2.2.4.1 Loudspeaker Type

Using the amplified output, the CyberData VoIP V2 Paging Amplifier supports the 011068
Loudspeaker or equivalent unamplified loudspeaker.
2.2.4.2 Cabling/Wiring
Using the amplified output, you may connect a loudspeaker to a Paging Amplifier with a good
quality speaker cable that is limited to 25 feet in length.
Operations Guide
for details about the Paging Amplifier connections.
Table 2-6. Paging Amplifier Connections
Connection Details
Use a RJ 45 cable.
Figure 2-10. 011068 Loudspeaker
930363B
Installing the VoIP V2 Paging Amplifier
Paging Amplifier Setup
Location
VoIP V2 Paging Amplifier
CyberData Corporation
12
