To program the TWA mode option:
1. From the Programming menu, select Communications, Comm.
Options, Two-Way Audio, TWA Mode [95412].
2. Select Duplex or Simplex.

10.7: GSM Options

10.7.1: GSM RX Report
The GSM RX Report is a feature that periodically reads the GSM signal strength of the Cellular
Communications module – see 4.7.9: GSM Signal Strength. This reading occurs at the times
programmed for the Periodic Test – see 10.6.2: Periodic Test Interval & 10.6.3: First Test. This
means that each time the periodic test is sent, the system also sends a GSM signal strength
report to the central station. The system also enters the GSM signal strength in the event log.
If the Periodic Test is disabled, the GSM RX Report feature will not function.
The GSM RX report belongs to the Peripherals event group – see 10.9: Event Options for
Central Station Reporting. If this event group is disabled, the GSM signal strength is still
recorded in the event log.
To program the GSM RX Report option:
1. From the Programming menu, select Communications, Comm.
Options, GSM Options, GSM RX Report [954131].
2. Select Enabled or Disabled.
10.7.2: PIN Code
The PIN (Personal Identity Number) is a four-digit code that protects the SIM card from
unauthorized use if lost or stolen.
When using a SIM card with an activated PIN code, the installer has to make sure that the PIN
code programmed in the Control System is the same as the SIM card's PIN code. The PIN code
should be programmed in the system before inserting the SIM card in the GSM module.
To program the PIN code:
1. From the Programming menu, select Communications, Comm.
Options, GSM Options, PIN Code [954132].
2. Edit the four-digit PIN code.
3. Press when you have finished editing.
4. Power up the Control System to apply the new PIN Code definition.
The new PIN code takes effect only after the System is powered up.
If a wrong PIN code was programmed in the system, a System Trouble is generated, PIN
Code Error message is displayed, and GSM communication of any kind is not available. In
this case, the SIM card must be reactivated.
To reactivate a SIM card:
1. Program the correct PIN code in the Control System (see above), then
disconnect the Control System from all the power sources.
2. Remove the SIM card from the GSM module and insert it into a
cellular phone.
3. Turn on the cellular phone and enter the correct PIN code.
4. Re-install the SIM card into the Control System and apply power.
-75-
