEL ........................4. GENERAL VIEW OF KEY OPERATION ..................5. ONLINE MODE..........................5.1 KEY FUNCTION........................5.2 LED FUNCTION ........................5.3 LCD FUNCTION........................5.4 ONLINE MODE OPERATION EXAMPLE ................5.5 THRESHOLD SETTING......................5.5.1 Outline of Threshold Setting ....................

  • Page 3: Table Of Contents

    Page 6. SYSTEM MODE........................... 37 6.1 OUTLINE OF SYSTEM MODE ....................37 6.2 SELF-TEST ..........................39 6.2.1 Self-test Operation Example .................... 39 6.2.2 Self-test Items ........................43 6.2.3 Self-test Results Printout Samples .................. 46 6.2.4 Self-test Printout Contents ....................48 6.3 VARIOUS PARAMETERS SETTING..................

  • Page 4: Scope

    1. SCOPE This specification describes key operations of the B-SX4T-GS10/20-QQ/QP/CN/QQ-US and B-SX4T- GS10-QQ-CCS (hereinafter collectively referred to as “B-SX4”) and the B-SX5T-TS12/22- QQ/QP/CN/QQ-US, TP-128, and B-SX5T-TS15 (hereinafter collectively referred to as “B-SX5”) high industrial general-purpose bar code printers using their keys and the LCD display. 2.

  • Page 5: General View Of Key Operation

    4. GENERAL VIEW OF KEY OPERATION [Power OFF] Online mode Turn the power on. [Online] [FEED] key [Feeds one label.] [RESTART] key [PAUSE] key [Pause] Hold down the [PAUSE] key for a few seconds. [Transmissive sensor threshold setting mode] [FEED] key [Reflective sensor threshold Hold down the [RESTART] key While holding down the [FEED],...

  • Page 6: Online Mode

    5. ONLINE MODE 5.1 KEY FUNCTION [FEED] key: (1) Feeds one sheet of paper. This key can be used to eject one sheet of paper. This key can also be used to adjust the paper to the proper position when the paper is not properly positioned.

  • Page 7: Online Mode Operation Example

    5.4 ONLINE MODE OPERATION EXAMPLE Power ON * This message is displayed while the L I N E printer is idling or printing normally. B - S X 4 T V 1 . 0 A An error occurs. * The message is displayed when an error P A P E R 1 2 5 occurs during printing, then printing is...

  • Page 8: Threshold Setting

    5.5 THRESHOLD SETTING 5.5.1 Outline of Threshold Setting When a label is printed, the printer detects the gap between the labels using the transmissive sensor, and corrects the print position automatically to obtain a constant print position. However, when a preprinted label is used, some inks may prevent proper positioning correction. In this case, determine the transmissive sensor threshold manually by key operation and store the value in the non-volatile memory (EEPROM).
  • Page 9 (10) The transmissive sensor designation is T R A N S M I S S I V E displayed. B - S X 4 T V 1 . 0 A (11) Continue holding down the [PAUSE] [PAUSE] key. (12) The printer feeds the label until the T R A N S M I S S I V E [PAUSE] key is released.

  • Page 10: Reset

    5.6 RESET Power ON (1) Idling or printing normally L I N E B - S X 4 T V 1 . 0 A (2) Press the [PAUSE] key. [PAUSE] * If the [PAUSE] key is pressed during P A U S E printing, this message is displayed and B - S X 4 T V 1 .

  • Page 11: Parameter Setting

    5.7 PARAMETER SETTING 5.7.1 Parameter Setting Operation Example Power ON (1) Idling or printing normally L I N E B - S X 4 T V 1 . 0 A (2) Press the [PAUSE] key. [PAUSE] (3) “PAUSE” is displayed. P A U S E B - S X 4 T V 1 .
  • Page 12 (19) Parity selection: < 2 > P A R A M E T E R S E T Select the parity using the [FEED] and P A R I T Y E V E N [RESTART] keys. [PAUSE] (20) Press the [PAUSE] key. (21) Transmission control method selection: <...
  • Page 13 (35) Control code selection: < 2 > P A R A M E T E R S E T Select the control code using the C O D E E S C , L F , N U L [FEED] and [RESTART] keys. (36) Press the [PAUSE] key.
  • Page 14 (55) Expansion I/O operation mode setting: < 2 > P A R A M E T E R S E T Select the expansion I/O operation mode using the [FEED] and [RESTART] keys. E X . I / O T Y P E 1 (56) Press the [PAUSE] key.
  • Page 15 In the case of V4.4A In the case of V4.4 (73) The parameter setting menu is displayed. < 2 > P A R A M E T E R S E T (73) XML function setting: < 2 > P A R A M E T E R S E T Select the specification of the XML function, using the [FEED] or [RESTART] key.

