Loudspeaker Type - CyberData 011116 Operation Manual

See Table 2-6
Connection
Ethernet

2.2.5.1 Loudspeaker Type

Using the amplified output, the CyberData VoIP V2 Loudspeaker Amplifier supports the 011068
Loudspeaker or equivalent unamplified loudspeaker.
2.2.5.2 Cabling/Wiring
Using the amplified output, you may connect a loudspeaker to a Loudspeaker Amplifier with a
good quality speaker cable that is limited to 25 feet in length.
Operations Guide
for details about the Loudspeaker Amplifier connections.
Table 2-6. Loudspeaker Amplifier Connections
Connection Details
Use a RJ 45 cable.
●
Figure 2-11. 011068 Loudspeaker
930377F
Installing the VoIP V2 Loudspeaker Amplifier
Loudspeaker Amplifier Setup
Location
VoIP V2 Loudspeaker Amplifier
