Hardware layout and configuration
LCD
segment
SEG0
SEG1
SEG2
SEG3
SEG4
SEG5
SEG6
SEG10
34/100

Figure 10. LCD glass module daughterboard in I/O-bridge position

Table 14. LCD-daughterboard-related configuration elements

Setting to enable
Element LCD glass
module
R82 In
SB32 Open
R81 In
SB31 Open
R78 In
SB22 Open
R68 In
SB21 Open
SB20 Open
R66 In
SB18 Open
SB19 Open
R62 In
SB14 Open
SB15 Open
R56 In
SB12 Open
SB13 Open
R50 In
SB9 Open
DocID027351 Rev 3
Description
PA1 routed to LCDSEG0
PA1 not routed to motor control
PA2 routed to LCDSEG1
PA2 not routed to motor control
PA3 routed to LCDSEG2
PA3 not routed to motor control
PA6 routed to LCDSEG3
PA6 not routed to Quad-SPI Flash memory device
PA6 not routed to motor control
PA7 routed to LCDSEG4
PA7 not routed to Quad-SPI Flash memory device
PA7 not routed to motor control
PB0 routed to LCDSEG5
PB0 not routed to Quad-SPI Flash memory device
PB0 not routed to motor control
PB1 routed to LCDSEG6
PB1 not routed to Quad-SPI Flash memory device
PB1 not routed to motor control
PB10 routed to LCDSEG10
PB10 not routed to Quad-SPI Flash memory device
UM1855