  • Page 16: Setting Contents

    5.7.2 Setting Contents For details, refer to section 6.3 “Various Parameters Setting” in chapter 6 “System Mode”. (1) Character code selection (FONT CODE) • PC-850 • PC-852 • PC-857 • PC-8 • PC-851 • PC-855 • PC-1250 • PC-1251 • PC-1252 •...
  • Page 17 RS-232C transmission control method selection (XON+READY) • XON/XOFF protocol (An XON is not output when the power is on and an XOFF is not output when the power is off) • READY/BUSY (DTR) protocol (An XON is not output when the power is on and an XOFF is not output when the power is off) •...
  • Page 18 (13) Ribbon saving system setting (RBN SAVE) • ON (TAG) (The ribbon saving system is used.: When the head lever position is “TAG”.) • ON (LBL) (The ribbon saving system is used.: When the head lever position is “LABEL”.) • OFF (The ribbon saving system is not used.) (14) Control code selection (CODE) •...
  • Page 19 (26) Plug-and-play operation setting (PLUG & PLAY) • ON: Plug-and-play operation is enabled. • OFF: Plug-and-play operation is disabled. (27) Label end/ribbon end process setting (LBL/RBN END) • TYPE1: When a label end or ribbon end state is detected, the printer stops even if it is printing a label.

  • Page 20: Fine Adjustment Value Setting

    5.8 FINE ADJUSTMENT VALUE SETTING 5.8.1 Fine Adjustment Value Setting Operation Example Power ON (1) Idling L I N E B - S X 4 T V 1 . 0 A (2) Press the [PAUSE] key. [PAUSE] (3) “PAUSE” is displayed. P A U S E B - S X 4 T V 1 .
  • Page 21 (19) Print density fine adjustment (Thermal < 3 > A D J U S T S E T transfer print mode): T O N E A D J . < T > Set the fine adjustment value using the [FEED] and [RESTART] keys. [PAUSE] (20) Press the [PAUSE] key.
  • Page 22 (35) The reset menu is displayed. < 1 > R E S E T [PAUSE] (36) Press the [PAUSE] key. (37) The display is returned to the state L I N E obtained when the power is turned on. B - S X 4 T V 1 .
  • Page 23 5.8.2 Setting Contents For details, refer to section 6.4 “Various Fine Adjustment Values Setting” in chapter 6 “System Mode”. (1) Feed fine adjustment (FEED ADJ.) -50.0 mm to +50.0 mm (in 0.5 mm units) (2) Cut (strip) position fine adjustment (CUT ADJ.) -50.0 mm to +50.0 mm (in 0.5 mm units) (3) Back feed fine adjustment (BACK ADJ.) -9.5 mm to +9.5 mm (in 0.5 mm units)

  • Page 24: Dumping Of Receive Buffer

    5.9 DUMPING OF RECEIVE BUFFER 5.9.1 Operation Example of Receive Buffer Dumping Power ON (1) Idling L I N E B - S X 4 T V 1 . 0 A [PAUSE] (2) Press the [PAUSE] key. (3) “PAUSE” is displayed. P A U S E B - S X 4 T V 1 .
  • Page 25 (19) Print method selection: < 4 > D U M P M O D E Select the print method using the P R I N T D E M A N D [FEED] and [RESTART] keys. [RESTART] (20) Press the [RESTART] key. (21) Print method selection: <...
  • Page 26 Data in the receive buffer is printed out in the format below. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ....00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ....

  • Page 27: Basic Expansion Mode

    Print conditions: • Print width: Approximately 100 mm • Sensor designation: None • Print speed: 6 ips for B-SX4, 5 ips for B-SX5 • The print mode (thermal transfer/direct thermal) depends on the current setting. • Data of 16 bytes is printed on one line. •...

  • Page 28: Automatic Calibration Setting (Supported From V4.4)

    5.11 AUTOMATIC CALIBRATION SETTING (SUPPORTED FROM V4.4) 5.11.1 Operation Example of Automatic Calibration Setting Power ON (1) Idling or printing normally L I N E B - S X 4 T V 4 . 4 [PAUSE] (2) Press the [PAUSE] key. (3) “PAUSE”...
  • Page 29 (17) The current setting is displayed. < 6 > A U T O C A L I B O F F [FEED] or [RESTART] (18) Change the setting using the [FEED] or [RESTART] key. (19) Automatic calibration for the Transmissive <...
  • Page 30 The printer feeds about 160 mm long media to detect a black mark/gap and determine the threshold. When the printer detects more than two black marks/gaps during this 160-mm media feed, the printer measures the media pitch and stops the automatic calibration 1 mm short of the bottom of a black mark or gap.

  • Page 31: Lan Enable/Disable Setting (Supported Only By V4.4)

    5.12 LAN ENABLE/DISABLE SETTING (SUPPORTED ONLY BY V4.4) 5.12.1 Operation Example of LAN Enable/Disable Setting Power ON (1) Idling or printing normally L I N E B - S X 4 T V 4 . 4 [PAUSE] (2) Press the [PAUSE] key. (3) “PAUSE”...
  • Page 32 LAN Enable/Disable Setting (LAN) • OFF Disabled RESTART • ON SNMP ON LAN is enabled, SNMP is enabled. • ON SNMP OFF LAN is enabled, SNMP is disabled. FEED - 29 -...

