To add a NAT profile, please do the following:
1.
Click Add.
2.
The following page appears.
Available parameters are listed below:
Item
Enable
Name
Interface
Type
Description
Check the box to enable such profile.
Type a name for such profile.
Use the drop down list to specify one LAN profile (which
can be created from Network>>LAN>>Ethernet). If you
cannot find any selection here, simply open
Network>>LN>>Ethernet to create new ones.
Each DHCP service setting belongs to one LAN profile.
DHCP_Server – If it is selected, such profile will be used to
enable the DHCP server. It can respond to the client with the
gateway and DNS server.
DHCP_Relay – If it is selected, it means the real DHCP
server is one of the internal hosts. The client must inquire to
the relay agent which DHCP server will be used. Therefore,
you have to configure Forward to and the Server IP
additionally.
Forward To – Use the drop down list to choose a LAN
