Page 2 Vigor2760 Series User’s Guide...
Page 3 Vigor2760 Series VDSL2 Security Firewall User’s Guide Version: 1.6 Firmware Version: V3.8.2.1 (For future update, please visit DrayTek web site) Date: January 11, 2016 Vigor2760 Series User’s Guide...
Page 4 Web registration is preferred. You can register your Vigor router via Owner http://www.DrayTek.com. Firmware & Tools Due to the continuous evolution of DrayTek technology, all routers will be regularly Updates upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents.
Page 5: European Community Declarations
Product: Vigor2760 Series Router DrayTek Corp. declares that Vigor2760 Series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE 1999/5/EC, ErP 2009/125/EC and RoHS 2011/65/EU The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
Page 6 L'indice d'équivalence de la sonnerie (IES) sert à indiquer le nombre maximal de dispositifs qui peuvent être raccordés à une interface téléphonique. La terminaison d'une interface peut consister en une combinaison quelconque de dispositifs, à la seule condition que la somme des IES de tous les dispositifs n'excède pas cinq. Vigor2760 Series User’s Guide...
Page 7 More update, please visit www.draytek.com. Vigor2760 Series User’s Guide...
Page 8: Table Of Contents
2.1.3 For WAN3 (USB) ......................50 2.2 Service Activation Wizard...................... 52 2.3 VPN Client Wizard ........................ 55 2.4 VPN Server Wizard ....................... 61 2.5 Wireless Wizard ........................66 2.6 VoIP Wizard........................... 69 2.7 Registering Vigor Router....................... 71 Vigor2760 Series User’s Guide viii...
Page 9 3.7.2 APPE Signature Upgrade ..................... 221 3.7.3 URL Content Filter Profile..................... 222 3.7.4 Web Content Filter Profile..................... 226 3.7.5 DNS Filter Profile ......................230 3.7.6 APPE Support List ......................231 3.8 Bandwidth Management ..................... 232 3.8.1 Sessions Limit....................... 232 Vigor2760 Series User’s Guide...
Page 10 3.14.2 SSL Web Proxy ......................338 3.14.3 SSL Application ......................339 3.14.4 User Account ......................341 3.14.5 User Group ......................... 345 3.14.6 Online User Status...................... 347 3.15 USB Application ........................ 348 3.15.1 USB General Settings....................348 Vigor2760 Series User’s Guide...
Page 11 4.7.1 Create an Account via Vigor Router ................424 4.7.2 Create an Account via MyVigor Web Site ..............428 4.8 How to Setup Address Mapping..................432 4.9 How to Configure Certain Computers Accessing to Internet ..........434 Vigor2760 Series User’s Guide...
Page 12 Telnet Command: csm ucf obj INDEX wf ................471 Telnet Command: csm wcf ....................472 Telnet Command: ddns log....................474 Telnet Command: ddns time....................474 Telnet Command: dos ......................475 Telnet Command: exit......................476 Telnet Command: Internet ..................... 476 Vigor2760 Series User’s Guide...
Page 13 Telnet Command: mngt rmtcfg ....................516 Telnet Command: mngt echoicmp..................517 Telnet Command: mngt accesslist ..................517 Telnet Command: mngt snmp ....................518 Telnet Command: msubnet switch ..................519 Telnet Command: msubnet addr ................... 519 Telnet Command: msubnet nmask..................520 Vigor2760 Series User’s Guide xiii...
Page 14 Telnet Command: srv dhcp expired_RecycleIP ..............552 Telnet Command: srv dhcp tftp....................552 Telnet Command: srv dhcp option..................552 Telnet Command: srv nat dmz....................554 Telnet Command: sys cfg ...................... 558 Telnet Command: sys cmdlog ....................559 Vigor2760 Series User’s Guide...
Page 15 Telnet Command: wan forward....................589 Telnet Command: wan status ....................589 Telnet Command: wan vdsl ....................590 Telnet Command: wan detect....................590 Telnet Command: wan lb....................... 591 Telnet Command: wan mvlan ....................592 Telnet Command: wan multifno ..................... 593 Vigor2760 Series User’s Guide...
Page 16 Telnet Command: wl wmm ....................598 Telnet Command: wl ht......................600 Telnet Command: wl restart....................601 Telnet Command: wl btnctl ....................601 Telnet Command: wl efuse ....................601 Telnet Command: wan vlan ....................602 Telnet Command: wol......................602 Vigor2760 Series User’s Guide...
Page 17: Introduction
Internet telephony / access. Note : This manual is written based on the standard firmware version of Vigor2760 series and suitable for all of the countries except for UK area. For product enquiries in the UK, Ireland and Channel Islands, please contact the UK office.
Page 18: Features
Bonjour Printer Sharing FTP Server for File Sharing by a USB Memory Stick/USB HDD with FAT32 Format System Maintenance Web Syslog HTTP/HTTPS User Interface CLI over Telnet/SSH/Web UI Configuration Backup/Restore Administrator Access Control Restricted User Mode Vigor2760 Series User’s Guide...
Page 19 1.x.x firmware. If your Vigor 2760 has firmware version 3.7.5 or later (‘Delight/DrayOS’ hardware) then you can upgrade to any compatible later firmware. You cannot use Delight/DrayOS firmware on original (classic) Vigor 2760 hardware or vice-versa. This manual applies only to DrayOS/Delight hardware/firmware. Vigor2760 Series User’s Guide...
Page 20: Package And Content
The type of the power adapter depends on the country that the router will be installed. * The maximum power consumption is 17-23 Watt. UK-type Power Adapter EU-type Power Adapter USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter Vigor2760 Series User’s Guide...
Page 21: Led Indicators And Connectors
The DSL port is connected. Blinking The router is ready. DSL (Green) (Slowly) Blinking The connection is training. (Quickly) On (Green) The port is connected. Blinking The data is transmitting. LAN1/2/3/4 (Green) A USB device is connected and active. USB1/2 Vigor2760 Series User’s Guide...
Page 22 Then the router will restart with the factory default configuration. VDSL/ADSL Connector for accessing the Internet. USB (1-2) Connector for USB storage device (Pen Driver/Mobile HD) or printer or 3G backup. LAN (1-4) Connectors for local network devices. Vigor2760 Series User’s Guide...
Page 23: For Vigor2760N
The router is ready. DSL (Green) (Slowly) Blinking The router is trying to connect to Internet. (Quickly) The port is connected. Blinking The data is transmitting. LAN1/2/3/4 (Green) A USB device is connected and active. USB1/2 Vigor2760 Series User’s Guide...
Page 24 WLAN ON/OFF - Press the button once to enable (WLAN LED on) or disable (WLAN LED off) wireless connection. VDSL/ADSL Connector for accessing the Internet. USB (1-2) Connector for USB storage device (Pen Driver/Mobile HD) or printer or 3G backup. LAN (1-4) Connectors for local network devices. Vigor2760 Series User’s Guide...
Page 25: For Vigor2760Vn
The router is ready. DSL (Green) (Slowly) Blinking The router is trying to connect to Internet. (Quickly) The port is connected. Blinking The data is transmitting. LAN1/2/3/4 (Green) A USB device is connected and active. USB1/2 Vigor2760 Series User’s Guide...
Page 26 Connector for USB storage device (Pen Driver/Mobile HD) or printer or 3G backup. LAN (1-4) Connectors for local network devices. Interface Description LINE Connector for PSTN life line. Phone1/Phone2 Connector of analog phone for VoIP communication. Vigor2760 Series User’s Guide...
Page 27: Hardware Installation
Connect Phone port to a conventional analog telephone (for V model only). Connect detachable antennas to the router for Vigor2760 series (for n model only). Connect one end of the power cord to the power port of this device. Connect the other end to the wall outlet of electricity.
Page 28: Printer Installation
You can install a printer onto the router for sharing printing. All the PCs connected this router can print documents via the router. The example provided here is made based on Windows 7. For installation on other Windows systems, please visit www.DrayTek.com. Before using it, please follow the steps below to configure settings for connected computers (or wireless clients).
Page 29 A dialog will appear. Click Add a local printer and click Next. In this dialog, choose Create a new port. In the field of Type of port, use the drop down list to select Standard TCP/IP Port. Then, click Next. Vigor2760 Series User’s Guide...
Page 30 In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Hostname or IP Address and type 192.168.1.1 as the Port name. Then, click Next. Click Standard and choose Generic Network Card. Vigor2760 Series User’s Guide...
Page 31 Now, your system will ask you to choose right name of the printer that you installed onto the router. Such step can make correct driver loaded onto your PC. When you finish the selection, click Next. Type a name for the chosen printer. Click Next. Vigor2760 Series User’s Guide...
Page 32 10. Choose Do not share this printer and click Next. 11. Then, in the following dialog, click Finish. Vigor2760 Series User’s Guide...
Page 33 12. The new printer has been added and displayed under Printers and Faxes. Click the new printer icon and click Printer server properties. 13. Edit the property of the new printer you have added by clicking Configure Port. Vigor2760 Series User’s Guide...
Page 34 14. Select "LPR" on Protocol, type p1 (number 1) as Queue Name. Then click OK. Next please refer to the red rectangle for choosing the correct protocol and LPR name. The printer can be used for printing now. Most of the printers with different manufacturers are compatible with vigor router. Vigor2760 Series User’s Guide...
Page 35 Note 1: Some printers with the fax/scanning or other additional functions are not supported. If you do not know whether your printer is supported or not, please visit www.draytek.com to find out the printer list. Open Support >FAQ/Application Notes; find out the link of USB>>Printer Server and click it.
Page 36: Accessing Web Page
Please type “admin/admin” as the Username/Password and click Login. Notice: If you fail to access to the web configuration, please go to “Trouble Shooting” for detecting and solving your problem. Vigor2760 Series User’s Guide...
Page 37: Changing Password
Open a web browser on your PC and type http://192.168.1.1. A pop-up window will open to ask for username and password. Please type “admin/admin” as Username/Password for accessing into the web user interface with admin mode. Go to System Maintenance page and choose Administrator Password. Vigor2760 Series User’s Guide...
Page 38: Introducing Dashboard
“admin”. Dashboard shows the connection status including System Information, IPv4 Internet Access, IPv6 Internet Access, Interface (physical connection), Security and Quick Access. Click Dashboard from the main menu on the left side of the main page. Vigor2760 Series User’s Guide...
Page 39: Virtual Panel
LED display, refer to 1.2 LED Indicators and Connectors. A name with a link (e.g., Router Name, Current Time, WAN1 and etc.) below means you can click it to open the configuration page for modification. Vigor2760 Series User’s Guide...
Page 40: Quick Access For Common Used Menu
All of the hosts (including wireless clients) displayed with Host ID, IP Address and MAC address indicates that the traffic would be transmitted through LAN port(s) and then the WAN port. The purpose is to perform the traffic monitor of the host(s). Vigor2760 Series User’s Guide...
Page 41: Gui Map
All the functions the router supports are listed with table clearly in this page. Users can click the function link to access into the setting page of the function for detailed configuration. Click the icon on the top of the main screen to display all the functions. Vigor2760 Series User’s Guide...
Page 42: Web Console
The functions/settings modified under Web Console also can be reviewed on the web user interface. Click the Web Console icon on the top of the main screen to open the following screen. Vigor2760 Series User’s Guide...
Page 43: Config Backup
System Maintenance>>Configuration Backup. Simply click the icon on the top of the main screen and a pop up dialog will appear. Click Save to store the setting. Click this icon to exit the web user interface. Vigor2760 Series User’s Guide...
Page 44: Online Status
ADSL information, and so on. Note: If the firmware which supports Vectoring has been installed to your Vigor router, you will see a short message of “with Vectoring support” near to VDLS2 Information. Such feature is available for VDSL2 only. Vigor2760 Series User’s Guide...
Page 45 TX Rate - Displays the speed of transmitted octets at the WAN interface. RX Packets - Displays the total number of received packets at the WAN interface. RX Rate - Displays the speed of received octets at the WAN interface. Vigor2760 Series User’s Guide...
Page 46: Virtual Wan
Internet. Such page displays the virtual WAN connection information. Virtual WAN are used by TR-069 management, VoIP service and so on. The field of Application will list the purpose of such WAN connection. Vigor2760 Series User’s Guide...
Page 47: Saving Configuration
Each time you click OK on the web page for saving the configuration, you can find messages showing the system interaction with you. Ready indicates the system is ready for you to input settings. Settings Saved means your settings are saved once you click Finish or OK button. Vigor2760 Series User’s Guide...
Page 48 This page is left blank. Vigor2760 Series User’s Guide...
Page 49: Quick Setup
VoIP Wizard – used for establishing VoIP profile. Quick Start Wizard can help you to deploy and use the router easily and quickly. The first screen of Quick Start Wizard is entering login password. After typing the password, please click Next. Vigor2760 Series User’s Guide...
Page 50 WAN1; if Ethernet interface is used, please choose WAN2; if 3G USB modem is used, please choose WAN3. Then click Next for next step. WAN1, WAN2, and WAN3 will bring up different configuration page. Refer to the following sections for detailed information. Vigor2760 Series User’s Guide...
Page 51: For Wan1 (Adsl/Vdsl2)
ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE interface. In addition, the field of For ADSL Only will be available only when ADSL is detected. Then click Next for next step. Vigor2760 Series User’s Guide...
Page 52 Type the IP address if Fixed IP is enabled. Primary DNS Type in the primary IP address for the router. Secondary DNS Type in secondary IP address for necessity in the future. Back Click it to return to previous setting page. Vigor2760 Series User’s Guide...
Page 53 Note: The maximum length of the password you can set is 62 characters. Confirm Password Retype the password. Click it to return to previous setting page. Back Next Click it to get into the next setting page. Cancel Click it to give up the quick start wizard. Vigor2760 Series User’s Guide...
Page 54 After finished the above settings, click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 55 VPI and VCI. Or, click Auto detect to find out the best values. Fixed IP Click Yes to enable Fixed IP feature. Type the IP address if Fixed IP is enabled. IP Address Subnet Mask Type the subnet mask. Vigor2760 Series User’s Guide...
Page 56 Then click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 57: For Wan2 (Ethernet)
On the next page as shown below, please select the appropriate Internet access type according to the information from your ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE interface. Then click Next for next step. Vigor2760 Series User’s Guide...
Page 58 Note: The maximum length of the user name you can set is 63 characters. Password Assign a valid password provided by the ISP. Note: The maximum length of the password you can set is 62 characters. Vigor2760 Series User’s Guide...
Page 59 Please manually enter the Username/Password provided by your ISP. Click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 60 Note: The maximum length of the user name you can set is 63 characters. Assign a valid password provided by the ISP. Password Note: The maximum length of the password you can set is 62 characters. Vigor2760 Series User’s Guide...
Page 61 Then click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 62 Type the IP address of gateway. Type in the primary IP address for the router. Primary DNS Secondary DNS Type in secondary IP address for necessity in the future. Back Click it to return to previous setting page. Vigor2760 Series User’s Guide...
Page 63 Please type in the IP address information originally provided by your ISP. Then click Next for next step. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 64 Choose WAN2 as WAN Interface and click the Next button. The following page will be open for you to specify Internet Access Type. Click DHCP as the Internet Access type. Simply click Next to continue. Vigor2760 Series User’s Guide...
Page 65 After finished the settings above, click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 66: For Wan3 (Usb)
Internet. The maximum length of the pin code you can set is 15 characters. Modem Initial String – Such value is used to initialize USB modem. Please use the default value. If you have any Vigor2760 Series User’s Guide...
Page 67 Then, click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2760 Series User’s Guide...
Page 68: Service Activation Wizard
Service Activation Wizard is a tool which allows you to use trial version or update the license of WCF directly without accessing into the server (MyVigor) located on http://myvigor.draytek.com. For using Web Content Filter Profile, please refer to later section Web Content Filter Profile for detailed information.
Page 69 When you finish the selection, please click Next. Commtouch is the web content filter based on Commtouch operated in the worldwide. There is a 30-day trial period. After trial, you can purchase DrayTek's prepared Commtouch GlobalView WCF package from retailing outlets.
Page 70 The valid time for the free trial of these services is one month. When all the trial editions for various web content filters had been enabled, the configuration page of Service Activation Wizard will be invalid as shown below. Vigor2760 Series User’s Guide...
Page 71: Vpn Client Wizard
Route Mode/NAT Mode – If the remote network only allows you to dial in with single IP, please choose this mode, otherwise please choose Route Mode. Please choose a There are 32 VPN profiles for users to set. LAN-to-LAN Profile Vigor2760 Series User’s Guide...
Page 72 In this page, you have to select suitable VPN type for the VPN client profile. There are six types provided here. Different type will lead to different configuration page. After making the choices for the client profile, please click Next. You will see different configurations based on the selection(s) you made. Vigor2760 Series User’s Guide...
Page 73 Note: The following descriptions for VPN Type are based on the Route Mode specified in LAN-to-LAN Client Mode Selection.  When you choose PPTP (None Encryption) or PPTP (Encryption), you will see the following graphic:  When you choose IPsec, you will see the following graphic: Vigor2760 Series User’s Guide...
Page 74 When you choose L2TP over IPsec (Nice to Have) or L2TP over IPsec (Must), you will see the following graphic: Available settings are explained as follows: Item Description Profile Name Type a name for such profile. The length of the file is limited to 10 characters. Vigor2760 Series User’s Guide...
Page 75 3. After finishing the configuration, please click Next. The confirmation page will be shown as follows. If there is no problem, you can click one of the radio buttons listed on the page and click Finish to execute the next action. Vigor2760 Series User’s Guide...
Page 76 Click this radio button to set another profile of VPN Server Server Wizard Setup through VPN Server Wizard. View more detailed Click this radio button to access VPN and Remote configuration Access>>LAN to LAN for viewing detailed configuration. Vigor2760 Series User’s Guide...
Page 77: Vpn Server Wizard
VPN connection. Please choose a This item is available when you choose Site to Site VPN LAN-to-LAN Profile (LAN-to-LAN) as VPN server mode. There are 32 VPN profiles for users to set. Vigor2760 Series User’s Guide...
Page 78 2. After making the choices for the server profile, please click Next. You will see different configurations based on the selection you made. Here we take the examples of choosing Site-to-Site VPN as the VPN Server Mode. Vigor2760 Series User’s Guide...
Page 79 When you check PPTP, you will see the following graphic:  When you check PPTP & IPsec & L2TP (three types) or PPTP & IPsec (two types) or L2TP with Policy (Nice to Have/Must), you will see the following graphic: Vigor2760 Series User’s Guide...
Page 80 Peer IP/VPN Client Type the WAN IP address or VPN client IP address for the remote client. Peer ID Type the ID name for the remote client. The length of the name is limited to 47 characters. Vigor2760 Series User’s Guide...
Page 81 Click this radio button to set another profile of VPN Server Server Wizard Setup through VPN Server Wizard. View more detailed Click this radio button to access VPN and Remote configuration Access>>LAN to LAN for viewing detailed configuration. Vigor2760 Series User’s Guide...
Page 82: Wireless Wizard
Description Name Type the SSID name of this router. The default name is defined with DrayTek. Change the name if required. Mode At present, the router can connect to 11b Only, 11n Only, 11g Only, Mixed (11b+11g), Mixed (11g+11n), and Mixed (11b+11g+11n) stations simultaneously.