  • Page 33: Lcd Messages And Led Indications

    5.13 LCD MESSAGES AND LED INDICATIONS The model and the firmware version are displayed on the lower line of the LCD. Restoration Acceptance LCD Messages of LED Indication by the of Status Upper line Printer Status [RESTART] Request Reset (English) Yes/No Command POWER ON LINE ERROR...
  • Page 34 Restoration Acceptance LCD Messages of LED Indication by the of Status Upper line Printer Status [RESTART] Request Reset (English) Yes/No Command POWER ON LINE ERROR Yes/No A command error has occurred in Display of error analyzing the command. command (See NOTE 1.) A momentary power interruption POWER FAILURE has occurred.
  • Page 35 Restoration Acceptance LCD Messages of LED Indication by the of Status Upper line Printer Status [RESTART] Request Reset (English) Yes/No Command POWER ON LINE ERROR Yes/No The printer does not succeed RFID WRITE ERROR in writing data onto the RFID tag after having retried for the specified times.
  • Page 36 NOTE 3: Blinking ****: Remaining number of labels to be printed to 9999 (in units of 1 label/tag) %%%%%%%: Remaining memory capacity for ATA card 0 to 9999999 (in units of 1 K byte) ###: Remaining memory capacity of PC save area of the flash memory card: 0 to 895 (in K bytes) &&&&: Remaining memory capacity of writable character storage area for the flash memory card 0 to 3147 (in K bytes)

  • Page 37: Lcd Messages In Different Languages (Upper Line Of Lcd)

    5.14 LCD MESSAGES IN DIFFERENT LANGUAGES (UPPER LINE OF LCD) ENGLISH GERMAN FRENCH ON LINE ON LINE PRETE HEAD OPEN KOPF OFFEN TETE OUVERTE PAUSE **** PAUSE **** PAUSE **** COMMS ERROR UEBERTR.-FEHLER ERR. COMMUNICAT. PAPER JAM **** PAPIERSTAU **** PB.
  • Page 38 No. DUTCH No. SPANISH No. JAPANESE IN LIJN ON LINE KOP OPEN CABEZAL ABIERTO PAUZE **** PAUSA **** COMM. FOUT ERROR COMUNICACI PAPIER VAST **** ATASCO PAPEL**** SNIJMES FOUT**** ERROR CORTAD**** PAPIER OP **** SIN PAPEL **** LINT OP **** SIN CINTA **** KOP OPEN...
  • Page 39 Italian PRONTA TESTA APERTA PAUSA **** ERR. COMUNICAZ. CARTA INCEP.**** ERR. TAGL. **** NO CARTA **** NO NASTRO **** TESTA APERTA**** 10 ERROR TESTA 11 TEMP. TESTA ALTA 12 ERR. NASTRO **** 13 RIAVV.PIENO **** 14 SALVA ### &&&& SALVA %%%%%%% 15 ERR.SCRITT.CARD 16 ERR.

  • Page 40: Outline Of System Mode

    6. SYSTEM MODE 6.1 OUTLINE OF SYSTEM MODE In this mode, the printer self-test operation and parameter setting operation are performed. Described below is the key operation procedure performed regarding the system mode. System mode for service persons and system administrators (All system mode menus are available.) Power OFF While holding the [FEED] and [PAUSE] keys down, turn the power on.
  • Page 41 Continued from the previous page. RFID read test, RFID module type selection, [RESTART] [FEED] RFID carrier sense setting, RFID tag type selection, Max. number of <10>RFID RFID issue retries, RFID error tag detection, Max. number of RFID read retries, RFID read retry time-out, Max. number of RFID write retries, [FEED] RFID write retry time-out, RFID adjustment for retry, RFID wireless power level, AGC threshold setting, Channel setting...

  • Page 42: Self-Test

    6.2 SELF-TEST 6.2.1 Self-test Operation Example (1) Maintenance counter/various parameters printout, automatic self-test printout (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. <...
  • Page 43 (21) Start of automatic self-test < 1 > D I A G . V 1 . 0 A C H E C K I N G & P R I N T (22) Results printout (23) The self-test menu is displayed. <...
  • Page 44 (2) Head broken dots check (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 45 (16’) Results display (Error) < 1 > D I A G . V 1 . 0 A H E A D E R R O R [PAUSE] (17’) Press the [PAUSE] key. (18’) The self-test menu is displayed. < 1 > D I A G . V 1 .

  • Page 46: Self-Test Items

    6.2.2 Self-test Items (1) Maintenance counter/various parameters printout Maintenance counter • Total label distance covered (cannot be cleared) • Label distance covered • Print distance • Cut count • Head-up/down count • Ribbon motor drive time • Head-up solenoid drive time •...
  • Page 47 • Web printer function setting • Reset process when the nInit signal is ON • Ribbon near end detection setting • Expansion I/O operation mode setting • Centronics operation mode setting • Plug-and-play operation setting • Label end/ribbon end process setting •...
  • Page 48 • Reflective sensor • Transmissive sensor • Ribbon end sensor • Thermal head resistance rank Expansion I/O loop back check Internal serial I/F loop back check RFID module check - 45 -...

