UM1855
Terminal
1
3.11

RF-EEPROM daughterboard connector CN3

Terminal
1
2
3
4
3.12

Motor control connector CN2

Table 40. Analog input-output connector CN8

Function / MCU port
GND

Figure 27. RF EEPROM daughterboard connector CN3 (front view)

Table 41. RF-EEPROM daughterboard connector CN3

Terminal name (MCU port)
I2C_SDA (PG13)
NC
I2C_SCL (PG14)
EXT_RESET(PC6)

Figure 28. Motor control connector CN2 (top view)

DocID027351 Rev 3
Terminal Function / MCU port
2 analog input-output PA4
Terminal Terminal name (MCU port)
5
6
7
8
Connectors
+3V3
NC
GND
+5 V
69/100