Page 83 Type the SSID name of this router. (SSID1) Security Key The wireless mode offered by this wizard is WPA2/PSK. The WPA encrypts each frame transmitted from the radio using the key, which either PSK (Pre-Shared Key) entered Vigor2760 Series User’s Guide...
Page 84 Exit the wireless wizard without saving any changes. 4. After typing the required information, click Next. 5. The following page will display the configuration summary for wireless setting. 6. Click Finish to complete the wireless settings configuration. Vigor2760 Series User’s Guide...
Page 85: Voip Wizard
Password – Type the password for the account registered to your ISP. Use the same Account as phone 1 – If you don’t need to configure Phone 2 settings, simply check this box. Next Click it to get into the next setting page. Vigor2760 Series User’s Guide...
Page 86 Cancel Click it to give up the quick start wizard. 3. After finished the settings above, click Next for viewing summary of such connection. 4. Click Finish. A page of VoIP Wizard Setup OK!!! will appear. Vigor2760 Series User’s Guide...
Page 87: Registering Vigor Router
Please login the web configuration interface of Vigor router by typing “admin/admin” as User Name / Password. Click Support Area>>Production Registration from the home page. A Login page will be shown on the screen. Please type the account and password that you created previously. And click Login. Vigor2760 Series User’s Guide...
Page 88 (it appears when you click on the box of Registration Date). After adding the basic information for the router, please click Submit. When the following page appears, your router information has been added to the database. Now, you have finished the product registration. Vigor2760 Series User’s Guide...
Page 89 From the Device’s Service section, click the Trial. In the following page, check the box of “I have read and accept the above Agreement”. The system will find out the date for you to activate this version of service. Then, click Next. Vigor2760 Series User’s Guide...
Page 90 When this page appears, click Register. Wait for a moment until the following page appears. Click Close. Vigor2760 Series User’s Guide...
Page 91: Advanced Configuration
These are known as private IP addresses, and are listed in the following ranges: From 10.0.0.0 to 10.255.255.255 From 172.16.0.0 to 172.31.255.255 From 192.168.0.0 to 192.168.255.255 Vigor2760 Series User’s Guide...
Page 92 Besides, 3G USB Modem in WAN3 also can be used as backup device. Therefore, when WAN1 and WAN2 are not available, the router will use 3.5G for supporting automatically. The supported 3G USB Modem will be listed on DrayTek web site. Please visit www.draytek.com for more detailed information.
Page 93: General Setup
V means such WAN interface is enabled and ready to be used. Physical Mode / Type Display the physical mode and physical type of such WAN interface. Note: In default, each WAN port is enabled. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 94 Physical Type For such interface, no type can be selected. DSL Modem Code Choose the correct DSL modem code for ensuring the network connection. If you have no idea about the selection, simply choose Vigor2760 Series User’s Guide...
Page 95 Tag value – Type the value as the VLAN ID number. The range is form 0 to 4095. Priority – Type the packet priority number for such VLAN. The range is from 0 to 7. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 96 Disable – Disable the function of VLAN with tag. Tag value – Type the value as the VLAN ID number. The range is form 0 to 4095. Priority – Type the packet priority number for such VLAN. Vigor2760 Series User’s Guide...
Page 97 Choose No to disable the settings for this WAN interface. Display Name Type the description for such WAN interface. Physical Mode Display the physical mode of such WAN interface. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 98: Internet Access
Use the drop down list to choose a proper access mode. The details page of that mode will be popped up. If not, click Details Page for accessing the page to configure the settings. Details Page This button will open different web page (based on IPv4) Vigor2760 Series User’s Guide...
Page 99 WAN>>Interface Access will be overwritten. DataType – Choose the type (ASCII or Hex) for the data to be stored. Data – Type the content of the data to be processed by the function of DHCP option. Vigor2760 Series User’s Guide...
Page 100 WAN detection. Ping IP – If you choose Ping Detect as detection mode, you have to type IP address in this field for pinging. TTL (Time to Live) – Displays value for your reference. Vigor2760 Series User’s Guide...
Page 101 MPoA is a specification that enables ATM services to be integrated with existing LANs, which use either Ethernet, token-ring or TCP/IP protocols. The goal of MPoA is to allow different LANs to send packets to each other via an ATM backbone. Vigor2760 Series User’s Guide...
Page 102 Click Enable RIP for activating this function. If you choose Bridged IP as the protocol, you can check Bridge Mode this box to invoke the function. The router will work as a bridge modem. Vigor2760 Series User’s Guide...
Page 103 DNS Server IP Address Type in the primary IP address for the router. If necessary, type in secondary IP address for necessity in the future. After finishing all the settings here, please click OK to activate them. Vigor2760 Series User’s Guide...
Page 104 It means Max Transmit Unit for packet. The default setting is 1442. PPP Setup PPP Authentication - Select PAP only or PAP or CHAP for PPP. Vigor2760 Series User’s Guide...
Page 105 Specify an IP address – Click this radio button to specify some data.  IP Address – Type the IP address.  Subnet Mask – Type the subnet mask. After finishing all the settings here, please click OK to activate them. Vigor2760 Series User’s Guide...
Page 106 PPPoA) provided by ISP. If you have already used Quick Start Wizard to set the protocol, then it is not necessary for you to change any settings in this group. Modulation –Default setting is Multimode. Choose the one Vigor2760 Series User’s Guide...
Page 107 It means Max Transmit Unit for packet. Path MTU Discovery – It is used to detect the maximum MTU size of a packet not to be segmented in specific transmit path. Click Detect to open the following dialog. Vigor2760 Series User’s Guide...
Page 108 WAN IP Alias - If you have multiple public IP addresses and would like to utilize them on the WAN interface, please use WAN IP Alias. You can set up to 8 public IP addresses other than the current one you are using. Vigor2760 Series User’s Guide...
Page 109 LANs to send packets to each other via an ATM backbone. To use MPoA/Static or Dynamic IP as the accessing protocol of the Internet, select MPoA /Static or Dynamic IP from the WAN>>Internet Access >>WAN1 page. The following web page will appear. Vigor2760 Series User’s Guide...
Page 110 VCI - Type in the value provided by ISP. Modulation –Default setting is Multimode. Choose the one that fits the requirement of your router. WAN Connection Such function allows you to verify whether network connection is alive or not through ARP Detect or Ping Vigor2760 Series User’s Guide...
Page 111 WAN IP Alias. You can set up to 8 public IP addresses other than the current one you are using. Notice that this setting is available for WAN1 only. Type the additional WAN IP address and check the Enable box. Then click OK to exit the dialog. Vigor2760 Series User’s Guide...
Page 112 Type in the primary IP address for the router. If necessary, DNS Server IP Address type in secondary IP address for necessity in the future. After finishing all the settings here, please click OK to activate them. Vigor2760 Series User’s Guide...
Page 113 WAN Connection Such function allows you to verify whether network Detection connection is alive or not through ARP Detect or Ping Detect. Mode – Choose ARP Detect or Ping Detect for the system Vigor2760 Series User’s Guide...
Page 114 Default MAC Address – You can use Default MAC Address or specify another MAC address by typing on the boxes of MAC Address for the router. Specify a MAC Address – Type the MAC address for the Vigor2760 Series User’s Guide...
Page 115 Keep WAN Connection Normally, this function is designed for Dynamic IP environments because some ISPs will drop connections if there is no traffic within certain periods of time. Check Vigor2760 Series User’s Guide...
Page 116 WAN IP Alias. You can set up to 8 public IP addresses other than the current one you are using. Obtain an IP address automatically – Click this button to obtain the IP address automatically if you want to use Vigor2760 Series User’s Guide...
Page 117 Type in the primary IP address for the router if you want to use Static IP mode. If necessary, type in secondary IP address for necessity in the future. After finishing all the settings here, please click OK to activate them. Vigor2760 Series User’s Guide...
Page 118 It means Max Transmit Unit for packet. The default setting is 1460. PPP Setup PPP Authentication - Select PAP only or PAP or CHAP Vigor2760 Series User’s Guide...
Page 119 Specify an IP address – Click this radio button to specify some data.  IP Address – Type the IP address.  Subnet Mask – Type the subnet mask. After finishing all the settings here, please click OK to activate them. Vigor2760 Series User’s Guide...
Page 120 SIM PIN code Type PIN code of the SIM card that will be used to access Internet. The maximum length of the PIN code you can set is 15 characters. Vigor2760 Series User’s Guide...
Page 121 PING operation. Ping Retry – Type the number of times that the system is allowed to execute the PING operation before WAN disconnection is judged. After finishing all the settings here, please click OK to activate them. Vigor2760 Series User’s Guide...
Page 122 The maximum length of the PIN code you can set is 19 characters. Network Mode Force Vigor router to connect Internet with the mode specified here. If you choose 4G/3G/2G as network mode, the router will choose a suitable one according to the actual Vigor2760 Series User’s Guide...
Page 123 Ping Interval – Type the interval for the system to execute the PING operation.  Ping Retry – Type the number of times that the system is allowed to execute the PING operation before WAN disconnection is judged. Vigor2760 Series User’s Guide...
Page 124 WAN detection. Always On means no detection will be executed. The network connection will be on always.  Ping IP/Hostname – If you choose Ping Detect as detection mode, you have to type IP address in this field for pinging. Vigor2760 Series User’s Guide...
Page 125 After getting the IPv6 prefix and starting router advertisement daemon (RADVD), the PC behind this router can directly connect to IPv6 the Internet. Vigor2760 Series User’s Guide...
Page 126 IP address in this field for pinging.  TTL (Time to Live) –If you choose Ping Detect as detection mode, you have to type TTL value. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 127 Such function allows you to verify whether network Detection connection is alive or not through Ping Detect. Mode – Choose Always On or Ping Detect for the system to execute for WAN detection.  Ping IP/Hostname – If you choose Ping Detect as Vigor2760 Series User’s Guide...
Page 128 Ping IP/Hostname – If you choose Ping Detect as detection mode, you have to type IP address in this field for pinging.  TTL (Time to Live) –If you choose Ping Detect as detection mode, you have to type TTL value. Vigor2760 Series User’s Guide...
Page 129 Enable Bridge Mode - If the function is enabled, the router will work as a bridge modem. Bridge Subnet – Make a bridge between the selected LAN subnet and such WAN interface. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 130 Add – Click it to add a new entry. Delete – Click it to remove an existed entry. Current IPv6 Address Display current interface IPv6 address. Table Static IPv6 Gateway IPv6 Gateway Address - Type your IPv6 gateway address Configuration here. Vigor2760 Series User’s Guide...
Page 131 Enable Bridge Mode - If the function is enabled, the router will work as a bridge modem. Bridge Subnet – Make a bridge between the selected LAN subnet and such WAN interface. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 132 Type the static IPv6 address for LAN routing with the value LAN Routed Prefix for prefix length. Tunnel TTL Type the number for the data lifetime in tunnel. After finished the above settings, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 133 Auto 6rd – Retrieve 6rd prefix automatically from 6rd service provider. The IPv4 WAN must be set as "DHCP". Static 6rd - Set 6rd options manually. IPv4 Border Relay Type the IPv4 addresses of the 6rd Border Relay for a given 6rd domain. Vigor2760 Series User’s Guide...
Page 134 TTL (Time to Live) –If you choose Ping Detect as detection mode, you have to type TTL value. After finished the above settings, click OK to save the settings. Below shows an example for successful IPv6 connection based on 6rd mode. Vigor2760 Series User’s Guide...
Page 135: Multi-Pvc/Vlan
WAN type may not configure the same VLAN tag value. Enable - Check this box to enable the port-based bridge function on this channel. P1 ~ P4 – Check the box(es) to build bridge connection on LAN. Vigor2760 Series User’s Guide...
Page 136 VLAN Tags. Channels using the same WAN type may not configure the same VLAN tag value. Priority – Choose the number to determine the packet Vigor2760 Series User’s Guide...
Page 137 WAN links for Channel 4, 5 and 6 are provided for router-borne application such as TR-069. The settings must be applied and obtained from your ISP. For your special request, please contact with your ISP and then click WAN link of Channel 4, 5 and 6 to configure your router. Vigor2760 Series User’s Guide...
Page 138 Multi-VLAN Channel Enable – Click it to enable the configuration of this 4/5/6 channel. Disable –Click it to disable the configuration of this channel. General Settings VPI - Type in the value provided by your ISP. Vigor2760 Series User’s Guide...
Page 139 Password – Type in the password provided by ISP in this field. The maximum length of the password you can set is 48 characters. PPP Authentication – Select PAP only or PAP or CHAP for PPP. Always On – Check it to keep the network connection Vigor2760 Series User’s Guide...
Page 140 Such configuration is applied to upstream packets. Such information will be provided by ISP. Please contact with your ISP for detailed information. Note that such web page is available only when ADSL is selected as WAN type. Vigor2760 Series User’s Guide...
Page 141: Lan
IP address to private IP address to forward the right packets to the right host and vice versa. Besides, Vigor router has a built-in DHCP server that assigns private IP address to each local host. See the following diagram for a briefly understanding. Vigor2760 Series User’s Guide...
Page 142 When you have several subnets in your LAN, sometimes a more effective and quicker way for connection is the Static routes function rather than other method. You may simply set rules to Vigor2760 Series User’s Guide...
Page 143 You can group local hosts by physical ports and create up to 8 virtual LANs. To manage the communication between different groups, please set up rules in Virtual LAN (VLAN) function and the rate of each. Vigor2760 Series User’s Guide...
Page 144: General Setup
LAN must be configured in different subnet. IPv6 – Click it to access into the settings page of IPv6. Advanced DHCP packets can be processed by adding option number and data information when such function is enabled. Vigor2760 Series User’s Guide...
Page 145 Internet Access server (PPPoE, PPTP, L2TP or DHCP server). Inter-LAN Routing Check the box to link two or more different subnets (LAN and LAN). When you finish the configuration, please click OK to save and exit this page. Vigor2760 Series User’s Guide...
Page 146 LAN. Disable Server – Let you manually assign IP address to every host in the LAN. Enable Relay Agent –Specify which subnet that DHCP server is located the relay agent should redirect the DHCP Vigor2760 Series User’s Guide...
Page 147 DNS Server. If your ISP does not provide it, the router will automatically apply default secondary DNS Server IP address: 194.98.0.1 to this field. The default DNS Server IP address can be found via Online Status: Vigor2760 Series User’s Guide...
Page 148 There are two configuration pages for LAN1, Ethernet TCP/IP and DHCP Setup (based on IPv4) and IPv6 Setup. Click the tab for each type and refer to the following explanations for detailed information. Below shows the settings page for IPv6. Vigor2760 Series User’s Guide...
Page 149 Add – Click it to add a new entry. Delete – Click it to remove an existed entry. Such feature is used for the host without assigned IPv6 Unique Local Address (ULA) configuration address to obtain IPv6 address automatically or have an Vigor2760 Series User’s Guide...
Page 150 IPv6 range automatically. Start IPv6 Address / End IPv6 Address –Type the start and end address for IPv6 server. Advance setting More options are offered under the Advance setting. Click Edit to open the pop-up window. Vigor2760 Series User’s Guide...
Page 151 Extension WAN – Not only the IP address can be obtained from the primary WAN, but also the prefix for IPv6 LAN IP address can be assigned by extension WAN specified here. When you finish the configuration, please click OK to save and exit this page. Vigor2760 Series User’s Guide...
Page 152 Vigor Router’s, you can let Relay Agent help you to redirect the DHCP request to the specified location. DHCP Server IP Address – It is available when Enable Relay Agent is checked. Set the IP address of the DHCP Vigor2760 Series User’s Guide...
Page 153 DNS Server IP address: 194.98.0.1 to this field. The default DNS Server IP address can be found via Online Status: If both the Primary IP and Secondary IP Address fields are Vigor2760 Series User’s Guide...
Page 154 DHCP stands for Dynamic Host Configuration Protocol. The router by factory default acts a DHCP server for your Configuration network so it automatically dispatch related IP settings to any local user configured as a DHCP client. It is highly Vigor2760 Series User’s Guide...
Page 155 Edit – Click it to edit the selected MAC address. Cancel – Click it to cancel the job of adding, deleting and editing. When you finish the configuration, please click OK to save and exit this page. Vigor2760 Series User’s Guide...
Page 156: Static Route
Displays the destination address of the static route. Status Displays the status of the static route. Set to Factory Default Clear all of the settings and return to factory default settings. Displays the routing table for your reference. Viewing Routing Table Vigor2760 Series User’s Guide...
Page 157 1st subnet (192.168.1.0/24). The second is that those hosts on the internal private subnets (ex. 192.168.10.0/24) can access the Internet via the router, and continuously exchange of IP routing information with different subnets. Vigor2760 Series User’s Guide...
Page 158 Use the drop down list to specify an interface for such static route. Return to Static Route Setup page. Click on another Index Number to add another static route as show below, which regulates all packets destined to 211.100.88.0 will be forwarded to 192.168.1.3. Click OK. Vigor2760 Series User’s Guide...
Page 159 Set to Factory Default Clear all of the settings and return to factory default settings. Viewing IPv6 Routing Displays the routing table for your reference. Table Click any underline of index number to get the following page. Vigor2760 Series User’s Guide...
Page 160 Type the gateway address for this entry. Network Interface Use the drop down list to specify an interface for this static route. When you finish the configuration, please click OK to save and exit this page. Vigor2760 Series User’s Guide...
Page 161: Vlan
Choose one of them to make the selected VLAN mapping to the specified subnet only. For example, LAN1 is specified for VLAN0. It means that PCs grouped under VLAN0 can get the IP address(es) that specified by the subnet. Vigor2760 Series User’s Guide...
Page 162 Note: Leave one VLAN untagged at least to prevent from not connecting to Vigor router due to unexpected error. Vigor2760 series features a hugely flexible VLAN system. In its simplest form, each of the Gigabit LAN ports can be isolated from each other, for example to feed different companies or departments but keeping their local traffic completely separated.
Page 163 Vigor router supports up to six private IP subnets on LAN. Each can be independent (isolated) or common (able to communicate with each other). This is ideal for departmental or multi-occupancy applications. Vigor2760 Series User’s Guide...
Page 164: Bind Ip To Mac
Each pair of IP and MAC address listed in ARP table can be selected and added to IP Bind List by clicking Add below Click this link to select all the items in the ARP table. Select All Sort Reorder the table based on the IP address. Vigor2760 Series User’s Guide...
Page 165 Note: Before you select Strict Bind, you have to bind one set of IP/MAC address for one PC. If not, no one of the PCs can access into Internet. And the web user interface of the router might not be accessed. When you finish the configuration, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 166: Lan Port Mirror
Mirror Port Select a port to view traffic sent from mirrored ports. Mirrored Port Select which ports are necessary to be mirrored. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 167: Web Portal Setup
Display the content (Disable, URL Redirect or Message) of the profile. Interface Display the applied interfaced of the profile. Preview Open a preview window according to the configured settings. To configure the profile, click any index number link to open the following page. Vigor2760 Series User’s Guide...
Page 168: Route Policy
Route Policy (Cisco called it "policy-based routing") is a feature where a set of rules or "policies" are defined first. Then, if there comes a packet that matches any one of the "policies", it will be directed to the specified interface. Vigor2760 Series User’s Guide...
Page 169 Allows to configure detailed settings of route policy. Advance Mode To use Wizard Mode, simple do the following steps: 1. Click the Wizard Mode radio button. 2. Click Index 1. The setting page will appear as follows: Vigor2760 Series User’s Guide...
