Omron FQ2-S4 User Manual page 506

External Category Data name
refer-
ence
number
180 Judge- Edge position X upper
ment limit 0
condi-
181 Edge position X lower
tions
limit 0
182 Edge position Y upper
limit 0
183 Edge position Y lower
limit 0
185 Edge position X upper
limit 1
186 Edge position X lower
limit 1
187 Edge position Y upper
limit 1
188 Edge position Y lower
limit 1
190 Position compensation
X upper limit
191 Position compensation
X lower limit
192 Position compensation
Y upper limit
193 Position compensation
Y lower limit
310 Logging Data logging switch for
condi- entire unit
tions
311 Data logging switch for
judgement
312 Data logging switch for
scroll X
313 Data logging switch for
scroll Y
314 Data logging switch
for detected edge posi-
tion X0
315 Data logging switch
for detected edge posi-
tion Y0
316 Data logging switch
for detected edge posi-
tion X1
317 Data logging switch
for detected edge posi-
tion Y1
504
External Reference Parameters
Setting/Acqui- Data range
sition
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
−99,999.9999 to
Setting/Acqui-
sition 99,999.9999
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Setting/Acqui- 0: Data logging OFF,
sition 1: Data logging ON
Default Expres- Logged data/
sion text Judgement
string parameter
99,999.9999 --- Adjust judge-
ment
−99,999.9999 ---
Adjust judge-
ment
99,999.9999 --- Adjust judge-
ment
−99,999.9999 ---
Adjust judge-
ment
99,999.9999 --- Adjust judge-
ment
−99,999.9999 ---
Adjust judge-
ment
99,999.9999 --- Adjust judge-
ment
−99,999.9999 ---
Adjust judge-
ment
99,999.9999 --- Adjust judge-
ment
−99,999.9999 ---
Adjust judge-
ment
99,999.9999 --- Adjust judge-
ment
−99,999.9999 ---
Adjust judge-
ment
0 --- ---
0 --- ---
0 --- ---
0 --- ---
0 --- ---
0 --- ---
0 --- ---
0 --- ---
FQ2-S4 User's Manual
