Electronics Line Infinite Prime Installation Manual page 31

Code 28: Duress Code
The Duress code is designed for situations where the user is being forced to operate the
system. This user code grants access to the selected operation, while sending a Duress
event message to the central station.
Code 29: Telecontrol Code
The Telecontrol code is designed to enable the user to perform a number of tasks via their
telephone using DTMF commands. Using this code, the user can call their system to arm
and disarm, turn on and off Home automation units, activate and deactivate the PGM output,
cancel siren activation, or establish Two-Way Audio communication.
Code 30: Central Station TWA Code
The Central Station TWA code is designed to enable the central station operator to
establish Two-Way Audio communication with the control system after an alarm. This
code is valid for use for the first ten minutes after an alarm has occurred. This code can
only be used for this specific purpose and does not grant access to any additional system
functions such as disarming.
Code 31: Guard Code (future option)
The Guard Code is a future option that is not available in the current firmware.
Code 32: Installer Code
The Installer code grants access to the Programming menu and the Service menu.
Additionally, this code enables you to view and clear the Event Log.
The default Installer code is 1111. Change this code immediately after installing
the system!
4.4.1: Editing User Codes
To edit a user code:
1. From the main menu select, User Codes [4].
2. Select the code you want to edit.
3. From the code's sub-menu, select Edit Code [#1]; the 4-digit code is
displayed with the cursor flashing on the first digit.
4. Edit the code.
5. Press ; the new code is stored in the memory.
If you enter a code that is identical to an existing user code, the control system sounds an
error tone and the new code is not accepted.
Codes 1-29 can be edited only by the Master code. The Installer code, Guard Code and
the Central Station TWA Code can be edited only by the installer.
4.4.2: Deleting User Codes
To delete a user code:
1. From the main menu select, User Codes [4].
2. Select the code you want to delete.
3. From the code's sub-menu, select Edit Code [#1]; the 4-digit code is
displayed with the cursor flashing on the first digit.
4. Enter 0000.
5. Press ; the code is deleted.
The Installer and Master codes cannot be deleted.
-31-