Page 170 Available settings are explained as follows: Item Description Interface Use the drop down list to choose a WAN or LAN interface or VPN profile. Packets match with the above criteria will be transferred to the interface chosen here. Vigor2760 Series User’s Guide...
Page 171 It determines which mechanism that the router will use to Routing forward the packet to WAN. 5. After choosing the mechanism, click Next to get the summary page for reference. 6. If there is no error, click Finish to complete wizard setting. Vigor2760 Series User’s Guide...
Page 172 Vigor2760 Series User’s Guide...
Page 173 Any – Any IP can be treated as the source IP. Src IP Range – Define a range of IP address as source IP addresses.  Start - Type an address as the starting IP for such Vigor2760 Series User’s Guide...
Page 174 Failover to – Check this button to lead the data passing through specific interface (WAN/LAN/VPN/Route Policy) automatically when the selected interface (defined in Send via if criteria matched) is down.  WAN/LAN – Use the drop down list to choose an Vigor2760 Series User’s Guide...
Page 175: Diagnose
When you finish the configuration, please click OK to save and exit this page. With the analysis done by such page, possible path (static route, routing table or policy route) of the packets sent out of the router can be traced. Vigor2760 Series User’s Guide...
Page 176 Analyze – Click it to perform the job of analyzing. The analyzed result will be shown on the page. If required, click export analysis to export the result as a file. Vigor2760 Series User’s Guide...
Page 177 Note that the analysis was based on the current "load-balance/route policy" settings, we do not guarantee it will be 100% the same as the real case. Vigor2760 Series User’s Guide...
Page 178: Nat
IP address/port, the goal of Port Redirection function is to forward all access request with public IP address from external users to the mapping private IP address/port of the server. Vigor2760 Series User’s Guide...
Page 179 Each item is explained as follows: Item Description Display the number of the profile. Index Service Name Display the description of the specific network service. WAN Interface Display the WAN IP address used by the profile. Vigor2760 Series User’s Guide...
Page 180 Private IP and Port of the internal host. If you choose Range as the port redirection mode, you will see two boxes on this field. Simply type the required number on the first box. The second one will be assigned automatically later. Vigor2760 Series User’s Guide...
Page 181 80 to avoid conflict, such as 8080. This can be set in the System Maintenance >>Management Setup. You then will access the admin screen of by suffixing the IP address with 8080, e.g., http://192.168.1.1:8080 instead of port 80. Vigor2760 Series User’s Guide...
Page 182: Dmz Host
Click DMZ Host to open the following page. You can set different DMZ host for each WAN interface. Click the WAN tab to switch into the configuration page for that WAN. Vigor2760 Series User’s Guide...
Page 183 IP address will be shown on the following screen. Click OK to save the setting. DMZ Host for WAN2, or WAN3 is slightly different with WAN1. Active True IP selection is available for WAN1 only. See the following figure. Vigor2760 Series User’s Guide...
Page 184 When you have selected one private IP from the above dialog, the IP address will be shown on the screen. Click OK to save the setting. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 185: Open Ports
Local IP Address Display the private IP address of the local host offering the service. Status Display the state for the corresponding entry. X or V is to represent the Inactive or Active state. Vigor2760 Series User’s Guide...
Page 186 Specify the transport layer protocol. It could be TCP, UDP, or ----- (none) for selection. Start Port Specify the starting port number of the service offered by the local host. End Port Specify the ending port number of the service offered by the local host. Vigor2760 Series User’s Guide...
Page 187: Port Triggering
The duration that these ports are opened depends on the type of protocol used. The "default" durations are shown below and these duration values can be modified via telnet commands. TCP: 86400 sec. UDP: 180 sec. IGMP: 10 sec. TCP WWW: 60 sec. TCP SYN: 60 sec. Vigor2760 Series User’s Guide...
Page 188 Available settings are explained as follows: Item Description Enable Check to enable this entry. Choose the predefined service to apply for such trigger Service profile. Comment Type the text to memorize the application of this rule. Vigor2760 Series User’s Guide...
Page 189 (TCP, UDP or TCP/UDP) for the incoming data of such triggering profile. Incoming Port Type the port or port range for the incoming packets. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 190: Firewall
It will check packets according to the filter rules. If legal, the packet will pass the router. The following illustrations are flow charts explaining how router will treat incoming traffic and outgoing traffic respectively. Vigor2760 Series User’s Guide...
Page 191 4. Port Scan attack 12. Tear drop attack 5. IP options 13. Ping of Death attack 6. Land attack 14. ICMP fragment 7. Smurf attack 15. Unassigned Numbers 8. Trace route Below shows the menu items for Firewall. Vigor2760 Series User’s Guide...
Page 192: General Setup
Check Enable to activate the Call Filter function. Assign a Call Filter start filter set for the Call Filter. Data Filter Check Enable to activate the Data Filter function. Assign a start filter set for the Data Filter. Vigor2760 Series User’s Guide...
Page 193 NAT. IPv4 - Check the box to make the incoming packets via IPv4 being accepted by such router. It is effective only for the packets routed but not for packets translated by NAT. Vigor2760 Series User’s Guide...
Page 194 For detailed information of setting QoS, please refer to the related section later. APP Enforcement Select an APP Enforcement profile for global IM/P2P application blocking. If there is no profile for you to select, please choose [Create New] from the drop down list in this Vigor2760 Series User’s Guide...
Page 195 I. If you do not choose any codepage, no decoding job of URL will be processed. Please use the drop-down list to choose a codepage. If you do not have any idea of choosing suitable codepage, Vigor2760 Series User’s Guide...
Page 196 However, if the network is not stable, small value will be proper. Session timeout – Setting timeout for sessions can make the best utilization of network resources. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 197: Filter Setup
Use Up or Down link to move the order of the filter rules. Next Filter Set Set the link to the next filter set to be executed after the current filter run. Do not make a loop with many filter sets. Vigor2760 Series User’s Guide...
Page 198 Set the direction of packet flow. It is for Data Filter only. For the Call Filter, this setting is not available since Call Filter is only applied to outgoing traffic. Note: RT means routing domain for 2nd subnet or other Vigor2760 Series User’s Guide...
Page 199 Service Type Click Edit to access into the following dialog to choose a suitable service type. To set the service type manually, please choose User defined as the Service Type and type them in this dialog. In Vigor2760 Series User’s Guide...
Page 200 Sessions Control The number typed here is the total sessions of the packets that do not match the filter rule configured in this page. The Vigor2760 Series User’s Guide...
Page 201 Or click the DNS Filter link from the drop down list in this page to create a new profile. Advance Setting Click Edit to open the following window. However, it is strongly recommended to use the default settings here. Vigor2760 Series User’s Guide...
Page 202 TCP protocol only; session timeout is configured for the data flow which matched with the firewall rule. DrayTek Banner – Please uncheck this box and the following screen will not be shown for the unreachable web page. The default setting is Enabled.
Page 203 Vigor router. When the resource is inadequate, the packets will be blocked if Strict Security Checking is enabled. If Strict Security Checking is not enabled, then the packets will pass through the router. Vigor2760 Series User’s Guide...
Page 204 Each filter set is composed by 7 filter rules, which can be further defined. After that, in General Setup you may specify one set for call filter and one set for data filter to execute first. Vigor2760 Series User’s Guide...
Page 205: Dos Defense
Once detecting the Threshold of the UDP packets from the Internet has exceeded the defined value, the Vigor router will start to randomly discard the subsequent UDP packets for a period defined in Timeout. The default setting for threshold and timeout are 2000 Vigor2760 Series User’s Guide...
Page 206 The Vigor router will drop any packets having SYN flag and more fragment bit set. Block Fraggle Attack Check the box to activate the Block fraggle Attack function. Any broadcast UDP packets received from the Internet is blocked. Activating the DoS/DDoS defense functionality might Vigor2760 Series User’s Guide...
Page 207 All the warning messages related to DoS Defense will be sent to user and user can review it through Syslog daemon. Look for the keyword DoS in the message, followed by a name to indicate what kind of attacks is detected. Vigor2760 Series User’s Guide...
Page 208 Vigor2760 Series User’s Guide...
Page 209: Objects Settings
Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Name Display the name of the object profile. To set a new profile, please do the steps listed below: Vigor2760 Series User’s Guide...
Page 210 Select Range Address if this object contains several IPs within a range. Select Subnet Address if this object contains one subnet for IP address. Select Any Address if this object contains any IP address. Select Mac Address if this object contains Mac address. Vigor2760 Series User’s Guide...
Page 211 If it is checked, all the IP addresses except the ones listed above will be applied later while it is chosen. After finishing all the settings here, please click OK to save the configuration. Below is an example of IP objects settings. Vigor2760 Series User’s Guide...
Page 212: Ip Group
Display the name of the group profile. To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Vigor2760 Series User’s Guide...
Page 213 Selected IP Objects Click >> button to add the selected IP objects in this box. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 214: Ipv6 Object
Display the name of the object profile. To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Vigor2760 Series User’s Guide...
Page 215 Invert Selection If it is checked, all the IPv6 addresses except the ones listed above will be applied later while it is chosen. After finishing all the settings, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 216: Ipv6 Group
To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Available settings are explained as follows: Vigor2760 Series User’s Guide...
Page 217: Service Type Object
You can set up to 96 sets of Service Type Objects with different conditions. Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Name Display the name of the object profile. Vigor2760 Series User’s Guide...
Page 218 (>) – the port number greater than this value is available. (<) – the port number less than this value is available for this profile. Vigor2760 Series User’s Guide...
Page 219: Service Type Group
This page allows you to bind several service types into one group. Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Display the name of the group profile. Name Vigor2760 Series User’s Guide...
Page 220 Objects Setting>>Service Type Object will be shown in this box. Selected Service Type Click >> button to add the selected IP objects in this box. Objects After finishing all the settings, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 221: Keyword Object
Web Content Filter Profile. Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Display the profile number that you can configure. Index Name Display the name of the object profile. Vigor2760 Series User’s Guide...
Page 222 Contents. When you browse the webpage, the page with gambling information will be watched out and be passed/blocked based on the configuration on Firewall settings. After finishing all the settings, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 223: Keyword Group
Display the name of the group profile. To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Vigor2760 Series User’s Guide...
Page 224: File Extension Object
Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Name Display the name of the object profile. Vigor2760 Series User’s Guide...
Page 225 Type a name for this profile. The maximum length of the name you can set is 7 characters. Type a name for such profile and check all the items of file extension that will be processed in the router. Finally, click OK to save this profile. Vigor2760 Series User’s Guide...
Page 226 Display the service provider which offers SMS service. To set a new profile, please do the steps listed below: 1. Click the SMS Provider tab, and click the number (e.g., #1) under Index column for configuration in details. Vigor2760 Series User’s Guide...
Page 227 Note that one credit equals to one SMS text message on the standard route. Sending Interval To avoid quota being exhausted soon, type time interval for sending the SMS. 3. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 228 Display the name of this profile. It cannot be modified. Service Provider Type the website of the service provider. Type the URL string in the box under the filed of Service Provider. You have to contact your SMS provider to obtain the exact URL string. Vigor2760 Series User’s Guide...
Page 229: Sms/Mail Service Object
Each item is explained as follows: Item Description Set to Factory Default Clear all of the settings and return to factory default settings. Index Display the profile number that you can configure. Profile Display the name for such mail server profile. Vigor2760 Series User’s Guide...
Page 230 Username – Type a name for authentication. The maximum length of the name you can set is 31 characters. Password – Type a password for authentication. The maximum length of the password you can set is 31 Vigor2760 Series User’s Guide...
Page 231: Notification Object
You can set an object with different monitoring situation. To set a new profile, please do the steps listed below: 1. Open Object Setting>>Notification Object, and click the number (e.g., #1) under Index column for configuration in details. Vigor2760 Series User’s Guide...
Page 232 Display the types that will be monitored. Category Status Display the status for the category. You can check the box you want to be monitored. 3. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 233: Csm Profile
Please note that this action will not introduce any delay in your Web surfing because each of multiple load balanced database servers can handle millions of requests for categorization. Note: The priority of URL Content Filter is higher than Web Content Filter. Vigor2760 Series User’s Guide...
Page 234: App Enforcement Profile
Click the number under Index column for settings in detail. There are four tabs IM, P2P, Protocol and Misc displayed on this page. Each tab will bring out different items that you can choose to disallow people using. Vigor2760 Series User’s Guide...
Page 235 Uncheck all the selected boxes. The profiles configured here can be applied in the Firewall>>General Setup and Firewall>>Filter Setup pages as the standard for the host(s) to follow. Below shows the items which are categorized under IM. Vigor2760 Series User’s Guide...
Page 236 The items categorized under P2P ----- The items categorized under OTHERS----- Vigor2760 Series User’s Guide...
Page 237: Appe Signature Upgrade
The APPE Enforcement Profile adopted by Vigor router will be treated as the APPE signature. DrayTek will periodically upgrade versions for all of the APPs supported by Vigor router. However, it might be inconvenient for users to upgrade the APP version one by one. This feature is specially designed to offer a quick method to execute APP version upgrade.
Page 238: Url Content Filter Profile
URL such as “www.sex.com” or “sex.com”. Also the Vigor router will discard any request that tries to retrieve the malicious code. Click CSM and click URL Content Filter Profile to open the profile setting page. Vigor2760 Series User’s Guide...
Page 239 Administration Message. You can set eight profiles as URL content filter. Simply click the index number under Profile to open the following web page. Available settings are explained as follows: Vigor2760 Series User’s Guide...
Page 240 Access Control is higher than Restrict Web Feature. If the web content match the setting set in URL Access Control, the router will execute the action specified in this field and ignore the action specified under Restrict Web Feature. Vigor2760 Series User’s Guide...
Page 241 Vigor router performs. Web Feature Enable Restrict Web Feature - Check this box to make the keyword being blocked or passed. Action - This setting is available only when Either: URL Vigor2760 Series User’s Guide...
Page 242: Web Content Filter Profile
Note: If you have used Service Activation Wizard to activate WCF service, you can skip this section. WCF adopts the mechanism developed and offered by certain service provider (e.g., DrayTek). No matter activating WCF feature or getting a new license for web content filter, you have to click Activate to satisfy your request.
Page 243 Setup Test Server It is recommended for you to use the default setting, auto-selected. Find more Click it to open http://myvigor.draytek.com for searching another qualified and suitable server. Test a site to verify Click this link to do the verification.
Page 244 If you have and activate another web content filter license, the items will be changed simultaneously. All of the configuration made for web content filter will be deleted automatically. Therefore, please backup your data before you change the web content filter license. Vigor2760 Series User’s Guide...
Page 245 Block – Only the log about Block will be recorded in Syslog. All – All the actions (Pass and Block) will be recorded in Syslog. After finishing all the settings, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 246: Dns Filter Profile
Click the profile link to open the following page. Then, type the name of the profile and specify WCF/UCF based on your requirement. DNS Filter Local Setting will be applied to DNS query DNS Filter Local Setting Vigor2760 Series User’s Guide...
Page 247: Appe Support List
After finishing all the settings, please click OK to save the configuration. Such page lists all the information (name, version and note) about IM, P2P, Protocol and others applications that Vigor router supports for APPE function. Vigor2760 Series User’s Guide...
Page 248: Bandwidth Management
To activate the function of limit session, simply click Enable and set the default session limit. Available settings are explained as follows: Item Description Session Limit Enable - Click this button to activate the function of limit session. Vigor2760 Series User’s Guide...
Page 249 All the schedules can be set previously in Application >> Schedule web page and you can use the number that you have set in that web page. After finishing all the settings, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 250: Bandwidth Limit
Disable - Click this button to close the function of limit bandwidth. Default TX limit - Define the default speed of the upstream for each computer in LAN. Default RX limit - Define the default speed of the Vigor2760 Series User’s Guide...
Page 251 Index (1-15) in Schedule Setup - You can type in four sets of time schedule for your request. All the schedules can be set previously in Application >> Schedule web page and you can use the number that you have set in that web page. Vigor2760 Series User’s Guide...
Page 252: Quality Of Service
The core routers in the backbone will do the same checking before executing treatments in order to ensure service-level consistency throughout the whole QoS-enabled network. Vigor2760 Series User’s Guide...
Page 253 Rule – Allow to configure detailed settings for the selected Class. Service Type – Allow to configure detailed settings for the service type. Enable the First Priority When this feature is enabled, the VoIP SIP/UDP packets will Vigor2760 Series User’s Guide...
Page 254 There are four queues allowed for QoS control. The first three (Class 1 to Class 3) class rules can be adjusted for your necessity. Yet, the last one is reserved for the packets which are not suitable for the user-defined class rules. Vigor2760 Series User’s Guide...
Page 255 Enable UDP Bandwidth Check this and set the limited bandwidth ratio on the right Control field. This is a protection of TCP application traffic since UDP application traffic such as streaming video will exhaust lots of bandwidth. Vigor2760 Series User’s Guide...
Page 256 Edit link of that one. After you click the Edit link, you will see the following page. Now you can define the name for that Class. In this case, “Test” is used as the name of Class Index #1. Vigor2760 Series User’s Guide...
Page 257 QoS control. It can also be edited. You can choose the predefined service type from the Service Type drop down list. Those types are predefined in factory. Simply choose the one that you want for using by current QoS. Vigor2760 Series User’s Guide...
Page 258 Edit to open the rule edit page for modification. To add a new service type, edit or delete an existed service type, please click the Edit link under Service Type field. After you click the Edit link, you will see the following page. Vigor2760 Series User’s Guide...
Page 259 After finishing all the settings here, please click OK to save the configuration. By the way, you can set up to 10 service types. If you want to edit/delete an existed service type, please select the radio button of that one and click Edit/Edit for modification. Vigor2760 Series User’s Guide...
Page 260 For example, in the following illustration, the VoIP packets in LAN go into Vigor router without any header. However, when they go forward to the Server on ISP through Vigor router, all of the packets are tagged with AF (configured in Bandwidth >>QoS>>Class) automatically. Vigor2760 Series User’s Guide...
Page 261: App Qos
The protocol listed below is traceable by Vigor router. Each tab offers different types of protocols to fit your request. Untraceable The protocol listed below is not easy to trace by Vigor router. Each tab offers different types of protocols to fit your request. Vigor2760 Series User’s Guide...
Page 262 Apply – Click it to make the selected action be applied all of the selected protocols immediately. Action There are many protocols which can be specified with different QoS Class. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 263: Applications
Enable the Function and Add a Dynamic DNS Account Assume you have a registered domain name from the DDNS provider, say hostname.dyndns.org, and an account with username: test and password: test. In the DDNS setup menu, check Enable Dynamic DNS Setup. Vigor2760 Series User’s Guide...
Page 264 Service Provider Select the service provider for the DDNS account. Service Type Select a service type (Dynamic, Custom or Static). If you choose Custom, you can modify the domain that is chosen in the Domain Name field. Vigor2760 Series User’s Guide...
Page 265 Delete a Dynamic DNS Account In the DDNS setup menu, click the Index number you want to delete and then push Clear All button to delete the account. Vigor2760 Series User’s Guide...
Page 266: Lan Dns / Dns Forwarding
Simply click Application>>LAN DNS to open the following page. Each item is explained as follows: Item Description Set to Factory Default Clear all profiles and recover to factory settings. Enable Check the box to enable the selected profile. Vigor2760 Series User’s Guide...