  • Page 49: Self-Test Results Printout Samples

    6.2.3 Self-test Results Printout Samples (1) Maintenance counter/various parameters printout TOTAL FEED 1.1km [QQ] RFID MODULE [U1] FEED 1.1km RFID TAG TYPE [NONE] PRINT 0.5km RFID ERR CHECK [OFF] RFID RETRY HEAD U/D RFID RD CYCLE [5] [2.0sec] RIBBON RFID WT CYCLE [5] [2.0sec] SOLENOID RFID ADJ RETRY...
  • Page 50 NOTE: Print conditions: 288 mm of label length, thermal transfer/direct thermal print (*1) (*2) mode , no sensor used, 6 ips/5 ips , one sheet to print, batch issue, no driving of paper rewind motor (*1) Depends on the print type setting. (*2) B-SX4: 6 ips, B-SX5: 5 ips (2) Automatic self-test printout When the firmware version of the MAIN PC...

  • Page 51: Self-Test Printout Contents

    6.2.4 Self-test Printout Contents (1) Maintenance counter Item Contents Range TOTAL FEED Total label distance covered 0.0 to 3200.0 km (cannot be cleared) FEED Label distance covered 0.0 to 3200.0 km PRINT Print distance 0.0 to 200.0 km Cut count 0 to 1000000 HEAD U/D Head up/down count...
  • Page 52 Maintenance Counter Count Conditions Head-up solenoid drive time Counts when the ribbon saving operation is performed. For B-SX4: When the power is off, a drive time of 32 seconds or less is rounded down and backed up. For B-SX5: When the power is off, a drive time of 27 seconds or less is rounded down and backed up.
  • Page 53 Item Contents Remarks PC-850: PC-850 Character code selection FONT PC-852: PC-852 PC-857: PC-857 PC-8: PC-8 PC-851: PC-851 PC-855: PC-855 PC-1250: PC-1250 PC-1251: PC-1251 PC-1252: PC-1252 PC-1253: PC-1253 PC-1254: PC-1254 PC-1257: PC-1257 LATIN9: LATIN9 Arabic: Arabic UTF-8: UTF-8 0 : No slash used Font “0”...
  • Page 54 Item Contents Remarks Language selection for LCD ENGLISH: English MESSAGE messages GERMAN: German FRENCH: French DUTCH: Dutch SPANISH: Spanish JAPANESE: Japanese ITALIAN: Italian Forward feed standby after an ON: Performed FORWARD WAIT issue (A fine adjustment value for the stop position is also printed.) OFF: Not performed Forward feed standby action...
  • Page 55 Item Contents Remarks Automatic broken dots check ON: Automatic broken dots check AUTO HD CHK setting is performed. OFF: Automatic broken dots check is not performed. Centronics ACK/BUSY timing TYPE 1: The ACK signal is sent to ACK/BUSY setting match the rising edge of ACK signal and the falling edge of the BUSY signal.
  • Page 56 Item Contents Remarks System mode password operation OFF: Password is not asked to SYSTEM PASSWORD enter the system mode. ON: Password is asked to enter the system mode. Password: 4-digit HEX value Printer IP address ***.***.***.*** PRTR IP ADDRESS Gateway IP address ***.***.***.*** GATE IP ADDRESS Subnet mask...
  • Page 57 Item Contents Remarks RFID module type selection NONE: No RFID kit is installed. RFID MODULE B-9704-RFID-U1-EU/US B-9704-RFID-H1-QM B-SX704-RFID-H2 B-SX704-RFID-U2 RFID tag type selection I-Code: RFID TAG TYPE Tag-it: C220: ISO15693: C210: C240: C320: EPC Class0: EPC Class1: ISO18000-6B: EPC C1 Gen2: 24 RFID error tag detection ON: Detection is enabled.
  • Page 58 (3) Memory check contents Model name: B-SX4: B-SX4T-GS10-QQ/QP/CN B-SX5: B-SX5T-TS10-QQ/QP/CN Part number PROGRAM B-SX4T 7FM00226000 MAIN 15OCT2002 V1.0A:1A00 Checksum Version V1.0 A Creation date Revision (Day-Month-Year) Version Name PROGRAM: Program area BOOT 20SEP2002 V1.0 :8500 Checksum Version V1.0 A Creation date Revision (Day-Month-Year) Version...
  • Page 59 SDRAM Capacity of SDRAM (8 MB for B-SX4, 16 MB for B-SX5) Memory for the system and drawing CARD SLOT 1 ATA ATA: ATA card is installed. SLOT 2 LAN LAN: LAN card is installed. FSH: Flash memory card is installed. ATA card or flash memory card which is not formatted, is installed, neither card is installed.
  • Page 60 When the MAIN PC Board type is the PWA-SX MAIN2 (Part No.: 7FM00503x00), the heat sink sensor status is not printed. SENSOR2 [H]20 C [A]22 C [S]25 ° ° ° Heat sink sensor status (25 °C, 80 °C, 90 °C) Open-air temperature sensor status (0 to 86 °C, --°C if it cannot be detected) Thermal head temperature sensor status...
  • Page 61 (5) Expansion I/O check contents EXP.I/O NG OK: Normal data NG: Abnormal data, or the loop-back jig is not connected. Expansion I/O * Connect the cable as illustrated below, then check the high output/high input, low output/low input. R = 300 ohms Connector: FCN-781P024-G/P (6) Internal serial I/F check contents EX.232C NG...

