4. On the Test IP Speaker page, Enter a number into the Test duration field.
5. Click Test.
6. You will hear a tone from the unit being testing.
7. After the test, click Cancel to return to the IP Configuration page.
Test duration
Note
Operations Guide
Identifying and Testing a Loudspeaker Amplifier when Using InformaCast 4.0 or Later
View Speaker's Status Page
When viewing the unit's status page via Informacast, Informacast links to the wrong port
and path.
Informacast expects our unit's status page to be at:
http://<ipaddr>:10004/status.
The status page is actually at:
http://<ipaddr>/ (port 80)
Therefore, if a user clicks the link to view the status page and is directed to:
http://10.10.10.10:1004/status
The user will need to edit the url in the address bar to:
http://10.10.10.10/
Figure 2-23. Test IP Speaker Page
Cancel
930377F
Installing the VoIP V2 Loudspeaker Amplifier
Test
