Appendix D: Zone Types - Electronics Line Infinite Prime Installation Manual

Normal
A Normal zone is active when the system is armed. This zone generates a Burglary
alarm instantly when triggered. Normal zones are designed for detectors installed inside
the protected site or doors/windows that are never used to enter the premises.
Entry/Exit
When the system is armed, Entry/Exit zones initiates the entry delay when triggered. If
the system is not disarmed by the time the entry delay expires, a Burglary alarm is
generated. These zones are designed for detectors protecting the entrance to the
protected site
Follower
If an Entry/Exit zone is triggered first, Follower zones do not generate an alarm when
triggered during the entry delay. If the system is not disarmed by the end of the entry
delay, the Follower zone generates an alarm. A Follower zone instantly generates an
alarm if triggered when the entry delay is not active. These zones are designed for
detectors protecting the area in which a keypad has been installed or the area crossed in
order to reach the keypad.
Panic
Panic zones are always active. When a Panic zone is triggered, a Panic alarm is
generated. This zone type is designed for panic buttons that may be pressed in a hold-up
situation. If the Bell option is disabled for Panic zones, in addition to the siren not
sounding, all forms of alarm indication from the keypad are also disabled.
Medical
Medical zones are always active. When triggered, Medical zones generate a Medical
alarm. These zones are used typically with panic buttons that may be pressed in the
event of a medical emergency.
Fire
Fire zones are always active. When triggered, Fire zones generate a Fire alarm. These
zones are designed for use with smoke detectors and panic buttons that may be pressed
in the event of a fire. A Fire zone always activates the siren even if the Bell option is
programmed as disabled. Fire alarms sound a pulsating siren to distinguish them from
other alarms.
24Hr
24Hr zones are always active. When triggered, 24Hr zones generate a Burglary alarm.
These zones are used for applications that require constant protection.

Appendix D: Zone Types

-109-
Event Group: Burglary
Event Group: Burglary
Event Group: Burglary
Event Group: Burglary
Event Group: Medical
Event Group: Fire
Event Group: Burglary