  • Page 62: Various Parameters Setting

    6.3 VARIOUS PARAMETERS SETTING 6.3.1 Various Parameters Setting Operation Example Power OFF (1) Power off state (2) While holding the [FEED] and [RESTART] [FEED] [RESTART] keys down, turn the power on. (3) The self-test menu is displayed. (3) The self-test menu is displayed. <...
  • Page 63 (13) Data length selection: < 2 > P A R A M E T E R S E T Select the data length using the [FEED] D A T A L E N G . 8 b i t s and [RESTART] keys.
  • Page 64 (33) Control code selection: < 2 > P A R A M E T E R S E T Select the code using the [FEED] and C O D E E S C , L F , N U L [RESTART] keys.
  • Page 65 (53) Expansion I/O operation mode setting: < 2 > P A R A M E T E R S E T Select the operation mode using the [FEED] and [RESTART] keys. E X . I / O T Y P E 1 (54) Press the [PAUSE] key.
  • Page 66 In the case of V4.4A In the case of V4.4 (71) The parameter setting menu is displayed. < 2 > P A R A M E T E R S E T (71) XML function setting: < 2 > P A R A M E T E R S E T Select the specification of the XML function, using the [FEED] or [RESTART] key.
  • Page 67 6.3.2 Setting Contents (1) Character code selection (FONT CODE) • PC-8 • PC-857 • PC-852 • PC-850 • Arabic • LATIN9 RESTART • PC-1257 • PC-1254 FEED • PC-1253 • PC-1252 • PC-1251 • PC-1250 • PC-855 • PC-851 • UTF-8 (V4.4A only) (2) Font “0”...
  • Page 68 (5) RS-232C stop bit length selection (STOP BIT) RESTART • 2 bits • 1 bit FEED (6) RS-232C parity selection (PARITY) RESTART • EVEN • ODD FEED • NONE (No parity) (7) RS-232C transmission control method selection (XON/XOFF, READY/BUSY) • XON/XOFF AUTO XON/XOFF protocol (XON output when the power is on, XOFF output when the power is off)
  • Page 69 (9) Setting for forward feed standby after an issue (FORWARD WAIT) [RESTART] FORWARD WAIT OFF • OFF: Not performed • ON: Performed [RESTART] [FEED] FORWARD WAIT ON [FEED] [PAUSE] [FEED] POSITION +0.0mm [FEED] [RESTART] POSITION +0.5mm [FEED] [RESTART] Setting for the fine adjustment value for the POSITION +5.0mm stop position after a forward feed standby: [FEED]...
  • Page 70 (12) Installed solenoid type setting (SOLENOID) RESTART • TYPE 1: TDS-12C (wound with blue tape) is installed. • TYPE 2: TDS-16A (stronger pull force type wound with black tape) is FEED installed. NOTE: If this setting does not match the actually installed solenoid type, ribbon saving function may not be able to work.
  • Page 71 (15) Peel-off wait status selection (PEEL OFF STS) RESTART • OFF: No peel-off wait status selection • ON: Peel-off wait status selection FEED (16) [FEED] key function setting (FEED KEY) RESTART • FEED: One label is fed. • PRINT: Data in the image buffer is printed on one label. FEED (17) Kanji code selection (KANJI CODE) KANJI CODE TYPE1...
  • Page 72 (21) Web printer function setting (WEB PRINTER) RESTART • OFF: Web printer function is disabled. • ON: Web printer function is enabled. FEED (22) Reset process when the nInit signal is ON (INPUT PRIME) RESTART • OFF: The reset process is not performed. •...
  • Page 73 (26) Plug-and-play operation setting (PLUG & PLAY) RESTART • OFF: Plug-and-play operation is disabled. • ON: Plug-and-play operation is enabled. FEED NOTE: In the USB interface, plug-and-play operation is always enabled, regardless of this setting. (27) Label end/ribbon end process setting (LBL/RBN END) RESTART •...
  • Page 74 • When a ribbon end is detected where the unfinished label length is less than 30 mm, the printer completes the half-finished label and stops printing when the next label is at the home position, displaying the error message “NO RIBBON X”.