Page 267 In general, one domain name maps with one IP address. If required, you can configure two IP addresses mapping with the same domain name. Add – Click it to open a dialog to type the host’s IP address. Vigor2760 Series User’s Guide...
Page 268 Type the domain name for such profile. DNS Server IP Type the IP address of the DNS server you want to use for Address DNS forwarding. Click OK button to save the settings. A new LAN DNS profile has been created. Vigor2760 Series User’s Guide...
Page 269: Schedule
You can set up to 15 schedules. Then you can apply them to your Internet Access or VPN and Remote Access >> LAN-to-LAN settings. To add a schedule: Click any index, say Index No. 1. The detailed settings of the call schedule with index 1 are shown below. Vigor2760 Series User’s Guide...
Page 270 How often -Specify how often the schedule will be applied Once -The schedule will be applied just once Weekdays -Specify which days in one week should perform the schedule. Click OK button to save the settings. Vigor2760 Series User’s Guide...
Page 271 Assign these two profiles to the PPPoE Internet access profile. Now, the PPPoE Internet connection will follow the schedule order to perform Force On or Force Down action according to the time plan that has been pre-defined in the schedule profiles. Vigor2760 Series User’s Guide...
Page 272: Radius
The maximum length of the shared secret you can set is 36 characters. Confirm Shared Secret Re-type the Shared Secret for confirmation. After finished the above settings, click OK button to save the settings. Vigor2760 Series User’s Guide...
Page 273: Active Directory/Ldap
Anonymous – Perform a search action first with Anonymous account then do the bind authentication.  Regular Mode– Mostly it is the same with anonymous mode. The different is that, the server will firstly check if you have the search authority. Vigor2760 Series User’s Guide...
Page 274 After finished the above settings, click OK button to save the settings. You can configure eight AD/LDAP profiles. These profiles would be used with User Management for different purposes in management. Click any index number link to open the following page. Vigor2760 Series User’s Guide...
Page 275: Upnp
DMZ. UPnP is available on Windows XP and the router provide the associated support for MSN Messenger to allow full use of the voice, video and messaging features. Vigor2760 Series User’s Guide...
Page 276 Non-privileged users can control some router functions, including removing and adding port mappings. The UPnP function dynamically adds port mappings on behalf of some UPnP-aware applications. When the applications terminate abnormally, these mappings may not be removed. Vigor2760 Series User’s Guide...
Page 277: Igmp
This field displays the ID port for the multicast group. The available range for IGMP starts from 224.0.0.0 to 239.255.255.254. P1 to P4 It indicates the LAN port used for the multicast group. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 278: Wake On Lan
MAC Address Type any one of the MAC address of the bound PCs. Wake Up Click this button to wake up the selected IP. See the following figure. The result will be shown on the box. Vigor2760 Series User’s Guide...
Page 279: Sms / Mail Alert Service
SMS. Schedule Type the schedule number that the SMS will be sent out. You can click the Schedule(1-15) link to define the schedule. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 280 Schedule Type the schedule number that the notification will be sent out. You can click the Schedule(1-15) link to define the schedule. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 281: Bonjour
Below shows an example for applying the bonjour feature that Vigor router can be used as the FTP server. 1. Here, we use Firefox and DNSSD to discover the service in such case. Therefore, just ensure the Bonjour client program and DNSSD for Firefox have been installed on the computer. Vigor2760 Series User’s Guide...
Page 282 (DNSSD) and see the following results. 3. Open System Maintenance>>Management. Type a name (e.g., Dray_2925) as the Router Name and click OK. 4. Next, open Applications>>Bonjour. Check the service that you want to use via Bonjour. Vigor2760 Series User’s Guide...
Page 283 Vigor router (based on Bonjour protocol) is ready to be used as a printer server, FTP server, SSH Server, Telnet Server, and HTTP Server. 6. Now, any page or document can be printed out through Vigor router (installed with a printer). Vigor2760 Series User’s Guide...
Page 284: Vpn And Remote Access
LAN, you should disable the VPN service of Vigor Router to allow VPN tunnel pass through, as well as the appropriate NAT settings, such as DMZ or open port. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 285: Ppp General Setup
Maximum MPPE - This option indicates that the router will use the MPPE encryption scheme with maximum bits (128-bit) to encrypt the data. Mutual Authentication The Mutual Authentication function is mainly used to Vigor2760 Series User’s Guide...
Page 286: Ipsec General Setup
There are two encapsulation methods used in IPsec, Transport and Tunnel. The Transport mode will add the AH/ESP payload and use original IP header to encapsulate the data payload only. It can just apply to local packet, e.g., L2TP over IPsec. The Tunnel mode will not only Vigor2760 Series User’s Guide...
Page 287 By default, this option is active. High (ESP) - Encapsulating Security Payload (ESP) means payload (data) will be encrypted and authenticated. You may select encryption algorithm from Data Encryption Standard (DES), Triple DES (3DES), and AES. Vigor2760 Series User’s Guide...
Page 288: Ipsec Peer Identity
Click each index to edit one peer digital certificate. There are three security levels of digital signature authentication: Fill each necessary field to authenticate the remote peer. The following explanation will guide you to fill all the necessary fields. Vigor2760 Series User’s Guide...
Page 289 The field includes Country (C), State (ST), Location (L), Organization (O), Organization Unit (OU), Common Name (CN), and Email (E). After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 290: Remote Dial-In User
Click each index to edit one remote user profile. Each Dial-In Type requires you to fill the different corresponding fields on the right. If the fields gray out, it means you may leave it untouched. The following explanation will guide you to fill all the necessary fields. Vigor2760 Series User’s Guide...
Page 291  Nice to Have - Apply the IPsec policy first, if it is applicable during negotiation. Otherwise, the dial-in VPN connection becomes one pure L2TP connection.  Must -Specify the IPsec policy to be definitely Vigor2760 Series User’s Guide...
Page 292 (1-63) as the pre-shared key. Digital Signature (X.509) – Check the box of Digital Signature to invoke this function and Select one predefined Profiles set in the VPN and Remote Access >>IPsec Peer Vigor2760 Series User’s Guide...
Page 293: Lan To Lan
ID, connection type (VPN connection - including PPTP, IPsec Tunnel, and L2TP by itself or over IPsec) and corresponding security methods, etc. The following figure shows the summary table. Available settings are explained as follows: Item Description Set to Factory Default Click to clear all indexes. Vigor2760 Series User’s Guide...
Page 294 LAN-to-LAN profile includes 4 subgroups. If the fields gray out, it means you may leave it untouched. The following explanations will guide you to fill all the necessary fields. For the web page is too long, we divide the page into several sections for explanation. Vigor2760 Series User’s Guide...
Page 295 Dial-Out- initiator only  Dial-In- responder only. Always On-Check to enable router always keep VPN connection. Idle Timeout: The default value is 300 seconds. If the connection has been idled over the value, the router will Vigor2760 Series User’s Guide...
Page 296 PAP/CHAP is the most common selection due to wild compatibility. VJ compression - This field is applicable when you select PPTP or L2TP with or without IPsec policy above. VJ Compression is used for TCP/IP protocol header Vigor2760 Series User’s Guide...
Page 297 AES with Authentication-Use AES encryption algorithm and apply MD5 or SHA-1 authentication algorithm. Advanced - Specify mode, proposal and key life of each IKE phase, Gateway, etc. The window of advance setup is shown as below: Vigor2760 Series User’s Guide...
Page 298 Index(1-15) - Set the wireless LAN to work at certain time interval only. You may choose up to 4 schedules out of the 15 schedules pre-defined in Applications >> Schedule setup. The default setting of this field is blank and the function will always work. Vigor2760 Series User’s Guide...
Page 299 Must - Specify the IPsec policy to be definitely applied on the L2TP connection. Specify Remote VPN Gateway - You can specify the IP address of the remote dial-in user or peer ID (should be the Vigor2760 Series User’s Guide...
Page 300 High- Encapsulating Security Payload (ESP) means payload (data) will be encrypted and authenticated. You may select encryption algorithm from Data Encryption Standard (DES), Triple DES (3DES), and AES. TCP/IP Network My WAN IP –This field is only applicable when you select Vigor2760 Series User’s Guide...
Page 301 If the remote network only allows you to dial in with single IP, please choose NAT, otherwise choose Route. Change default route to this VPN tunnel - Check this box to change the default route with this VPN tunnel. Vigor2760 Series User’s Guide...
Page 302 VPN router. Translated Type – There are two types for you to choose.  Whole Subnet  Specific IP Address Virtual IP Mapping – A pop up dialog will appear for you Vigor2760 Series User’s Guide...
Page 303: Connection Management
Dial - Click this button to execute dial out function. Refresh Seconds - Choose the time for refresh the dial information among 5, 10, and 30. Refresh - Click this button to refresh the whole connection status. Vigor2760 Series User’s Guide...
Page 304: Certificate Management
Click this button to import a saved file as the certification information. Refresh Click this button to refresh the information listed below. View Click this button to view the detailed settings for certificate request. Delete Click this button to delete selected name with certification information. Vigor2760 Series User’s Guide...
Page 305 Vigor router allows you to generate a certificate request and submit it the CA server, then import it as “Local Certificate”. If you have already gotten a certificate from a third party, you may import it directly. The supported types are PKCS12 Certificate and Certificate with a private key. Vigor2760 Series User’s Guide...
Page 306 .pfx or .p12. And these certificates usually need passwords. Note that PKCS12 is a standard for storing private keys and certificates securely. It is used in (among other things) Netscape and Microsoft Internet Explorer with their import and export options. Vigor2760 Series User’s Guide...
Page 307: Trusted Ca Certificate
Therefore, Vigor router offers a mechanism which allows you to generate root CA to save time and provide convenience for general user. Later, such root CA generated by DrayTek server can perform the issuing of local certificate. Trusted CA certificate lists three sets of trusted CA certificate.
Page 308 Trusted CA Certificate window. For viewing each trusted CA certificate, click View to open the certificate detail information window. If you want to delete a CA certificate, choose the one and click Delete to remove all the certificate information. Vigor2760 Series User’s Guide...
Page 309: Certificate Backup
Backup on the following screen to save them. If you want to set encryption password for these certificates, please type characters in both fields of Encrypt password and Retype password. Also, you can use Restore to retrieve these two settings to the router whenever you want. Vigor2760 Series User’s Guide...
Page 310: Voip
Then, both parties’ SIP proxies will forward the sequence of messages to caller to establish the session. If you both register to the same SIP Registrar, then it will be illustrated as below: Vigor2760 Series User’s Guide...
Page 311 Internet. You will always have the required inbound and outbound bandwidth that is prioritized exclusively for Voice traffic over Internet but you just get your data a little slower and it is tolerable for data traffic. Vigor2760 Series User’s Guide...
Page 312: General Setting
Nortel server NAT Traversal Support. Symmetric RTP – Check this box to invoke the function. To make the data transmission going through on both ends of local router and remote router not misleading due to IP Vigor2760 Series User’s Guide...
Page 313 RTP TOS – It decides the level of VoIP package. Use the drop down list to choose any one of them. IP Call Enable IP Call – It allows that a user could dial outgoing IP Calls; and Vigor router could receive the incoming IP Calls. Vigor2760 Series User’s Guide...
Page 314: Sip Accounts
Show the status for the corresponding SIP account. R means such account is registered on SIP server successfully. – means the account is failed to register on SIP server. Click any index link to access into the following page for configuring SIP account. Vigor2760 Series User’s Guide...
Page 315 Proxy Set domain name or IP address of SIP proxy server. By the time you can type :port number after the domain name to specify that port as the destination of data transmission (e.g., nat.draytel.org:5065) Vigor2760 Series User’s Guide...
Page 316 SIP URL by the time out. SIP URL – Type in the SIP URL (e.g., aaa@draytel.org or abc@iptel.org) as the site for call forwarded. Time Out – Set the time out for the call forwarding. The default setting is 30 sec. Vigor2760 Series User’s Guide...
Page 317 If not, the router will do something to save the bandwidth for other using. Click On to invoke this function; click off to close the function. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 318: Dialplan
SIP addresses. Loop through and Backup Phone Number will be displayed if you are using Vigor router for setting the phone book. Click any index number to display the dial plan setup page. Vigor2760 Series User’s Guide...
Page 319 Note: If the incoming or outgoing calls do not match any entry on the phonebook, the router will try to make the call "being protected". But, if the call ends up "unprotected"(e.g. peer side does not support ZRTP+SRTP), the router will not play out a warning message. Vigor2760 Series User’s Guide...
Page 320 VoIP interface. Take the above picture (Prefix Table Setup web page) as an example, the prefix number of 03 will be replaced by 8863. For example: dial number of Vigor2760 Series User’s Guide...
Page 321 VoIP>> Phone Settings. Move UP /Move Down Click the link to move the selected entry up or down. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 322 Call barring is used to block phone calls coming from the one that is not welcomed. Click any index number to display the dial plan setup page. Vigor2760 Series User’s Guide...
Page 323 SIP accounts. Such control also can be done based on preconfigured schedules. For Block IP Address – this function can block incoming calls (through Phone port) coming from IP address. Such control also can be done based on preconfigured schedules. Vigor2760 Series User’s Guide...
Page 324 Dial the number typed in this field to forward all the Call Forward [No incoming calls to the specified place while there is no Ans][Act] answer of the connected phone. Vigor2760 Series User’s Guide...
Page 325 Dial the number typed in this field to release this function. Block Last Calls [Act] Dial the number typed in this field to block the last incoming phone call. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 326 PSTN number available for dial whenever you need and type the number in the field of phone number for PSTN relay. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 327: Phone Settings
SIP account for each phone port. DTMF Relay – Display DTMF mode that configured in the advanced settings page of Phone Index. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 328 Check this box to hide the caller ID on the display panel of the phone set. Call Waiting Check this box to invoke this function. A notice sound will appear to tell the user new phone call is waiting for your Vigor2760 Series User’s Guide...
Page 329 Select the proper region which you are located. The common settings of Caller ID Type, Dial tone, Ringing tone, Busy tone and Congestion tone will be shown automatically on the page. If you cannot find out a suitable Vigor2760 Series User’s Guide...
Page 330 DTMF Mode – There are four DTMF modes for you to choose.  InBand - Choose this one then the Vigor will send the DTMF tone as audio directly when you press the keypad on the phone. Vigor2760 Series User’s Guide...
Page 331: Status
From this page, you can find codec, connection and other important call status for each port. Available settings are explained as follows: Item Description Refresh Seconds Specify the interval of refresh time to obtain the latest VoIP Vigor2760 Series User’s Guide...
Page 332 Accumulation for the times of in call. Out Calls Accumulation for the times of out call. Miss Calls Accumulation for the times of missing call. Speaker Gain The volume of present call. Display logs of VoIP calls. Vigor2760 Series User’s Guide...
Page 333: Wireless Lan
SSID as identification, located channel etc. Vigor router supports four SSID settings for wireless connections. Each SSID can be defined with different name and download/upload rate for selecting by stations connected to the router wirelessly. Vigor2760 Series User’s Guide...
Page 334 For a more flexible deployment, you may add filters of MAC addresses to isolate users’ access from wired LAN. Manage Wireless Stations - Station List will display all the station in your wireless network and the status of their connection. Vigor2760 Series User’s Guide...
Page 335: General Setup
Means the channel of frequency of the wireless LAN. The default channel is 6. You may switch channel if the selected channel is under serious interference. If you have no idea of choosing the frequency, please select Auto to let system determine for you. Vigor2760 Series User’s Guide...
Page 336: Security
If WEP mode is selected, only one of four preset keys can be selected at one time. By clicking the Security Settings, a new web page will appear so that you could configure the settings of WPA and WEP. Vigor2760 Series User’s Guide...
Page 337 RADIUS server with 802.1X protocol. WPA/802.1x Only- Accepts only WPA clients and the encryption key is obtained dynamically from RADIUS server with 802.1X protocol. WPA2/802.1x Only- Accepts only WPA2 clients and the Vigor2760 Series User’s Guide...
Page 338 The keys can be entered in ASCII or Hexadecimal. Check the key you wish to use. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 339: Access Control
Isolate the station from LAN - select to isolate the wireless connection of the wireless client of the MAC address from LAN. Add a new MAC address into the list. Delete Delete the selected MAC address in the list. Vigor2760 Series User’s Guide...
Page 340: Wps
He/she only needs to press a button on wireless client, and WPS will connect for client and router automatically. There are two methods to do network connection through WPS between AP and Stations: pressing the Start PBC button or using PIN Code. Vigor2760 Series User’s Guide...
Page 341 For WPS is supported in WPA-PSK or WPA2-PSK mode, if you do not choose such mode in Wireless LAN>>Security, you will see the following message box. Please click OK and go back Wireless LAN>>Security to choose WPA-PSK or WPA2-PSK mode and access WPS again. Vigor2760 Series User’s Guide...
Page 342 Start PIN button. The WPS LED on the router will blink fast when WPS is in progress. It will return to normal condition after two minutes. (You need to setup WPS within two minutes) Vigor2760 Series User’s Guide...
Page 343: Wds
In the following examples, hosts connected to Bridge 1 or 3 can communicate with hosts connected to Bridge 2 through WDS links. However, hosts connected to Bridge 1 CANNOT communicate with hosts connected to Bridge 3 through Bridge 2. Vigor2760 Series User’s Guide...
Page 344 Click WDS from Wireless LAN menu. The following page will be shown. Available settings are explained as follows: Item Description Mode Choose the mode for WDS setting. Disable mode will not invoke any WDS setting. Bridge mode is designed to fulfill Vigor2760 Series User’s Guide...
Page 345 Disable to cancel this function. Status It allows user to send “hello” message to peers. Yet, it is valid only when the peer also supports this function. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 346: Advanced Setting
Aggregation MSDU combine frames with different Aggregation MSDU can sizes. It is used for improving MAC layer’s performance for some brand’s clients. The default setting is Enable. Vigor2760 Series User’s Guide...
Page 347 To apply WMM parameters for wireless data transmission, please click the Enable radio button. APSD Capable APSD (automatic power-save delivery) is an enhancement over the power-save mechanisms supported by Wi-Fi networks. It allows devices to take more time in sleeping Vigor2760 Series User’s Guide...
Page 348 Set the RTS threshold. Do not modify default value if you don’t know what it is, default value is 2347. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 349: Station Control
All the wireless stations connecting to Vigor router by using Control List such SSID will be listed on Station Control List. WEB Portal Setup Click it to access in to LAN>>Web Portal Setup page for modifying the settings if required. Vigor2760 Series User’s Guide...
Page 350: Bandwidth Management
Download Limit - Default value is 30,000 kbps. Each wireless station can have the bandwidth for uploading without exceeding the values typed here. After finished the above settings, click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 351: Ap Discovery
AP’s MAC address on the bottom of the page and click Bridge or Repeater. Next, click Add to. Later, the MAC address of the AP will be added to Bridge or Repeater field of WDS settings page. Vigor2760 Series User’s Guide...
Page 352: Station List
WLAN station and click Add to Access Control below. Available settings are explained as follows: Item Description Refresh Click this button to refresh the status of station list. Click this button to add current typed MAC address into Access Control. Vigor2760 Series User’s Guide...
Page 353: Ssl Vpn
Otherwise, choose Self-signed to use the router’s built-in default certificate. The default certificate can be used in SSL VPN server and HTTPS Web Proxy. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 354: Ssl Web Proxy
Type the address (function variation or IP address) or path of the proxy server. If you type function variation as URL, you have to type Host IP Address corresponding IP address in this filed. Such field must Vigor2760 Series User’s Guide...
