A.1.1 Mounting the Enclosure
To mount the enclosure:
1. Prepare holes for the screws.
2. Plug in the power adapter and use the green Power light to verify that the power is on.
3. Plug the Ethernet cable into the Loudspeaker Amplifier. The yellow Link light verifies the
4. For wall mounting, use the three #6 x 1-1/4-inch Pan Head Phillip screws to secure the speaker.
Operations Guide
network connection.
See Figure A-1.
Figure A-1. Mounting the Enclosure
930377F
Mount the Loudspeaker Amplifier
071057A
531032
#6 PLASTIC ANCHOR (3x)
151014
#6x1 1/4" PAN HEAD
PHILLIP SCREW (3x)