  • Page 75: November

    (28) Pre-peel-off process setting (PRE PEEL OFF) RESTART • OFF: Pre-peel-off operation is not performed.. • ON: Pre-peel-off operation is performed. FEED NOTE: When the printer speed “10 ips” is specified, the pre-peel-off operation is performed, even if it is set to OFF in this setting. (29) Back feed speed setting (BACK SPEED) RESTART •...
  • Page 76 (32) System password setting (PASSWORD) • With the system mode password parameter set to ON, a password entry window appears when either of the following occurs: a) “system mode for service persons and system administrators” is invoked, b) “system mode for users” is invoked, or c) the [PAUSE] and [RESTART] keys are held down for 3 seconds to invoke the system mode.
  • Page 77 • System mode password entry Enter system password mode (while holding the [FEED]+[RESTART] keys down, turn the power on, while holding the [FEED] and [PAUSE] keys down, turn the power on, or press the [PAUSE] key in online mode, then the [RESTART] key for 3 seconds. System password disabled System password enabled System password...
  • Page 78 (33) XML function setting (XML) Note: Supported only by V4.4A. RESTART • STD: Standard specification • LOW: Specification for Oracle FEED - 75 -...
  • Page 79 6.4 FINE ADJUSTMENT VALUE SETTING 6.4.1 Fine Adjustment Value Setting Operation Example (1) Power off state Power OFF [FEED] [PAUSE] (2) While holding the [FEED] and [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 80 (19) Print density fine adjustment < 3 > A D J U S T S E T (Direct thermal print mode): T O N E A D J . < D > Set the fine adjustment value using the [FEED] and [RESTART] keys. [PAUSE] (20) Press the [PAUSE] key.
  • Page 81 6.4.2 Setting Contents (1) Feed fine adjustment (FEED ADJ.) +0.0 mm +50.0 mm +49.5 mm Print start One label position RESTART +0.5 mm +0.0 mm +3.0 mm -0.5 mm FEED Print start One label position -49.5 mm -50.0 mm -3.0 mm Paper feed direction One label Print start position...
  • Page 82 [Procedure for label having label pitch of less than 38 mm when the swing cutter is used] The minimum label pitch of the label which can be cut in normal use is 38.0 mm. When a label having a label pitch of less than 38.0 mm is used (although it is out of specifications), the edge of the label is caught by the edge of the thermal head during a back feed to the home position after cutting the gap area between labels.
  • Page 83 (b) Operation example Issue count: 2, Cut interval = 1 Head position position Idling Completes printing the first label (A). Feeds the label to the cut position, then cuts the gap at the front of label (A). Backfeeds to the home position. Completes printing the second label (B).
  • Page 84 [Procedure for label having less than the min. label pitch for each issue speed when the rotary cutter is used] When the following conditions are all met, the cut operation for the last label to be cut is as follows. Forward feed to the cut position →...
  • Page 85 [Strip position fine adjustment] +0.0 mm +3.0 mm - 3.0 mm Printing in strip issue mode is stopped at the position where the 4 mm distance from the middle point of the gap between labels to the end of the strip shaft is 4 mm, since the gap between labels is 3 mm assumed to be 2 mm.
  • Page 86 (3) Back feed fine adjustment (BACK ADJ.) +0.0 mm +9.5 mm +9.0 mm Print start position (Home position after a back feed) +0.5 mm RESTART +0.0 mm -0.5 mm FEED +3.0 mm -9.0 mm Print start position -9.5 mm (Home position after a back feed) -3.0 mm Paper feed direction Print start position...
  • Page 87 (5) Print density fine adjustment (Thermal transfer/direct thermal) (TONE ADJ.) Darker +10 step +9 step RESTART +1 step Standard +0 step -1 step FEED -9 step -10 step Lighter ([Step] is not displayed.) (6) Ribbon motor drive voltage fine adjustment setting (Rewind) (RBN ADJ <FW>) [RESTART] +0 step (Standard) RBN ADJ <BK>...
  • Page 88 (8) Transmissive sensor manual threshold fine adjustment setting (THRESHOLD<T>) +4.0 V +3.9 V RESTART NOTE: If “0.0 V” is set, when the power is turned OFF then ON, the value “0.0 V” FEED is returned to the initial value (1.0 V). +0.1 V +0.0 V (9) Reflective sensor manual threshold fine adjustment setting (THRESHOLD<R>)
  • Page 89 Supplementary explanation • When the [RESTART] and [FEED] keys are pressed at the same time, the display shows the system mode menu. • If the [RESTART] or [FEED] key is held down for 0.5 seconds or more when a fine adjustment value is being set, the printer enters the repeat mode, in which the key is entered repeatedly.

  • Page 90: Test Print

    6.5 TEST PRINT 6.5.1 Test Print Operation Example (1) Normal test print (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 91 (19) Print type setting mode: < 4 > T E S T P R I N T Select the print type using the [FEED] P R T T Y P E T R A N S F R and [RESTART] keys. (20) Press the [PAUSE] key.
  • Page 92 (2) Test print for assembly process (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 93 (19) System mode menu display < 4 > T E S T P R I N T (Test print) (20) Press the [PAUSE] key. [PAUSE] (21) Assembly process automatic printout < 4 > T E S T P R I N T mode (Transmissive sensor) A U T O P R I N T ( T R A N )
  • Page 94 6.5.2 Setting Contents (1) Test print mode selection • PRINT CONDITION (Test print condition parameter setting) • SLANT LINE (1DOT) (1-dot slant line printout) • SLANT LINE (3DOT) (3-dot slant line printout) • CHARACTERS (Character printout) RESTART • BARCODE (Bar code printout) •...
  • Page 95 (5) Sensor selection (SENSOR) RESTART • NONE (No position detected) • REFLECT. (Reflective sensor) FEED • TRANS. (Transmissive sensor) (6) Print type (PRT TYPE) RESTART • TRANSFR (Thermal transfer) • DIRECT (Direct thermal) FEED (7) Issue type (TYPE) RESTART • [S] NO CUT (Batch issue mode) •...
  • Page 96 (10) Initial parameter values when turning the power on • Menu selection: Test print condition parameter setting • Issue count setting (ISSUE COUNT): 1 • Print speed (PRINT SPEED): 6”/sec for B-SX4, 5”/sec for B-SX5 • Sensor selection (SENSOR): Transmissive sensor •...
  • Page 97 • For B-SX4, the print speed “10 ips” is not supported for printing with the rotary cutter. If “10 ips” is specified when the rotary cutter has been installed, the print speed is corrected from 10 ips to 6 ips, regardless of the cut designation. For B-SX4, if less than 15.0 mm and 30.0 mm of the label pitch is specified for printing at 3 ips and 6 ips, respectively, an issue without a cut is performed.