Page 355: Ssl Application
Display the type of the service selected, e.g., VNC/RDP/SMB. Active Display current status (active or inactive) of the selected profile. To create a new SSL application profile: 1. Click number link under Index field to set detailed configuration. Vigor2760 Series User’s Guide...
Page 356 If you choose RDP, you have to choose the screen size for such application. SMB Path If you choose Samba, you have to specify the path of the Samba service. 3. Enter the required information. 4. After finished the above settings, click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 357: User Account
Therefore, the user account for SSL VPN must be set together with remote dial-in user web page. Such menu item will guide to access into VPN and Remote Access>>Remote Dial-in user. Click each index to edit one remote user profile. Vigor2760 Series User’s Guide...
Page 358 Must -Specify the IPSec policy to be definitely applied on the L2TP connection. SSL Tunnel - It allows the remote dial-in user to make an SSL VPN Tunnel connection through Internet, suitable for the application through network accessing (e.g., Vigor2760 Series User’s Guide...
Page 359 Digital Signature (X.509) – Check the box of Digital Signature to invoke this function and Select one predefined Profiles set in the VPN and Remote Access >>IPSec Peer Identity. IPSec Security Method This group of fields is a must for IPSec Tunnels and L2TP Vigor2760 Series User’s Guide...
Page 360 Local ID - Specify a local ID to be used for Dial-in setting in the LAN-to-LAN Profile setup. This item is optional and can be used only in IKE aggressive mode. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 361: User Group
Display the number of the client which connecting to FTP Index server. Name Display the name of the group profile. Click any index number link to open the following page for detailed configuration. Available settings are explained as follows: Vigor2760 Series User’s Guide...
Page 362 If the above three options are enabled, the system will do the authentication based on them in sequence. After finishing all the settings here, please click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 363: Online User Status
If you have finished the configuration of SSL Web Proxy (server), users can find out corresponding settings when they access into DrayTek SSL VPN portal interface. Next, users can open SSL VPN>> Online Status to view logging status of SSL VPN.
Page 364: Usb Application
FAT32 for viewing the filename completely (FAT16 cannot support long filename). Available settings are explained as follows: Item Description General Settings Simultaneous FTP Connections - This field is used to specify the quantity of the FTP sessions. The router allows Vigor2760 Series User’s Guide...
Page 365: Usb User Management
USB storage disk must type the same username and password configured in this page. Before adding or modifying settings in this page, please insert a USB storage disk first. Otherwise, an error message will appear to warn you. Vigor2760 Series User’s Guide...
Page 366 USB storage disk. Note: When write protect status for the USB storage disk is ON, you cannot type any new folder name in this field. Only “/” can be used in such case. Vigor2760 Series User’s Guide...
Page 367: File Explorer
File Explorer offers an easy way for users to view and manage the content of USB storage disk connected on Vigor router. Available settings are explained as follows: Item Description Click this icon to refresh files list. Refresh Click this icon to return to the upper directory. Back Vigor2760 Series User’s Guide...
Page 368: Usb Device Status
Username It displays the username that user uses to login to the FTP server. When you insert USB storage disk into the Vigor router, the system will start to find out such device within several seconds. Vigor2760 Series User’s Guide...
Page 369: Temperature Sensor
A USB Thermometer is now available. It complements your installed DrayTek router installations which will help you monitor the server or data communications room environment and notify you if the server room or data communications room is overheating. During summer in particular, it is important to ensure that your server or data communications equipment are not overheating due to cooling system failures.
Page 370 Enable Syslog Alarm - The temperature log will be recorded on Syslog if it is enabled. Upper temperature limit/Lower temperature limit - Type the upper limit and lower limit for the system to send out temperature alert. Below shows an example of temperature graph: Vigor2760 Series User’s Guide...
Page 371: Modem Support List
Such page provides the information about the brand name and model name of the USB modems which are supported by Vigor router. Vigor2760 Series User’s Guide...
Page 372: System Maintenance
Below shows the menu items for System Maintenance. The System Status provides basic network settings of Vigor router. It includes LAN and WAN interface information. Also, you could get the current running firmware version or firmware related information from this presentation. Vigor2760 Series User’s Guide...
Page 373 Scope - Display the scope of IPv6 address. For example, IPv6 Link Local could only be used for direct IPv6 link. It can't be used for IPv6 internet. Internet Access Mode – Display the connection mode chosen for accessing into Internet. Vigor2760 Series User’s Guide...
Page 374: 358
Test With Inform – Specify the Event Code from the drop down list. Click this button to make a test for the response from VigorACS. Last Inform Response Time - Display the response time informed by VigorACS. Vigor2760 Series User’s Guide...
Page 375 VigorAP.  AP Password – Type the password of the VigorAP that you want to apply Vigor2760’s TR-069 settings. This page allows you to set new password. Available settings are explained as follows: Vigor2760 Series User’s Guide...
Page 376: Administrator Password
Below shows an example for accessing into User Operation with User Password. 1. Open System Maintenance>>User Password. 2. Check the box of Enable User Mode for simple web configuration to enable user mode operation. Type a new password in the field of New Password and click OK. Vigor2760 Series User’s Guide...
Page 377 4. Log out Vigor router web user interface by clicking the Logout button. 5. The following window will be open to ask for username and password. Type the new user password in the filed of Password and click Login. Vigor2760 Series User’s Guide...
Page 378: Login
At that moment, the background of the web page is blank and no heading will be displayed on the Login window. This page allows you to specify login URL and the heading on the Login window if you have such requirement. Vigor2760 Series User’s Guide...
Page 379 Enable Check this box to enable the login customization function. Login Page Title Type a brief description (e.g., Welcome to DrayTek) which will be shown on the heading of the login dialog. Welcome Message and Type words or sentences here. It will be displayed for bulletin message.
Page 380: Configuration Backup
Click Backup button to get into the following dialog. Click Save button to open another dialog for saving configuration as a file. In Save As dialog, the default filename is config.cfg. You could give it another name by yourself. Vigor2760 Series User’s Guide...
Page 381 Click Browse button to choose the correct configuration file for uploading to the router. Click Restore button and wait for few seconds, the following picture will tell you that the restoration procedure is successful. Vigor2760 Series User’s Guide...
Page 382: Syslog/Mail Alert
User Access, Call, WAN, Router/DSL information to Syslog. Mail Alert Setup Check Enable to activate function of mail alert. Send a test e-mail - Make a simple test for the e-mail address specified in this page. Please assign the mail Vigor2760 Series User’s Guide...
Page 383 From the Syslog screen, select the router you want to monitor. Be reminded that in Network Information, select the network adapter used to connect to the router. Otherwise, you won’t succeed in retrieving information from the router. Vigor2760 Series User’s Guide...
Page 384 Vigor2760 Series User’s Guide...
Page 385: Time And Date
Check the box to enable the daylight saving. Such feature is available for certain area. Advanced – Click it to open a pop up dialog. Use the default time setting or set user defined time for your requirement. Vigor2760 Series User’s Guide...
Page 386: Snmp
DES) and authentication method (support MD5 and SHA) for the management needs. Available settings are explained as follows: Item Description Enable SNMP Agent Check it to enable this function. Get Community Set the name for getting community by typing a proper Vigor2760 Series User’s Guide...
Page 387 Privacy Algorithm Choose one of the methods listed below as the privacy algorithm. Privacy Password Type a password for privacy. The maximum length of the text is limited to 23 characters. Click OK to save these settings. Vigor2760 Series User’s Guide...
Page 388: Management
Available settings are explained as follows: Item Description Router Name Type in the router name provided by ISP. Default: Disable If it is enabled, the function of auto-logout for web user Auto-Logout interface will be disabled. Vigor2760 Series User’s Guide...
Page 389 Client, you may still need to enable SSL 3.0 to make sure you can connect, however, it's not recommended. Device Management Check the box to enable the device management function for Vigor2860. Respond to external device – If it is enabled, Vigor2760 Vigor2760 Series User’s Guide...
Page 390 (master device) sends request packet to Vigor2760, Vigor2760 would send back information to respond the request coming from the external device which is able to manage Vigor2760. After finished the above settings, click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 391 A maximum of three IPs/subnet masks is allowed. IPv6 Address /Prefix Length- Indicate the IP address(es) allowed to login to the router. After finished the above settings, click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 392: Reboot System
Note: When the system pops up Reboot System web page after you configure web settings, please click Reboot Now to reboot your router for ensuring normal operation and preventing unexpected errors of the router in the future. Vigor2760 Series User’s Guide...
Page 393: Firmware Upgrade
Note that this example is running over Windows OS (Operating System). Download the newest firmware from DrayTek's web site or FTP site. The DrayTek web site is www.DrayTek.com (or local DrayTek's web site) and FTP site is ftp.DrayTek.com.
Page 394: Dsl Firmware Upgrade
The Activate link brings you accessing into www.vigorpro.com to finish the activation of the account and the router. Authentication Message As for authentication information of web filter, the process of authenticating will be displayed on this field for your reference. Vigor2760 Series User’s Guide...
Page 395: Diagnostics
Below shows the successful activation of Web Content Filter: Diagnostic Tools provide a useful way to view or diagnose the status of your Vigor router. Below shows the menu items for Diagnostics. Vigor2760 Series User’s Guide...
Page 396: Dial-Out Triggering
(e.g., PPPoE) is triggered by a package sending from the source IP address. Available settings are explained as follows: Item Description Decoded Format It shows the source IP address (local), destination IP (remote) address, the protocol and length of the package. Refresh Click it to reload the page. Vigor2760 Series User’s Guide...
Page 397: Routing Table
Click Diagnostics and click Routing Table to open the web page. Available settings are explained as follows: Item Description Refresh Click it to reload the page. Vigor2760 Series User’s Guide...
Page 398: Arp Cache Table
IPv6 address. This information is helpful in diagnosing network problems, such as IP address conflicts, etc. Click Diagnostics and click IPv6 Neighbour Table to open the web page. Available settings are explained as follows: Item Description Vigor2760 Series User’s Guide...
Page 399: Dhcp Table
It displays the IP address assigned by this router for specified PC. MAC Address It displays the MAC address for the specified PC that DHCP assigned IP address for it. Leased Time It displays the leased time of the specified PC. Vigor2760 Series User’s Guide...
Page 400: Nat Sessions Table
It indicates the temporary port of the router used for NAT. Peer IP:Port It indicates the destination IP address and port of remote host. Interface It displays the representing number for different interface. Refresh Click it to reload the page. Vigor2760 Series User’s Guide...
Page 401: Ping Diagnosis
Use the drop down list to choose the destination that you want to ping. IP Address Type the IP address of the Host/IP that you want to ping. Type the IPv6 address that you want to ping. Ping IPv6 Address Vigor2760 Series User’s Guide...
Page 402: Data Flow Monitor
Flow Monitor. If not, a notification dialog box will appear to remind you enabling it. Click Diagnostics and click Data Flow Monitor to open the web page. You can click IP Address, TX rate, RX rate or Session link for arranging the data display. Vigor2760 Series User’s Guide...
Page 403 Peak means the highest peak value detected by the router in data transmission. Speed means line speed specified in WAN>>General Setup. If you do not specify any rate at that page, here will display Auto for instead. Vigor2760 Series User’s Guide...
Page 404: Traffic Graph
WAN1/WAN2/WAN3 Bandwidth chart, the numbers displayed on vertical axis represent the numbers of the transmitted and received packets in the past. For Sessions chart, the numbers displayed on vertical axis represent the numbers of the NAT sessions during the past. Vigor2760 Series User’s Guide...
Page 405: Trace Route
Available settings are explained as follows: Item Description IPv4 / IPv6 Click one of them to display corresponding information for Trace through Use the drop down list to choose the interface that you want to ping through. Vigor2760 Series User’s Guide...
Page 406: Syslog Explorer
Click this link to save the data as a file. Refresh Click this link to refresh this page manually. Clear Click this link to clear information on this page. Display Mode There are two modes for you to choose. Vigor2760 Series User’s Guide...
Page 407 This page displays the syslog recorded on the USB storage disk. Available settings are explained as follows: Item Description Time Display the time of the event occurred. Log Type Display the type of the record. Message Display the information for each event. Vigor2760 Series User’s Guide...
Page 408: Ipv6 Tspc Status
If TSPC has configured properly, the router will display the following page when the user connects to tunnel broker successfully. Available settings are explained as follows: Item Description Refresh Click this link to refresh this page manually. Vigor2760 Series User’s Guide...
Page 409: Tutorials And Applications
TSPC, AICCU, DHCPv6 Client, Static IPv6, 6in4 Static Tunnel and 6rd. Access into the web user interface of Viogr2760. Open WAN>> Internet Access. Choose one of the WAN interfaces as the one supporting IPv6 service. Then, click the IPv6 button of the selected WAN. Vigor2760 Series User’s Guide...
Page 410 PPP – Dual Stack application, IPv4 and IPv6 services can be utilized at the same time Choose PPP and type the information for PPPoE of IPv4. Access into the setting page for IPv6 service, it is not necessary for you to configure anything. Vigor2760 Series User’s Guide...
Page 411 Click OK and open Online Status. If the connection is successful, you will get the IP address for IPv4 and IPv6 at the same time. Vigor2760 Series User’s Guide...
Page 412 (In the following figure, the TSPC information is obtained from http://gogo6.com/ after applied for the service.) Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2760 Series User’s Guide...
Page 413 (In the following figure, the AICCU information is obtained from https://www.sixxs.net/main/ after applied for the service.) Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2760 Series User’s Guide...
Page 414  DHCPv6 Client Choose DHCPv6 Client. Click one of the identity associations and type the IAID number. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2760 Series User’s Guide...
Page 415  Static IPv6 Choose Static IPv6. Type IPv6 address, Prefix Length and Gateway Address. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2760 Series User’s Guide...
Page 416 Choose 6in4 Static Tunnel. Type remote endpoint IPv4 address, 6in4 IPv6 Address, LAN Routed Prefix and Tunnel TTL. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2760 Series User’s Guide...
Page 417  Choose 6rd. Type IPv4 Border Relay, IPv4 Mask Length, 6rd Prefix and 6rd Prefix Length. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2760 Series User’s Guide...
Page 418 In the field of HCPv6 Server Configuration, when DHCPv6 service is enabled, you can assign available IPv6 address for the client manually. Note: When both mechanisms are enabled, the client can determine which mechanism to be used (e.g., the default mechanism for Windows7 is Router Advertisement Server ). Vigor2760 Series User’s Guide...
Page 419 IPv4 IP and IPv6 IP services. Its IPv6 address is seen with a format of 2001:200:dff:fff1:216:3eff:feb1:44d7. After getting the above message, it means the IPv6 service has been activated successfully. Vigor2760 Series User’s Guide...
Page 420 If not, only a steady turtle will be seen. If you can see a turtle dancing on the screen, that means IPv6 service is ready for you to access and utilize. Vigor2760 Series User’s Guide...
Page 421: How Can I Get The Files From Usb Storage Device Connecting To Vigor Router
Setup a user account for the FTP service by using USB Application >>USB User Management. Click Enable to enable FTP account. Here we add a new account "user1" and assign authorities “Read”, “Write” and “List” to it. Click OK to save the configuration. Vigor2760 Series User’s Guide...
Page 422 Now, users in LAN of Vigor2710 can access into the USB storage device by typing ftp://192.168.1.1 on any browser. They can add or remove files / directories, depending on the Access Rule for FTP account settings in USB Application >>USB User Management. Vigor2760 Series User’s Guide...
Page 423: How To Build A Lan-To-Lan Vpn Between Remote Office And Headquarter Via Ipsec Tunnel
(in this case, type VPN Server), and check the box of Enable This Profile. For Vigor router will be set as a server, the call direction shall be set as Dial-in and set 0 as Idle Timeout. Vigor2760 Series User’s Guide...
Page 424 (e.g., 218.242.130.19 in this case). Press the IKE Pre-Shared Key button to set the PSK; and select Medium (AH) or High (ESP) as the security method. Continue to navigate to the TCP/IP Network Settings for setting the LAN IP for remote side. Click OK to save the settings. Vigor2760 Series User’s Guide...
Page 425 (in this case, type VPN Client), and check the box of Enable This Profile. For such Vigor router will be set as a client, the call direction shall be set as Dial-out. Check the box of Always on for a permanent VPN connection. Vigor2760 Series User’s Guide...
Page 426 IKE Pre-Shared Key button to set the PSK; and select Medium (AH) or High (ESP) as the security method. Continue to navigate to the TCP/IP Network Settings for setting the LAN IP for the remote side. Click OK to save the settings. Vigor2760 Series User’s Guide...
Page 427: How To Optimize The Bandwidth Through Qos Technology
Internet connection line? The advanced bandwidth management technology-QoS (Quality of Service) helps you to well allocate the bandwidth upon your demand of Voice, Video, or Data transferring. Let's see how to get the optimum bandwidth per your request by using DrayTek Vigor router as below.
Page 428 In the pop-up window, choose Range Address as the Address Type and type the start IP address and end IP address in relational fields. Click OK to save the settings and exit the window. Click OK again to save the settings. Vigor2760 Series User’s Guide...
Page 429 Do the same steps to add class rules for IPTV and Data/Email with IP addresses as shown below. Assuming you get 2MB/512Kb Internet line. You can click the Setup link of WAN1 to set up the bandwidth for different groups among VoIP, IPTV and Data/Email. Vigor2760 Series User’s Guide...
Page 430 10. In the Setup page, check the box of Enable the QoS Control. Type 30, 50 and 15 in the boxes for VoIP, IPTV and Data/Email respectively. Check the box of Enable UDP Bandwidth Control. 11. Click OK to save the settings. The class rules for WAN1 are defined as shown below. Vigor2760 Series User’s Guide...
Page 431: Qos Setting Example
Skype in the restroom. Go to Bandwidth Management>>Quality of Service. Click Setup link of WAN(1/2/3). Make sure the QoS Control on the left corner is checked. And select BOTH in Direction. Set Inbound/Outbound bandwidth. Vigor2760 Series User’s Guide...
Page 432 E-mail using protocol POP3 and SMTP. Click OK to save the settings. Return to previous page. Enter the Name of Index Class 2 by clicking Edit link. In this index, the user will set reserved bandwidth for HTTPS. And click OK. Vigor2760 Series User’s Guide...
Page 433 Click OK. If the worker has connected to the headquarter using host to host VPN tunnel. (Please refer to Chapter 3 VPN for detail instruction), he may set up an index for it. Enter the Vigor2760 Series User’s Guide...
Page 434 Class Name of Index 3. In this index, he will set reserved bandwidth for 1 VPN tunnel. 10. Click Edit for Class 3 to open a new window. In this index, the user will set reserved bandwidth for VPN. 11. Click Add to open the following window. Check the ACT box, first. Vigor2760 Series User’s Guide...
Page 435 12. Then click Edit of Local Address to set a worker’s subnet address. Click Edit of Remote Address to set headquarter’s IP address. Leave other fields and click OK. Vigor2760 Series User’s Guide...
Page 436: How To Send A Notification To Specified Phone Number Via Sms Service In Wan Disconnection
Choose any index number (e.g., Index 1 in this case) to configure the SMS Provider setting. In the following page, type the username and password and set the quota that the router can send the message out. Vigor2760 Series User’s Guide...
