Table 29. Configuration elements related with smartcard and SWP

Setting
Default setting.
R109 in
Smartcard SWP cannot be handled:
R39 in
PB12 is routed to USB OTG FS port as USBOTG_OVRCR line, on
SB3 open
top of being routed to SWIO port of smartcard
CN11 I/O-bridged
Configuration dedicated for USB OTG FS operation.
R109 out Smartcard SWP can be handled:
R39 in PB12 is routed to SWIO port of smartcard. It is disconnected from
SB3 open any other resource that could affect the SWP operation
CN11 I/O-bridged Configuration dedicated for smartcard SWP operation
Smartcard SWP cannot be handled:
R39 out
PB12 is routed to motor control as MC_PFC_Shutdown
SB3 closed
Configuration dedicated for motor control operation
Smartcard SWP cannot be handled:
R39 out PB12 is only routed to touch-sensing button and it is disconnected
SB3 open from any other resource.
Configuration dedicated for touch-sensing button operation.
Default setting.
R62 in
Smartcard controller U30 is supplied with clock:
SB14 open
PB0 port is routed to XTAL1 of U30, as SmartCard_CLK line and it
SB15 open
is not routed to other resources.
CN11 I/O-bridged
Configuration dedicated for smartcard operation.
Smartcard controller U30 is not supplied with clock:
R62 out PB0 is routed to Quad-SPI Flash memory device as QSPI_D1 and it
SB14 closed is not routed to other resources.
SB15 open Configuration dedicated for Quad-SPI Flash memory device
operation.
Smartcard controller U30 is not supplied with clock:
R62 out
PB0 is routed to motor control as MC_PWM_2L line and it is not
SB14 open
routed to other resources.
SB15 closed
Configuration dedicated for motor control operation.
Default setting.
R65 in Smartcard controller gets SmartCard_IO line:
SB17 open PC4 port of MCU is routed to IOUC port of U30, as SmartCard_IO
CN14 I/O-bridged line and it is not routed to other resources.
Configuration dedicated for smartcard operation.
Smartcard controller does not get SmartCard_IO line:
R65 out PC4 port of MCU is routed to motor control as MC0PFC0IndCur line
SB17 closed and it is not routed to other resources.
Configuration dedicated for motor control operation.