  • Page 98: Test Print Samples

    6.5.3 Test Print Samples 1-dot slant line printout 3-dot slant line printout - 95 -...
  • Page 99 Character printout (B-SX4) Character printout (B-SX5) - 96 -...
  • Page 100 Bar code printout (B-SX4) Bar code printout (B-SX5) - 97 -...
  • Page 101 Line printout for the assembly process - 98 -...

  • Page 102: Sensor Display/Adjustment

    6.6 SENSOR DISPLAY/ADJUSTMENT 6.6.1 Sensor Display/Adjustment Operation Example (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 103 (21) Transmissive sensor adjustment value < 5 > S E N S O R A D J . display: [ T R A N S . ] 2 . 4 V Remove the label from the label paper and load the backing paper. (The [RESTART] label should not cover the sensor.) (22) Hold down the [RESTART] or [FEED]...

  • Page 104: Display Contents

    6.6.2 Display Contents (1) Sensor adjustment value display [ H ] 2 0 ° C [ A ] 2 2 ° C Open-air temperature sensor status (0 °C to 86 °C) Thermal head temperature sensor status (0 °C to 86 °C) [ S ] 2 5 °...

  • Page 105: Ram Clear

    6.7 RAM CLEAR 6.7.1 RAM Clear Operation Example (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 106 (21) RAM clear for the QP type (21) RAM clear for the QP type < 6 > R A M C L E A R * * * T Y P E * * * (22) Press the [FEED] key. [FEED] (23) RAM clear for the QQ type <...

  • Page 107: Ram Clear Contents

    6.7.2 RAM Clear Contents (1) RAM clear mode RESTART • NO RAM CLEAR • MAINTE.CNT CLEAR FEED • PARAMETER CLEAR (2) Selection of destination type RESTART • QP TYPE (for Europe/Asia) • QQ TYPE (for North/South America/China) FEED • CN TYPE (for China) •...
  • Page 108 (5) Initial values after parameter clear Parameter Initial Value Feed fine adjustment (PC) 0 mm Cut position (or strip position) fine adjustment (PC) 0 mm Back feed fine adjustment (PC) 0 mm Print density fine adjustment: Thermal transfer print mode (PC) Print density fine adjustment: Direct thermal print mode (PC) Ribbon motor drive voltage fine adjustment...
  • Page 109 Parameter Initial Value QP type English QQ type English Language for LCD messages CN type English QM type English Forward feed standby after an issue Forward feed standby action MODE 1 Head-up operation in cut issue mode, or use of the (Head-up operation is not operated/ rewinder the rewinder is not used.)
  • Page 110 Parameter Initial Value BASIC interpreter setting BASIC interpreter trace setting DHCP setting RFID module type selection NONE RFID tag type selection NONE RFID error tag detection Max. number of RFID issue retries Max. number of RFID read retries RFID read retry time-out 4.0 seconds Max.

  • Page 111: Ip Address Setting

    6.8 IP ADDRESS SETTING 6.8.1 IP Address Setting Operation Example (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 112 (21) Subnet mask setting mode < 7 > I P A D D R E S S S U B N E T M A S K (22) Press the [RESTART] key. [RESTART] (23) Socket port number setting mode < 7 > I P A D D R E S S S O C K E T P O R T...
  • Page 113 (41) Setting for the next 8 bits < 7 > I P A D D R E S S 1 5 7 . 1 6 7 . 0 1 0 . 0 1 0 [FEED] (42) Press the [FEED] key. (43) Setting for the next 8 bits <...
  • Page 114 (61) Setting for the next 8 bits < 7 > I P A D D R E S S 1 5 7 . 0 6 9 . 0 4 6 . 0 1 1 [RESTART] (62) Press the [RESTART] key. (63) Setting for the next 8 bits <...
  • Page 115 (81) Socket communication setting < 7 > I P A D D R E S S (Enabled) P O R T 0 8 0 0 0 [PAUSE] (82) Press the [PAUSE] key. (83) Set a value for the 5th digit. <...
  • Page 116 (101) DHCP client ID input mode setting M O D E A S C I I (ASCII)* D H C P C L I E N T (102) Press the [RESTART] key. [RESTART] (103) DHCP client ID input mode setting M O D E H E X (HEX)
  • Page 117 6.8.2 Setting Contents [FEED] [RESTART] [RESTART] [FEED] [FEED] 254.000.000.000 000.254.000.000 PRINTER IP ADRES [FEED] [FEED] [RESTART] [RESTART] [FEED] [RESTART] 255.000.000.000 000.255.000.000 [RESTART] [RESTART] [FEED] [FEED] 000.000.000.000 000.000.000.000 GATEWAY IP ADRES [PAUSE] [PAUSE] [RESTART] [RESTART] [FEED] [FEED] [FEED] [RESTART] 001.000.000.000 000.001.000.000 [FEED] [RESTART] [FEED]...