Page 437 Choose any index number (e.g., Index 1 in this case) to configure conditions for sending the SMS. In the following page, type the name of the profile and check the Disconnected and Reconnected boxes for WAN to work in concert with the topic of this paper. Vigor2760 Series User’s Guide...
Page 438 Click OK to save the settings. Later, if one of the WAN connections fails in your router, the system will send out SMS to the phone number specified. If the router has only one WAN interface, the system will send out SMS to the phone number while reconnecting the WAN interface successfully. Vigor2760 Series User’s Guide...
Page 439 URL string of the SMS provider and type the username and password. After clicking OK, the new added SMS provider will be added and will be available for you to specify for sending SMS out. Vigor2760 Series User’s Guide...
Page 440: How To Create An Account For Myvigor
The website of MyVigor (a server located on http://myvigor.draytek.com) provides several useful services (such as Anti-Spam, Web Content Filter, Anti-Intrusion, and etc.) to filtering the web pages for the sake of protecting your system. To access into MyVigor for getting more information, please create an account for MyVigor.
Page 441 2. Click the Activate link. A login page for MyVigor web site will pop up automatically. 3. Click the link of Create an account now. 4. Check to confirm that you accept the Agreement and click Accept. Vigor2760 Series User’s Guide...
Page 442 5. Type your personal information in this page and then click Continue. 6. Choose proper selection for your computer and click Continue. Vigor2760 Series User’s Guide...
Page 443 8. Check to see the confirmation email with the title of Letter from myvigor.draytek.com. 9. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. Vigor2760 Series User’s Guide...
Page 444: Create An Account Via Myvigor Web Site
11. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. 1. Access into http://myvigor.draytek.com. Find the line of Not registered yet?. Then, click the link Click here! to access into next page.
Page 445 2. Check to confirm that you accept the Agreement and click Accept. 3. Type your personal information in this page and then click Continue. 4. Choose proper selection for your computer and click Continue. Vigor2760 Series User’s Guide...
Page 446 6. Check to see the confirmation email with the title of Letter from myvigor.draytek.com. 7. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. Vigor2760 Series User’s Guide...
Page 447 UserName and Password. Then type the code in the box of Auth Code according to the value displayed on the right side of it. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. Vigor2760 Series User’s Guide...
Page 448: How To Setup Address Mapping
We will take an example to introduce how to make use of this feature. Log into the web user interface of Vigor2760. Open WAN>>Internet Access. For WAN1, choose MPoA/Static or Dynamic IP as the Access Mode. Vigor2760 Series User’s Guide...
Page 449 Click the WAN IP Alias button to configure the other P address which is 202.211.100.11. Make sure Join IP NAT Pool is not checked. Click OK to save the settings. Now, you bind some specific computers to some WAN IP alias for outgoing traffic. Vigor2760 Series User’s Guide...
Page 450: How To Configure Certain Computers Accessing To Internet
Firewall>>Filter Setup is used as the default setting, we has to create a new rule starting from Filter Rule 2 of Set 2. Access into the web user interface of Vigor router. Open Firewall>>Filter Setup. Click the Set 2 link and choose the Filter Rule 2 button. Vigor2760 Series User’s Guide...
Page 451 Next, set another rule. Just open Firewall>>Filter Setup. Click the Set 2 link and choose the Filter Rule 3 button. Check the box of Check to enable the Filter Rule. Type the comments (e.g., open_ip). Click the Edit button for Source IP. Vigor2760 Series User’s Guide...
Page 452 End IP. Then, click OK to save the settings. The computers within the range can access into the Internet. Now, check the content of Source IP is correct or not. The action for Filter shall be set with Pass Immediately. Then, click OK to save the settings. Vigor2760 Series User’s Guide...
Page 453 Both filter rules have been created. Click OK. Now, all the settings are configured well. Only the computers with the IP addresses within 192.168.1.10 ~ 192.168.1.20 can access to Internet. Vigor2760 Series User’s Guide...
Page 454: How To Block Facebook Service Accessed By The Users Via Web Content Filter / Url Content Filter
*How to Register AI/AV/AS/WCF Service (Service Activation Wizard) (http://www.draytek.com/user/SupportFAQDetail.php?ID=1955) *How to Activate Anti-Virus/Anti-Intrusion/Anti-Spam Service (http://www.draytek.com/user/SupportFAQDetail.php?ID=286 ) How to use the Web Content Filter (WCF) (http://www.draytek.com/user/SupportFAQDetail.php?ID=1953) * What the Web Content Filter (WCF) license benefits are, (http://www.draytek.com/user/PdInfoDetail.php?Id=110) Vigor2760 Series User’s Guide...
Page 455 Open CSM >> Web Content Filter Profile to create a WCF profile. Check Social Networking with Action, Block. Enable this profile in Firewall>>General Setup>>Default Rule. Next time when someone accesses facebook via this router, the web page would be blocked and the following message would be displayed instead. Vigor2760 Series User’s Guide...
Page 456 In the field of Contents, please type facebook. Configure the settings as the following figure. Open CSM>>URL Content Filter Profile. Click an index number to open the setting page. Configure the settings as the following figure. When you finished the above steps, click OK. Then, open Firewall>>General Setup. Vigor2760 Series User’s Guide...
Page 457 B. Disallow users to play games on Facebook Open Object Settings>>Keyword Object. Click an index number to open the setting page. In the field of Contents, please type apps.facebook. Configure the settings as the following figure. Vigor2760 Series User’s Guide...
Page 458 When you finished the above steps, please open Firewall>>General Setup. Click the Default Rule tab. Choose the profile just configured from the drop down list in the field of URL Content Filter. Now, users cannot open any web page with the word “facebook” inside. Vigor2760 Series User’s Guide...
Page 459: Trouble Shooting
Turn on the router. Make sure the ACT LED blink once per second and the correspondent LAN LED is bright. If not, it means that there is something wrong with the hardware status. Simply back to “1.3 Hardware Installation” to execute the hardware installation again. And then, try again. Vigor2760 Series User’s Guide...
Page 460 Open All Programs>>Getting Started>>Control Panel. Click Network and Sharing Center. In the following window, click Change adapter settings. Icons of network connection will be shown on the window. Right-click on Local Area Connection and click on Properties. Vigor2760 Series User’s Guide...
Page 461 Select Internet Protocol Version 4 (TCP/IP) and then click Properties. Select Obtain an IP address automatically and Obtain DNS server address automatically. Finally, click OK. Vigor2760 Series User’s Guide...
Page 462 Double click on the current used Mac OS on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4. Vigor2760 Series User’s Guide...
Page 463: Pinging The Router From Your Computer
Open the Application folder and get into Utilities. Double click Terminal. The Terminal window will appear. Type ping 192.168.1.1 and press [Enter]. If the link is OK, the line of “64 bytes from 192.168.1.1: icmp_seq=0 ttl=255 time=xxxx ms” will appear. Vigor2760 Series User’s Guide...
Page 464: Checking If The Isp Settings Are Ok Or Not
PIN code and try again. If it still fails, it might be the compliance problem of system. Please open DrayTek Syslog Tool to capture the connection information (WAN Log) and send the page (similar to the following graphic) to the service center of DrayTek.
Page 465: Backing To Factory Default Setting If Necessary
Go to System Maintenance and choose Reboot System on the web page. The following screen will appear. Choose Using factory default configuration and click Reboot Now. After few seconds, the router will return all the settings to the factory settings. Vigor2760 Series User’s Guide...
Page 466: Contacting Draytek
After restore the factory default setting, you can configure the settings for the router again to fit your personal request. If the router still cannot work correctly after trying many efforts, please contact Draytek or your dealer for further help right away. For any questions, please feel free to send e-mail to support@DrayTek.com.
Page 467: Telnet Command Reference
IP address of the router. Click OK. The Telnet terminal will be open. Please type admin/admin for Account/Password. Then, type ?. You will see a list of valid/common commands depending on the router that your use. Vigor2760 Series User’s Guide...
Page 468 CO ITU Version[1] : 00000000 DSLAM CHIPSET VENDOR : < ADI > This command can set the Internet Access mode for the router. adsl ppp [ ? | pvc_no vci vpi Encap Proto modu acqIP idle [Username Password] Vigor2760 Series User’s Guide...
Page 469 This parameter is used only for PPPoE/PPPoA Password This parameter is used only for PPPoE/PPPoA You have to reboot the system when you set it on Route mode. > adsl ppp o 35 8 1 1 4 1 -1 draytek draytek Vigor2760 Series User’s Guide...
Page 470: Telnet Command: Adsl Bridge
PVC). 1: for the IGMP with different PVC which is used for special ISP. px… It means the number of LAN port (x=2~4). Port 1 is locked for NAT. > adsl bridge 4 on p2 p3 Vigor2760 Series User’s Guide...
Page 471: Telnet Command: Adsl Idle
4. Now, it is on continuous sending mode, and adsl2/2+ led is always ON. 5. Use 'adsl reboot' to restart dsl to normal mode. This command can wake up the idle router. > adsl reboot % Adsl is Rebooting... Vigor2760 Series User’s Guide...
Page 472: Telnet Command: Adsl Oamlb
Some ISP might set the vci value under 32. In such case, we can cancel such limit manually by using this command. Do not set the number greater than 254. adsl vcilimit [n] The number shall be between 1 ~ 254. > adsl vcilimit 33 change VCI limitation from 32 to 33. Vigor2760 Series User’s Guide...
Page 473: Telnet Command: Adsl Annex
At present ,this command allows you to enable and disable dual-latency only. adsl optn FUNC [value/on/off] Parameter Description FUNC Available setting is “dual” only. It means dual-latency. value The value shall be hex digits. on/off Type “on” for enabling such function. Type “off” for disabling such function. Vigor2760 Series User’s Guide...
Page 474: Telnet Command: Adsl Savecfg
> adsl vendorid on set vid0 vid1 % User define CPE Vendor ID is ON This command can set QoS parameter for ATM. adsl atm pcr [pvc_no][PCR][max][status] adsl atm scr [pvc_no][SCR] adsl atm mbs [pvc_no][MBS] adsl atm status Parameter Description Vigor2760 Series User’s Guide...
Page 475: Telnet Command: Adsl Pvcbinding
Display a table for PVC binding group. It means to clear specific PVC binding. > adsl pvcbinding 3 5 set done. bind pvc3 to pvc5. The above example means PVC3 has been bound to PVC5. Vigor2760 Series User’s Guide...
Page 476: Telnet Command: Adsl Snr
The above example means the PVC3 binding group has been removed. This command is used to . Note: We can provide prompt support (support@draytek.com) if you refer to the telnet command and have any queries. adsl snr [delta]...
Page 477: Telnet Command: Vdsl Drivermode
Vigor> vdsl idle on % DSL is under [IDLE/QUIET] test mode. % DSL debug tool mode is off. Note: We can provide prompt support (support@draytek.com) if you refer to the telnet command and have any queries. > vdsl drivermode %ADSL Enter Driver Mode! % 1.
Page 478: Telnet Command: Vdsl Showbins
This command is used to display each Bin(Tone) SNR, Gain, and Bits allocated. Note: We can provide prompt support (support@draytek.com) if you refer to the telnet command and have any queries. adsl showbins [startbin endbin | up] Parameter Description startbin Available setting: 0 to 4092.
Page 479: Telnet Command: Vdsl Savecfg
On – Enable the function. Off – Disable the function. This command is used to save the configuration. Note: We can provide prompt support (support@draytek.com) if you refer to the telnet command and have any queries. > Vigor> vdsl savecfg ? % Xdsl Cfg Save OK! This command is used to set user defined CPE vender ID.
Page 480: Telnet Command: Bpa
5 : WA(61.9.240.13) -l <List> List all settings configured. > bpa 1 -a 1 -n testUser -p testPassword -s 4 > bpa -l -------index: 1 active------ UserName[1]: testUser PassWord[1]: testPassword ServerIP[1]:4 -------index: 2 inactive------ UserName[2]: PassWord[2]: ServerIP[2]:0 > Vigor2760 Series User’s Guide...
Page 481: Telnet Command: Csm Appe Prof
Set the action of specific application Specify one of the following applications for such profile. : MSN : YahooIM : AIM : ICQ QQTM : QQ/TM iChat : iChat Jabber : Jabber/GoogleTalk : GoogleChat AliWW : AliWW Skype : Skype Vigor2760 Series User’s Guide...
Page 482: Telnet Command: Csm Appe P2P
BitTorrent Protocol ACTION Specify the action of the application, 0 or 1. 0: Block. All of the applications meet the CSM rule will be blocked. 1: Pass. All of the applications meet the CSM rule will be Vigor2760 Series User’s Guide...
Page 483: Telnet Command: Csm Appe Prot
Specify one of the following applications for such profile. Streaming: MMS: RTSP: RTSP TVAnts: TVAnts PPStream: PPStream PPlive: PPlive FeiDian: FeiDian UUSee: UUSee NSPlayer: NSPlayer PCAST: PCAST TVKoo: TVKoo SopCast: SopCast UDLiveX: UDLiveX TVUPlayer: TVUPlayer MySee: MySee Joost: Joost FlashVideo: FlashVideo SilverLight: MS SilverLight Vigor2760 Series User’s Guide...
Page 484: Telnet Command: Csm Ucf
It means to specify the name of the profile (less than 16 characters) It means to set the priority for the profile. VALUE Available numbers you can define are listed below: 0: It means Bundle: Pass. 1: It means Bundle: Block. Vigor2760 Series User’s Guide...
Page 485: Telnet Command: Csm Ucf Obj Index Uac
INDEX uac -i E|D csm ucf obj INDEX uac -o KEY_WORD_Object_Index csm ucf obj INDEX uac -g KEY_WORD_Group_Index Parameter Description INDEX It means to specify the index number of CSM profile, from 1 to Vigor2760 Series User’s Guide...
Page 486 Profile Index: 1 Profile Name:[game] Log:[none] Priority Select : [Bundle : Pass] [ ]Enable URL Access Control Action:[block] [v]Prevent web access from IP address. No Obj NO. Object Name --- -------- --------------------------------- No Grp NO. Group Name Vigor2760 Series User’s Guide...
Page 487: Telnet Command: Csm Ucf Obj Index Wf
It means to set the file extension object index number. File_Extension_Object_in Type the index number (1 to 8) for the file extension object. > csm ucf obj 1 wf -s c Profile Index: 1 Profile Name:[game] Log:[none] Priority Select : [Bundle : Pass] Vigor2760 Series User’s Guide...
Page 488: Telnet Command: Csm Wcf
It means to return to default settings for all of the profile. It means to specify the object profile. INDEX It means to specify the index number of web content filter profile, from 1 to 8. It means to view the web content filter profile. Vigor2760 Series User’s Guide...
Page 489 Advertisements & Pop-Ups, Arts, Transportation, Compromised, Dating & Personals, , Education, Finance, Government,Health & Medcine, News, Non-profits & NGOs, Personal Sites,Politics, Real Estate, Rligion, Restaurants & Dining,Shopping, Translators, General, Cults,Greetig cards, Image Sharing, Network Errors, Parked Domains, Private IP Vigor2760 Series User’s Guide...
Page 490: Telnet Command: Ddns Log
Displays the DDNS log. >ddns log > Sets and displays the DDNS time. ddns time <update in minutes> Parameter Description Update in minutes Type the value as DDNS time. The range is from 1 to 1440. Vigor2760 Series User’s Guide...
Page 491: Telnet Command: Dos
It means to disable the defense function for a specific attack(s). >dos –A The Dos Defense system is Activated >dos –s synflood 50 10 Synflood is enabled! Threshold=50 <pke/sec> timeout=10 <pke/sec> Vigor2760 Series User’s Guide...
Page 492: Telnet Command: Exit
It means to assign netmask for WAN connection. You have to type 255.255.255.xxx (x is changeable) as the netmask for WAN port. -g <gateway> It means to assign gateway IP for such WAN connection. It means to view Internet Access profile. Vigor2760 Series User’s Guide...
Page 493: Telnet Command: Ip 2Ndsubnet
Display an IP address which allows users set as the public subnet IP address. 2nd subnet IP address Specify an IP address. The system will set the one that you specified as the second subnet IP address. Vigor2760 Series User’s Guide...
Page 494: Telnet Command: Ip 2Ndmask
It means the auxiliary WAN IP address. Join to NAT Pool 0 (disable) or 1 (enable). index Type the index number of the table displayed on your screen. > ip aux add 192.168.1.65 1 % 192.168.1.65 has added in index 2. Vigor2760 Series User’s Guide...
Page 495: Telnet Command: Ip Addr
LAN IP address (network segment) set by this command for accessing into the web user interface of the router. Later, modify the start addresses for the DHCP server. This command allows users to set/add a specified netmask for your router. ip nmask [IP netmask] Vigor2760 Series User’s Guide...
Page 496: Telnet Command: Ip Arp
4: Decline VRRP mac into arp table 5: Accept VRRP mac into arp table status: display the setting status. Time Available settings will be 10, 20, 30,..2550 seconds. > ip arp accept status Accept illegal source mac arp: disable Vigor2760 Series User’s Guide...
Page 497: Telnet Command: Ip Dhcpc
It means to release current WAN IP address. renew It means to renew the WAN IP address and obtain another new one. status It displays current status of DHCP client. >ip dhcpc status I/F#3 DHCP Client Status: Vigor2760 Series User’s Guide...
Page 498: Telnet Command: Ip Ping
[Host/IP address] [WAN1/WAN2] [Udp/Icmp] Parameter Description IP address It means the target IP address. WAN1/WAN2 It means the WAN port that the above IP address passes through. Udp/Icmp It means the UDP or ICMP. Vigor2760 Series User’s Guide...
Page 499: Telnet Command: Ip Telnet
0 means disable; 1 means first subnet and 2 means second subnet. > ip rip 1 %% Set RIP 1st subnet. This command allows users to set the RIP (routing information protocol) of WAN IP. ip wanrip [ifno] -e [0/1] Parameter Description Vigor2760 Series User’s Guide...
Page 500 <ifno> 1: WAN1,2: WAN2 3: PVC3,4: PVC4,5: PVC5 -e <0/1> 0: disable, 1: enable Now status: WAN[1] Rip Protocol disable WAN[2] Rip Protocol disable WAN[3] Rip Protocol disable WAN[4] Rip Protocol disable WAN[5] Rip Protocol enable > Vigor2760 Series User’s Guide...
Page 501: Telnet Command: Ip Route
> ip route add 172.16.2.0 255.255.255.0 172.16.2.4 3 static > ip route status Codes: C - connected, S - static, R - RIP, * - default, ~ - private 192.168.1.0/ 255.255.255.0 is directly connected, LAN1 172.16.2.0/ 255.255.255.0 via 172.16.2.4, WAN1 Vigor2760 Series User’s Guide...
Page 502: Telnet Command: Ip Igmp_Proxy
This command is for setting IGMP General Query Interval The default value is 125000 ms Current Setting is:130000 ms > This command is used to configure WAN IP address. ip wanaddr [IP address] ]<IP netmask] [gateway ip] Vigor2760 Series User’s Guide...
Page 503: Telnet Command: Ip Wanttr
It means the MAC address of the device that you want to specify >ip dmz ? % ip dmz <mac>, now : 00-00-00-00-00-00 > ip dmz 11-22-33-44-55-66 > ip dmz ? % ip dmz <mac>, now : 11-22-33-44-55-66 > Vigor2760 Series User’s Guide...
Page 504: Telnet Command: Ip Session
It means the number of the session limits, e.g., 100. p2pnum It means the number of the session limits, e.g., 50 for P2P. >ip session default 100 > ip session add 192.168.1.5-192.168.1.100 100 50 > ip session on > ip session status IP range: Vigor2760 Series User’s Guide...
Page 505: Telnet Command: Ip Bandwidth
It means that the bandwidth will be shared for the IP range. > ip bandwidth default 200 800 > ip bandwidth add 192.168.1.50-192.168.1.100 10 60 > ip bandwidth status IP range: 192.168.1.50 - 192.168.1.100 : Tx:10K Rx:60K Current ip Bandwidth limit is turn off Vigor2760 Series User’s Guide...
Page 506: Telnet Command: Ip Bindmac
IP : 192.168.1.46 bind MAC : 00-50-7f-22-33-55 Comment : just This command is used to set the maximum number of NAT users. ip maxnatuser user no Parameter Description A number specified here means the total NAT users that User no Vigor2760 Series User’s Guide...
Page 507: Telnet Command: Ip6 Addr
This command is used to configure option-request settings for DHCPv6 client. ip6 dhcp req_opt [LAN|WAN1|WAN2|iface#] [-<command> <parameter>| ... ] Parameter Description req_opt It means option-request. LAN|WAN1|WAN2|iface# It means to specify LAN or WAN interface for such address. Vigor2760 Series User’s Guide...
Page 508: Telnet Command: Ip6 Dhcp Client
The available commands with parameters are listed below. <parameter>|…] […] means that you can type in several commands in one line. It means to show current DHCPv6 status. It means to request identity association ID for Prefix -p [IAID] Delegation. Vigor2760 Series User’s Guide...
Page 509: Telnet Command: Ip6 Dhcp Server
It means to set the second DNS IPv6 address. -c<parameter> It means to send rapid commit to server. 1: Enable 0: Disable It means to enable or disable the DHCPv6 server. -e<parameter> 1: Enable 0: Disable Vigor2760 Series User’s Guide...
Page 510 > ip6 dhcp server -x ff02::3 > ip6 dhcp server -a % Interface LAN has following DHCPv6 server settings: DHCPv6 server disabled maximum address of the pool: FF02::3 minimum address of the pool: FF02::1 1st DNS IPv6 Addr: FF02::1 Vigor2760 Series User’s Guide...
Page 511: Telnet Command: Ip6 Internet
It means to set the secondary DNS Server IP. <server>= type an IPv6 address for second DNS server. -t <dhcp/ra/none> It means to set IPv6 PPP WAN test mode for DHCP or RADVD. <dhcp/ra/none>= type IPv6 address. Vigor2760 Series User’s Guide...
Page 512: Telnet Command: Ip6 Neigh
Neighbour 2001:2222:3333::1111 successfully added! > ip6 neigh -a I/F ADDR STATE ------------------------------------------------------------------------- LAN FF02::1 33-33-00-00-00-01 CONNECTED WAN2 2001:5C0:1400:B::10B8 00-00-00-00-00-00 CONNECTED WAN2 2001:2222:3333::1111 00-00-00-00-00-00 CONNECTED WAN2 2001:2222:6666::1111 00-00-00-00-00-00 CONNECTED WAN2 :: 00-00-00-00-00-00 CONNECTED LAN :: NONE > Vigor2760 Series User’s Guide...
Page 513: Telnet Command: Ip6 Pneigh
It means the gateway of the router. LAN|WAN1|WAN2|iface# It means to specify LAN or WAN interface for such address. > ip6 route -s FE80::250:7FFF:FE12:500 16 FE80::250:7FFF:FE12:100 LAN Route FE80::250:7FFF:FE12:500/16 successfully added! > ip6 route -a LAN Vigor2760 Series User’s Guide...
Page 514: Telnet Command: Ip6 Ping
Receive reply from 2001:4860:4860::8888, time=330ms Receive reply from 2001:4860:4860::8888, time=330ms Receive reply from 2001:4860:4860::8888, time=330ms Receive reply from 2001:4860:4860::8888, time=330ms Receive reply from 2001:4860:4860::8888, time=330ms Packets: Sent = 5, Received = 5, Lost = 0 <% loss> > Vigor2760 Series User’s Guide...
Page 515: Telnet Command: Ip6 Tracert
> ip6 tspc 2 Local Endpoint v4 Address : 111.243.177.223 Local Endpoint v6 Address : 2001:05c0:1400:000b:0000:0000:0000:10b9 Router DNS name : 8886666.broker.freenet6.net Remote Endpoint v4 Address :81.171.72.11 Remote Endpoint v6 Address : 2001:05c0:1400:000b:0000:0000:0000:10b8 Tspc Prefixlen : 56 Tunnel Broker: Amsterdam.freenet.net Vigor2760 Series User’s Guide...
Page 516: Telnet Command: Ip6 Radvd
[add<index> <prefix> <prefix-length>|remove <index>|flush] ip6 mngt status ip6 mngt [http|telnet|ping] [on|off] Parameter Description list It means to show the setting information of the access list. status It means to show the status of IPv6 management. Vigor2760 Series User’s Guide...
Page 517: Telnet Command: Ip6 Online
This command allows you to check the online status of IPv6 LAN /WAN. ip6 online [ifno] Parameter Description ifno It means the connection interface. 0=LAN1 1=WAN1 2=WAN2 > ip6 online 0 % LAN 1 online status : % Interface : UP Vigor2760 Series User’s Guide...
Page 518: Telnet Command: Ip6 Aiccu
IPv6 settings. show It means to display the AICCU status. > ip6 aiccu subnet add 2 2001:1111:0000::1111 64 > ip6 aiccu 2 Status: Connecting >ip6 aiccu subnet show 2 IPv6 WAN2 AICCU Subnet Prefix Config: 2001:1111::1111/64 > Vigor2760 Series User’s Guide...
Page 519: Telnet Command: Ip6 Ntp
It means to clear a filter rule’s statistics. It means to clear IP filter’s gross statistics. > ipf view -V -c -d ipf: IP Filter: v3.3.1 (1824) Kernel: IP Filter: v3.3.1 Running: yes Log Flags: 0x80947278 = nonip Default: pass all, Logging: available Vigor2760 Series User’s Guide...
Page 520: Telnet Command: Ipf Set
It means to accept large incoming fragmented UDP or ICMP packets. -E [VALUE] It means to set the maximum count for session limitation. -F [VALUE] It means to configure the load-balance policy. -Q [VALUE] It means to set the QoS class. Vigor2760 Series User’s Guide...
Page 521: Telnet Command: Ipf Rule
Such word means Filter Set, range form 1~12. Such word means Filter Rule, range from 1~7. <Command><parameter The following lists all of the available commands with > parameters. It means to enable or disable the rule setting. 0- disable Vigor2760 Series User’s Guide...
Page 522 1" means the first destination IP group profile. -S o:g <obj> It means to specify Service Type object and IP group. o – indicates “object”. g – indicates “group” <obj> – indicates index number of object or index number of Vigor2760 Series User’s Guide...
Page 523 <index> – Available settings range from 0 ~ 8. “0” means no profile will be applied. It means to set code page. Different number represents different code page. 0. None 1. ANSI(1250)-Central Europe 2. ANSI(1251)-Cyrillic 3. ANSI(1252)-Latin I 4. ANSI(1253)-Greek 5. ANSI(1254)-Turkish Vigor2760 Series User’s Guide...
Page 524 : Block Immediately Branch to Other Filter Set: None Max Sessions Limit : 32000 Current Sessions Mac Bind IP : Non-Strict Qos Class : None APP Enforcement : None URL Content Filter : None Load-Balance policy : Auto-select Vigor2760 Series User’s Guide...
Page 525 : Disable ------------------------------------------------------------------ ---- CodePage : ANSI(1252)-Latin I Window size : 65535 Session timeout : 1440 DrayTek Banner : Enable ------------------------------------------------------------------ Strict Security Checking [ ]APP Enforcement Vigor2760 Series User’s Guide...
Page 526: Telnet Command: Ipf Flowtrack
53 ,ifno=0 REPLY >> 8.8.8.8: 53 -> 192.168.1.11:15073 ,ifno=3 proto=17, age=93025100(2000), flag=203 ORIGIN>> 192.168.1.11: 7247 -> 8.8.8.8: 53 ,ifno=0 REPLY >> 8.8.8.8: 53 -> 192.168.1.11: 7247 ,ifno=3 proto=17, age=93020100(7000), flag=203 End to show the flowtrack sessions state Vigor2760 Series User’s Guide...
Page 527 25:36:49.580 ---->DHCP (WAN-5) Len = 548XID = 0x7880fdd4 Client IP = 0.0.0.0 Your IP = 0.0.0.0 Next server IP = 0.0.0.0 Relay agent IP = 0.0.0.0 25:36:57.580 ---->DHCP (WAN-5) Len = 548XID = 0x7880fdd4 Client IP = 0.0.0.0 Your IP = 0.0.0.0 Vigor2760 Series User’s Guide...
Page 528: Telnet Command: Mngt Ftpport
It means to type the number for HTTPS port. The default setting is 443. > mngt httpsport 443 % Set web server port to 443 done. This command allows users to set telnet port for management. mngt telnetport [Telnet port] Vigor2760 Series User’s Guide...
Page 529: Telnet Command: Mngt Sshport
It means to type the number for telnet port. The default setting is 23. > mngt telnetport 23 % Set Telnet server port to 23 done. This command allows users to set SSH port for management. Vigor2760 Series User’s Guide...
Page 530: Telnet Command: Mngt Ftpserver
Parameter Description All PING packets will be forwarded from LAN PC to Internet. All PING packets will be blocked from LAN PC to Internet. It means to display a log of ping action, including source viewlog Vigor2760 Series User’s Guide...
Page 531 MAC and source IP. clearlog It means to clear the log of ping action. > mngt noping off No Ping Packet Out is OFF!! Vigor2760 Series User’s Guide...
Page 532: Telnet Command: Mngt Defenseworm
[status] mngt rmtcfg [enable] mngt rmtcfg [disable] mngt rmtcfg [http/https/ftp/telnet/ssh/tr069] [on/off] Parameter Description status It means to display current setting for your reference. enable It means to allow the system administrators to login from the Internet. Vigor2760 Series User’s Guide...
Page 533: Telnet Command: Mngt Echoicmp
Parameter Description list It can display current setting for your reference. It means adding a new entry. index It means to specify the number of the entry. ip addr It means to specify an IP address. Vigor2760 Series User’s Guide...
Page 534: Telnet Command: Mngt Snmp
-T <seconds> It means to set the trap timeout <0~999>. It means to list SNMP setting. > mngt snmp -e 1 -g draytek -s DK -m 192.168.1.1 -t trapcom -n 10.20.3.40 -T 88 SNMP Agent Turn on!!! Get Community set to draytek Set Community set to DK Manager Host IP set to 192.168.1.1...
Page 535: Telnet Command: Msubnet Switch
Type the private IP address for the specified LAN interface. > msubnet addr 2 192.168.5.1 % Set LAN2 subnet IP address done !!! This setting will take effect after rebooting. Please use "sys reboot" command to reboot the router. Vigor2760 Series User’s Guide...
Page 536: Telnet Command: Msubnet Nmask
% Dhcp Gateway: 0.0.0.0, Start IP: 0.0.0.10, Pool Count: 50 This command is used to enable the DHCP server for the specified LAN interface. msubnet dhcps [2][On/Off] Parameter Description It means LAN interface. 2=LAN2 On means enabling the DHCP server for the specified LAN On/Off Vigor2760 Series User’s Guide...
Page 537: Telnet Command: Msubnet Nat
This command is used to configure an IP address as the gateway used for subnet. msubnet gateway [2] [Gateway IP] Parameter Description It means LAN interface. 2=LAN2 Specify an IP address as the gateway IP. Gateway IP Vigor2760 Series User’s Guide...
Page 538: Telnet Command: Msubnet Ipcnt
On – It means Off - It means > msubnet talk 1 2 on % Enable routing between LAN1 and LAN2 This setting will take effect after rebooting. Please use "sys reboot" command to reboot the router. Vigor2760 Series User’s Guide...
Page 539: Telnet Command: Msubnet Startip
This setting will take effect after rebooting. Please use "sys reboot" command to reboot the router. This command is used to specify the type for node which is required by DHCP option. msubnet nodetype [2][count] Parameter Description It means LAN interface. Vigor2760 Series User’s Guide...
Page 540: Telnet Command: Msubnet Primwins
Type the IP address as the WINS IP. > msubnet primWINS 2 192.168.3.5 %Set LAN2 Dhcp Primary WINS IP done !!! This command is used to configure secondary WINS server. msubnet secWINS [2] [WINS IP] Parameter Description It means LAN interface. 2=LAN2 Vigor2760 Series User’s Guide...
Page 541: Telnet Command: Msubnet Tftp
Available value ranges from 1000 to 1496 (bytes). The default value is 1500. msubnet mtu LAN2 1410 > Set LAN2 subnet mtu as 1410 This command is used to create an IP object profile. object ip obj setdefault Vigor2760 Series User’s Guide...
Page 542 Type an IP address. [END/MASK_IP] Type an IP address (different with START_IP) as the end IP address. > object ip obj 1 -n marketing > object ip obj 1 -a 1 192.168.1.45 > object ip obj 1 -v Vigor2760 Series User’s Guide...
Page 543: Telnet Command: Object Ip Grp
:object ip grp 3 -a 1 2 3 4 5 The IP object profiles with index number 1,2,3,4 and 5 will be group under such profile. > object ip grp 2 -n First IP Group Profile 2 Name :[First] Interface:[Any] Included ip object index: [0:][0] Vigor2760 Series User’s Guide...
Page 544 [6:][0] [7:][0] > object ip grp 2 -i 1 > object ip grp 2 -a 1 2 IP Group Profile 2 Name :[First] Interface:[Lan] Included ip object index: [0:][1] [1:][2] [2:][0] [3:][0] [4:][0] [5:][0] [6:][0] [7:][0] Vigor2760 Series User’s Guide...
Page 545: Telnet Command: Object Service Obj
2=larger(>), the port number greater than this value is available.. 3=less(<), the port number less than this value is available for Vigor2760 Series User’s Guide...
Page 546: Telnet Command: Object Service Grp
It means to define a name for the service group. NAME: Type a name with less than 15 characters. Example: object service grp 8 -n bruce -a SER_OBJ_INDEX It means to specify service object profiles for the group profile. Vigor2760 Series User’s Guide...
Page 547: Telnet Command: Object Kw
It means to return to default settings for all profiles. show PAGE It means to show the contents of the specified profile. PAGE: type the page number. show It means to show the contents for all of the profiles. Vigor2760 Series User’s Guide...
Page 548: Telnet Command: Object Fe
It means to view the information of the specified file extension object profile. -n NAME It means to define a name for the file extension object profile. NAME: Type a name with less than 15 characters. Vigor2760 Series User’s Guide...
Page 549 -------------------------------------------------------------------------- ----- Audio category: [v].aac [v].aiff [v].au [v].mp3 [v].m4a [v].m4p [v].ogg [v].ra [v].ram [v].vox [v].wav [v].wma -------------------------------------------------------------------------- ----- Java category: [ ].class [ ].jad [ ].jar [ ].jav [ ].java [ ].jcm [ ].js [ ].jse Vigor2760 Series User’s Guide...
Page 550 [ ].bzip2 [ ].bz2 [ ].cab [ ].gz [ ].gzip [ ].rar [ ].sit [ ].zip -------------------------------------------------------------------------- ----- Executation category: [ ].bas [ ].bat [ ].com [ ].exe [ ].inf [ ].pif [ ].reg [ ].scr Vigor2760 Series User’s Guide...
Page 551: Telnet Command: Port
<sec>: Type a number to set the UDP session timeout. -i <sec> It means “IGMP” protocol. <sec>: Type a number to set the IGMP session timeout. -w <sec> It means “TCP WWW” protocol. <sec>: Type a number to set the TCP WWW session Vigor2760 Series User’s Guide...
Page 552: Telnet Command: Qos Setup
It means to set outbound bandwidth in kbps (Ethernet WAN only). The available setting is from 1 to 100000. -r <index:ratio> It means to set ratio for class index, in %. -u <mode> It means to enable bandwidth control for UDP. 0: disable 1: enable Vigor2760 Series User’s Guide...
Page 553 WAN1 class 3 ratio set to 20 WAN1 udp bandwidth control set to enable WAN1 udp bandwidth limit ratio set to 50 WAN1 Outbound TCP ACK Prioritizel set to enable QoS WAN1 set complete; restart QoS > Vigor2760 Series User’s Guide...
Page 554: Telnet Command: Qos Class
– It means the subnet address with start IP address. Please type the subnet and the IP address, for example, “-l 172.16.3.9:255.255.0.0”.0 any – It means Any address. Simple type “-l” to specify any address for this command. -p <DSCP id> Specify the ID. Vigor2760 Series User’s Guide...
Page 555: Telnet Command: Qos Type
Show the rule in the specified class. It means that you can type in several commands in one line. […] > qos class -c 2 -n draytek -a -m 1 -l 192.168.1.50:192.168.1.80 Following setting will set in the class2 class 2 name set to draytek...
Page 556: Telnet Command: Quit
> qos type -a draytek -t 6 -p 510:1330 service name set to draytek service type set to 6:TCP Port type set to Range Service Port set to 510 ~ 1330 > This command can exit the telnet command screen.
Page 557: Telnet Command: Show Dmz
WAN1 DMZ mapping status: Index Status WAN1 aux IP Private IP ---------------------------------------------------- Disable 172.16.3.221 Disable 192.168.1.65 This command displays current status of DNS setting > show dns Domain name server settings: Primary DNS: [Not set] Secondary DNS: [Not set] Vigor2760 Series User’s Guide...
Page 558: Telnet Command: Show Openport
['q': Quit, 'Enter': New Lines, 'Space Bar': Next Page] This command displays the table of NAT Active Sessions. > show portmap -------------------------------------------------------------------------- Private_IP:Port Pseudo_IP:Port Peer_IP:Port [Timeout/Protocol/Flag] -------------------------------------------------------------------------- This command displays the reuse time of NAT session. Vigor2760 Series User’s Guide...
Page 559: Telnet Command: Show Session
This command displays current status of ADSL. > Vigor> show adsl --------------------------- ATU-R Info (hw: annex A, f/w: annex A) ----------- Running Mode T1.413 State : TRAINING DS Actual Rate 0 bps US Actual Rate 0 bps Vigor2760 Series User’s Guide...
Page 560: Telnet Command: Show Statistic
This command allows users to configure DHCP server for second subnet. srv dhcp public start [IP address] srv dhcp public cnt [IP counts] srv dhcp public status srv dhcp public add [MAC Addr XX-XX-XX-XX-XX-XX] srv dhcp public del [MAC Addr XX-XX-XX-XX-XX-XX/all/ALL] Vigor2760 Series User’s Guide...
Page 561: Telnet Command: Srv Dhcp Dns1
It means to display current IP address of DNS 1 for the DHCP server. DNS IP address It means the IP address that you want to use as DNS1. Note: The IP Routed Subnet DNS must be the same as NAT Subnet DNS). Vigor2760 Series User’s Guide...