  • Page 118: Basic Setting

    6.9 BASIC SETTING 6.9.1 BASIC Setting Operation Example (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. (3) The self-test menu is displayed. <...
  • Page 119 (21) BASIC file browser (21) BASIC FILE BROWSER < 8 > B A S I C F I L E M A I N T E N A N C E (22) Press the [RESTART] key. [RESTART] (23) BASIC trace setting <...
  • Page 120 (39) Program file display < 8 > B A S I C T E S T . B A S (40) Press the [PAUSE] key. [PAUSE] (41) BASIC trace setting < 8 > B A S I C B A S I C T R A C E (42) Press the [PAUSE] key.

  • Page 121: Adjustment Mode For Factory

    6.10 ADJUSTMENT MODE FOR FACTORY (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 122 (21) Head-up adjustment mode display < 9 > F O R F A C T O R Y H E A D A D J U S T [PAUSE] (22) Press the [PAUSE] key. (23) Option check mode display < 9 > F O R F A C T O R Y O P T I O N C H E C K...
  • Page 123 NOTE: Option Check Details By installing the tool for option check, the following connectors on the board are checked: the solenoid connector (CN11), the peeled-off paper sensor connector (CN20), rewinder overflow sensor connector (CN4), the rotary cutter detection connector (CN18). If the check results in a failure, then the failed item number is displayed on the LCD.

  • Page 124: Rfid Setting

    6.11 RFID SETTING 6.11.1 RFID Setting Operation Example (1) Power off state Power OFF (2) While holding the [FEED] and [PAUSE] [FEED] [PAUSE] keys down, turn the power on. (3) The self-test menu is displayed. < 1 > D I A G . V 1 .
  • Page 125 (21) RFID setting menu display < 1 0 > R F I D (22) Press the [PAUSE] key. [PAUSE] (23) RFID read test menu < 1 0 > R F I D Make a choice by using the [FEED] or R E A D T E S T O F F...
  • Page 126 (41) RFID write retry time-out < 1 0 > R F I D Set the value by using the [FEED] or [RESTART] key. C Y C L E T I M 2 . 0 [PAUSE] (42) Press the [PAUSE] key. (43) RFID adjustment for retry <...
  • Page 127 6.11.2 Setting Contents (1) RFID read test RESTART • OFF: A read test is not performed. • ON: A read test is performed. FEED OFF: A read test is not performed. ON: The printer enters the read test mode, and a read test is performed each time the [PAUSE] key is pressed.
  • Page 128 (3) RFID module type selection • U1: B-9704-RFID-U1-US/EU is installed. RESTART • H1: B-9704-RFID-H1-QM is installed. • NONE: No RFID kit is installed. FEED • U2: B-SX704-RFID-US is installed. • H2: B-SX704-RFID-H2 is installed. NONE: No RFID kit is installed. The RFID kit for UHF band (B-9704-RFID-U1-US/EU) is installed.
  • Page 129 When the RFID module type is set to “U1”: • EPC C1: RESTART • EPC C0: • NONE (When a tag type is not selected.) FEED • EPC C1 Gen2: • ISO18000-6B: When the RFID module type is set to “H1”: •...
  • Page 130 (6) Max. number of RFID issue retries • + RESTART • Initial value (3) • − FEED 0 to 255 Set the maximum number of retries to issue the RFID tag. When issuing the RFID tag failed, the printer prints the error pattern, and retries to issue the tag for up to specified number of times.
  • Page 131 (9) Max. number of RFID write retries • + RESTART • Initial value (5) • − FEED 0 to 255 Set the maximum number of retries to write data onto the RFID tag. The printer retries to write data onto the RFID tag for up to specified number of times. If the time-out has come before the max.
  • Page 132 (12) RFID wireless power level When the B-9704-RFID-U1-US/EU is installed. • 255 RESTART • 252 • Initial value (251) FEED • 250 • 0 0 to 255 Set the wireless power level from the RFID module. When the value is “0”, the power is the weakest and when “255”, the power is the strongest.
  • Page 133 (14) RFID channel setting Available only when the B-SX704-RFID-U2 is installed. • 8CH RESTART • 2CH • AUTO FEED • 8CH • 2CH 2CH to 8CH, AUTO Set the channel to be used for writing data onto RFID tags. When a channel is chosen from 2CH to 8CH, that channel will be repeatedly used. When the channel is set to AUTO, more than one channels are repeatedly used in the following order.

  • Page 134: Download Mode

    7. DOWNLOAD MODE (1) Power off state Power OFF (2) Turn the power on by pressing the [FEED]+[RESTART]+[PAUSE] [FEED], [RESTART] and [PAUSE] keys at the same time. D O W N L O A D M O D E (3) Download mode display [FEED] (4) Press the [FEED] key.
  • Page 135 When the power is turned on while pressing the [FEED], [RESTART], and [PAUSE] keys at the same time, the printer enters the download mode. In the download mode, only commands concerning downloading are available. The printer keys can be used for selecting between “DOWNLOAD MODE” and “DOWNLOAD MODE 2”. The timing for ACK-BUSY in Centronics differs between “DOWNLOAD MODE”...

This manual is also suitable for:

B-sx5 series

Table of Contents