Page 562: Telnet Command: Srv Dhcp Dns2
Note: The IP Routed Subnet DNS must be the same as NAT Subnet DNS). > srv dhcp dns2 10.1.1.1 % srv dhcp dns2 <DNS IP address> % Now: 10.1.1.1 (IP Routed Subnet dns same as NAT Subnet dns) Vigor2760 Series User’s Guide...
Page 563: Telnet Command: Srv Dhcp Frcdnsmanl
It means to display current gateway that you can use. It means to specify a gateway address used for DHCP server. Gateway IP > srv dhcp gateway 192.168.2.1 This setting will take effect after rebooting. Please use "sys reboot" command to reboot the router. Vigor2760 Series User’s Guide...
Page 564: Telnet Command: Srv Dhcp Ipcnt
1 or 2 specified here. > srv dhcp relay servip 192.168.1.46 > srv dhcp relay subnet 2 > srv dhcp relay servip ? % srv dhcp relay servip <server ip> % Now: 192.168.1.46 Vigor2760 Series User’s Guide...
Page 565: Telnet Command: Srv Dhcp Startip
This command can display general information for the DHCP server, such as IP address, MAC address, leased time, host ID and so on. > srv dhcp status DHCP server: Relay Agent Default gateway: 192.168.1.1 Index IP Address MAC Address Leased Time HOST ID 192.168.1.113 00-05-5D-E4-D8-EE 17:20:08 A1000351 Vigor2760 Series User’s Guide...
Page 566: Telnet Command: Srv Dhcp Leasetime
It means to specify a type for node. 1. B-node 2. P-node 4. M-node 8. H-node > srv dhcp nodetype 1 > srv dhcp nodetype ? %% srv dhcp nodetype <count> %% 1. B-node 2. P-node 4. M-node 8. H-node % Now: 1 Vigor2760 Series User’s Guide...
Page 567: Telnet Command: Srv Dhcp Primwins
It means to remove the IP address settings of second WINS server. > srv dhcp secWINS 192.168.1.180 > srv dhcp secWINS ? %% srv dhcp secWINS <WINS IP address> %% srv dhcp secWINS clear % Now: 192.168.1.180 Vigor2760 Series User’s Guide...
Page 568: Telnet Command: Srv Dhcp Expired_Recycleip
This command can set the time to check if the IP address can be assigned again by DHCP server or not. Note: We can provide prompt support (support@draytek.com) if you refer to the telnet command and have any queries. srv dhcp expRecycleIP <sec time>...
Page 569 It means the index number of the option value. > srv dhcp option -e 1 -c 18 -v /path > srv dhcp option -l % state idx interface opt type data % enable 1 ALL LAN 18 ASCII /path Vigor2760 Series User’s Guide...
Page 570: Telnet Command: Srv Nat Dmz
This command allows users to enable or disable IPSec ESP tunnel passthrough and IKE source port (500) preservation. Srv nat ipsecpass [options] Parameter Description [options] The available commands with parameters are listed below. It means to enable IPSec ESP tunnel passthrough and IKE source port (500) preservation. Vigor2760 Series User’s Guide...
Page 571 The range is from 0 to 65535. -e<end port> It means to specify the ending port number of the service offered by the local host. The range is from 0 to 65535. It means to display current settings. Vigor2760 Series User’s Guide...
Page 572 It means to add a new port redirection table with an index number. Available index number is from 1 to 10. serv name It means to type one name as service name. proto It means to specify TCP or UDP as the protocol. Vigor2760 Series User’s Guide...
Page 573 Protocol Public Port Private IP Private Port ifno game 192.168.1.11 Protocol: 0 = Disable, 6 = TCP, 17 = UDP Telnet Command: srv nat status This command allows users to view NAT Port Redirection Running Table. > srv nat status Vigor2760 Series User’s Guide...
Page 574: Telnet Command: Sys Cfg
192.168.1.96 R:Port Redirection, O:Open Ports, D:DMZ This command reset the router with factory default settings. When a user types this command, all the configuration will be reset to default setting. sys cfg default sys cfg status Vigor2760 Series User’s Guide...
Page 575: Telnet Command: Sys Cmdlog
> sys ftpd on % sys ftpd turn on !!! This command can set and remove the domain name of the system when DHCP mode is selected for WAN. sys domainname [wan1/wan2] [Domain Name Suffix] sys domainname [wan1/wan2] Vigor2760 Series User’s Guide...
Page 576: Telnet Command: Sys Iface
Interface 6 Ethernet: Status: DOWN IP Address: 0.0.0.0 Netmask: 0x00000000 MAC: 00-50-7F-00-00-04 Interface 7 Ethernet: Status: DOWN IP Address: 0.0.0.0 Netmask: 0x00000000 MAC: 00-50-7F-00-00-05 Interface 8 Ethernet: Status: DOWN IP Address: 0.0.0.0 Netmask: 0x00000000 MAC: 00-50-7F-00-00-06 Vigor2760 Series User’s Guide...
Page 577 Interface 9 Ethernet: Status: DOWN IP Address: 0.0.0.0 Netmask: 0x00000000 MAC: 00-50-7F-00-00-07 --- MORE --- ['q': Quit, 'Enter': New Lines, 'Space Bar': Next Page] > Vigor2760 Series User’s Guide...
Page 578: Telnet Command: Sys Name
Description ASCII string It means the password for administrator. The maximum character that you can set is 23. > sys passwd admin123 > This command allows users to restart the router immediately. > sys reboot > Vigor2760 Series User’s Guide...
Page 579: Telnet Command: Sys Autoreboot
This command can turn on TFTP server for upgrading the firmware. > sys tftpd % TFTP server enabled !!! This command can display current code and wireless region of this device. > sys cc Country Code : 0x 0 [International] Wireless Region Code: 0x30 > Vigor2760 Series User’s Guide...
Page 580: Telnet Command: Sys Version
# of flowstate = 12000 # of lost by siganture = 0 # of lost by list = 0 This command can turn on or turn off polling buffer for the router. sys pollbuf [on] sys pollbuf [off] Parameter Description Vigor2760 Series User’s Guide...
Page 581: Telnet Command: Sys Britask
[on/off] sys tr069 save sys tr069 inform [event code] sys tr069 port [port num] sys tr069 cert_auth [on/off] Parameter Description get [parm] [option] It means to get parameters for tr-069. option=<nextlevel>: only gets nextlevel for Vigor2760 Series User’s Guide...
Page 582 > sys tr069 get Int. nextlevel Total number of parameter is 24 Total content length of parameter is 915 InternetGatewayDevice.LANDeviceNumberOfEntries InternetGatewayDevice.WANDeviceNumberOfEntries InternetGatewayDevice.DeviceInfo. InternetGatewayDevice.ManagementServer. InternetGatewayDevice.Time. InternetGatewayDevice.Layer3Forwarding. InternetGatewayDevice.LANDevice. InternetGatewayDevice.WANDevice. InternetGatewayDevice.Services. InternetGatewayDevice.X_00507F_InternetAcc. InternetGatewayDevice.X_00507F_LAN. InternetGatewayDevice.X_00507F_NAT. InternetGatewayDevice.X_00507F_Firewall. InternetGatewayDevice.X_00507F_Bandwidth. Vigor2760 Series User’s Guide...
Page 583: Telnet Command: Sys Sip_Alg
[set/reg/qry] sys license dev_chg sys license dev_key Parameter Description licmsg It means to display license message. licauth It means the license authentication time setting. Vigor2760 Series User’s Guide...
Page 584: Telnet Command: Sys Diag_Log
[on/off] It is used to specify the function of the log. Supported features include SYS and DSL (Case-Insensitive). Default setting is “on” for “DSL”. It means the dump log buffer. Vigor2760 Series User’s Guide...
Page 585 [DSL] >> nXtseA=0d, nXtseB=00, nXtseV=07, nFwFeatures=5 0:00:05 [DSL] >> nHsToneGroupMode=0, nHsToneGroup=106, nToneSet=43, nCamState 0:00:05 [DSL] Line state has changed: 000000FF -> 00000100 0:00:05 [DSL] Line state has changed: 00000100 -> 00000200 0:00:05 [DSL] Status was switched: Init(5) to Train(6) Vigor2760 Series User’s Guide...
Page 586: Telnet Command: Testmail
PortMapLeaseDuration >>0<<, PortMapEnabled >>0<< Ftp Example [MICROSOFT] ((1)) InternalClient >>0.0.0.0<<, RemoteHost >>0.0.0.0<< InternalPort >>0<<, ExternalPort >>0<< PortMapProtocol >><NULL><< The tmpvirtual server index >>0<< PortMapLeaseDuration >>0<<, PortMapEnabled >>0<< PortMapProtocol >><NULL><< The tmpvirtual server index >>0<< PortMapLeaseDuration >>0<<, PortMapEnabled >>0<< Vigor2760 Series User’s Guide...
Page 587: Telnet Command: Upnp Service
This command can show all UPnP services subscribed. > upnp on UPNP start. > upnp subscribe Vigor> upnp subscribe >>>> (1) serviceType urn:schemas-microsoft-com:service:OSInfo:1 ----- Subscribtion1 ------- sid = 7a2bbdd0-0047-4fc8-b870-4597b34da7fb eventKey =1, ToSendEventKey = 1 expireTime =6926 Vigor2760 Series User’s Guide...
Page 588: Telnet Command: Upnp Tmpvs
>>0<< The protocol >>TCP<< time >>0<< ((1)) real_addr >>0.0.0.0<<, pseudo_addr >>0.0.0.0<< real_port >>0<<, pseudo_port >>0<< hit_portmap_index >>0<< The protocol >>0<< time >>0<< -- MORE -- ['q': Quit, 'Enter': New Lines, 'Space Bar': Next Page] --- Vigor2760 Series User’s Guide...
Page 589: Telnet Command: Upnp Wan
This command can disable vigor bridge function. > vigbrg off %Disable Vigor Bridge Function! This command can show whether the Vigor Bridge Function is enabled or disabled. > vigbrg status %Vigor Bridge Function is enable! %Wan1 management is disable! Vigor2760 Series User’s Guide...
Page 590: Telnet Command: Vigbrg Cfgip
[list index] aggressive [g1/g2] vpn l2lset [list index]pfs [on/off] vpn l2lset [list index] phase1[lifetime] vpn l2lset [list index] phase2[lifetime] Parameter Description It means the index number of L2L (LAN to LAN) profile. list index Vigor2760 Series User’s Guide...
Page 591: Telnet Command: Vpn L2Ldrop
It means the index number of the profile. <on/off> It means to enable or disable the profile. on – Enable. off – Disable. motp <on/off> It means to enable or disable the authentication with mOTP function. on – Enable. off – Disable. Vigor2760 Series User’s Guide...
Page 592: Telnet Command: Vpn Subnet
Profile Name: ??? Status: Active Mobile OTP: Enabled PIN: 1234 Secret: e759bb6f0e94c7ab4fe6 Idle Timeout: 300 sec This command allows users to specify a subnet selection for the specified remote dial-in VPN profile. vpn subnet <index> <1/2> Parameter Description Vigor2760 Series User’s Guide...
Page 593: Telnet Command: Vpn Setup
It means the IP address to dial to. <key> It means the value of IPsec Pre-Shared Key. It means the remote network IP and the mask. <nip> <nmask> e.g., vpn setup 1 name1 ipsec_out 1.2.3.4 1234 192.168.1.0 255.255.255.0 Vigor2760 Series User’s Guide...
Page 594: Telnet Command: Vpn Option
% Dial from : 1.2.3.4 % Remote NEtwork IP : 192.168.1.0 % Remote NEtwork Mask : 255.255.255.0 > This command allows users to configure settings for LAN to LAN profile. vpn option <index> <cmd1>=<param1> [<cmd2>=<para2> | ... ] Vigor2760 Series User’s Guide...
Page 595 For Dial-Out Settings ctype It means “Type of Server I am calling”. “ctype=t” means PPTP. “ctype=s” means IPSec. “ctype= l” means L2TP(IPSec Policy None). “ctype= l1” means L2TP(IPSec Policy Nice to Have). “ctype= l2” means L2TP(IPSec Policy Must). Vigor2760 Series User’s Guide...
Page 596 It means Server IP/Host Name for VPN (such as draytek.com or 123.45.67.89). ltype It means Link Type. “ltype=0” means “Disable”. “ltype=1” means “64kbps”. “ltype=2” means “128kbps”. “ltype=3” means “BOD”. oname It means Dial-Out Username. “oname=admin” means to set Username = admin.
Page 597 Type “off” means any remote IP is allowed to dial in. peerid It means the peer ID for Remote VPN Gateway. Type “draytek” means the word is used as local ID. iname It means Dial-in Username. “iname=admin” means to set username as “admin”.
Page 598: Telnet Command: Vpn Mroute
It means to list configuration of the specified profile. It means to list common settings of the specified profile. It means to list dial-out settings of the specified profile. It means to list dial-in settings of the specified profile. Vigor2760 Series User’s Guide...
Page 599: Telnet Command: Vpn Remote
% Netbios Naming Packet : Pass % Call Direction : Both % Idle Timeout : 300 % PING to keep alive : off > This command allows users to enable or disable PPTP/IPSec/L2TP VPN service. vpn remote [PPTP/IPSec/L2TP] [on/off] Vigor2760 Series User’s Guide...
Page 600: Telnet Command: Vpn 2Ndsubnet
The index number of the profile. <Block/Pass> Pass – Have an inquiry for data transmission between the hosts located on both sides of VPN Tunnel while connecting. Block – When there is conflict occurred between the hosts on Vigor2760 Series User’s Guide...
Page 601: Telnet Command: Vpn Mss
PPTP = 1400 L2TP = 1360 IPSec = 1360 L2TP over IPSec = 1360 >vpn mss show VPN TCP maximum segment size (MSS) : PPTP = 1400 L2TP = 1360 IPSec = 1360 L2TP over IPSec = 1360 Vigor2760 Series User’s Guide...
Page 602: Telnet Command: Vpn Ike
This command allows users to determine if the packets coming from the second subnet passing through current used VPN tunnel. vpn pass2nd[on] vpn pass2nd [off] Parameter Description on – the packets can pass through NAT. on/off off – the packets cannot pass through NAT. Vigor2760 Series User’s Guide...
Page 603: Telnet Command: Vpn Pass2Nat
1400 to 1600. wan ppp_mru 1 ? > % Now: 1492 > wan ppp_mru 1 1490 > > wan ppp_mru 1 ? % Now: 1490 > wan ppp_mru 1 1492 > wan ppp_mru 1 ? Vigor2760 Series User’s Guide...
Page 604: Telnet Command: Wan Mtu
DF_check [on] wan DF_check [off] Parameter Description It means to enable or disable DF. on/off > wan DF_check on %DF bit check enable! This command allows you to disable WAN connection. > wan disable WAN %WAN disabled. Vigor2760 Series User’s Guide...
Page 605: Telnet Command: Wan Forward
IP=---, GW IP=--- TX Packets=0, TX Rate(Bps)=0, RX Packets=0, RX Rate(Bps)=0 PVC_WAN4: Offline, stall=N Mode: ---, Up Time=00:00:00 IP=---, GW IP=--- TX Packets=0, TX Rate(Bps)=0, RX Packets=0, RX Rate(Bps)=0 PVC_WAN5: Offline, stall=N Mode: ---, Up Time=00:00:00 Vigor2760 Series User’s Guide...
Page 606: Telnet Command: Wan Vdsl
[wan1]target [ip addr] wan detect [wan1]ttl [1-255] wan detect status Parameter Description It means to enable ping detection. The IP address of the target shall be set. It means to enable ARP detection (default). Vigor2760 Series User’s Guide...
Page 607: Telnet Command: Wan Lb
Description It means to specify which WAN will be applied with load wan1/wan2 balance. It means to make WAN1/WAN2 as the member of load balance. It means to cancel WAN1/WAN2 as the member of load balance. Vigor2760 Series User’s Guide...
Page 608: Telnet Command: Wan Mvlan
PVC 7 will map to LAN port 2/3/4 in bridge mode;, service type is Normal. No tag added. > wan mvlan 7 on 0 p2 p3 p4 PVC Bridge Service Type Priority ----------------------------------------------------------------- Normal 0(OFF) > Vigor2760 Series User’s Guide...
Page 609: Telnet Command: Wan Multifno
% Configured channel 5 uplink to WAN1 > wan multifno status % Channel 3 uplink ifno: 3 % Channel 4 uplink ifno: 3 % Channel 5 uplink ifno: 3 % Channel 6 uplink ifno: 3 % Channel 7 uplink ifno: 3 > Vigor2760 Series User’s Guide...
Page 610: Telnet Command: Wl Acl
It means to clean all access control setting. > wl acl showmode ssid1: none ssid2: none ssid3: none ssid4: none > wl acl add 00-50-70-ff-12-70 Set Done !! > wl acl add 00-50-70-ff-12-70 ssid1 ssid2 isolate Set Done !! > wl acl show Vigor2760 Series User’s Guide...
Page 611: Telnet Command: Wl Config
Most modern wireless network uses short preamble with 56 bit sync field instead of long preamble with 128 bit sync field. However, some original 11b wireless network devices only support long preamble. 0: disable to use long preamble. 1: enable to use long preamble. Vigor2760 Series User’s Guide...
Page 612 It means to isolate the wireless connection for LAN and/or member] Member. lan – It can make the wireless clients (stations) with remote-dial and LAN to LAN users not accessing for each other. member – It can make the wireless clients (stations) with the Vigor2760 Series User’s Guide...
Page 613: Telnet Command: Wl Set
Access Point and Station (in wireless client) invoke this function at the same time. 0: disable the function. 1: enable the function. > wl set MKT 2 on % New Wlan Setting is: Vigor2760 Series User’s Guide...
Page 614: Telnet Command: Wl Act
This command allows users to set WMM for wireless connection. It defines the priority levels for four access categories derived from 802.1d (prioritization tabs). wl wmm ap QueIdx Aifsn Cwmin Cwmax Txop ACM wl wmm bss QueIdx Aifsn Cwmin Cwmax Txop ACM Vigor2760 Series User’s Guide...
Page 615 > wl wmm enable 1 0 1 0 WMM_SSID0 =1, WMM_SSID1 =0,WMM_SSID2 =1,WMM_SSID3 =0 > wl wmm show Enable WMM: SSID0 =1, SSID1 =0,SSID2 =1,SSID3 =0 APSD=0 QueIdx=0: APAifsn=3,APCwmin=4,APCwmax=6, APTxop=0,APACM=0 QueIdx=1: APAifsn=7,APCwmin=4,APCwmax=10, APTxop=0,APACM=0 QueIdx=2: APAifsn=1,APCwmin=3,APCwmax=4, APTxop=94,APACM=0 QueIdx=3: APAifsn=1,APCwmin=2,APCwmax=3, APTxop=47,APACM=0 Vigor2760 Series User’s Guide...
Page 616: Telnet Command: Wl Ht
The value you can type ranges from 0-3. 0: 2T3R 1: 2T2R 2: 1T2R 3: 1T1R wl ht greenfield value The value you can type is 0 (for mixed mode) and 1 (for green field). Vigor2760 Series User’s Guide...
Page 617: Telnet Command: Wl Restart
> wl btnctl 1 Enable wireless botton control Current wireless botton control is on > This command is used to configure parameters related to wireless RF hardware. At present, it is not allowed for end user to operate. Vigor2760 Series User’s Guide...
Page 618: Telnet Command: Wan Vlan
LAN host by using IP address, be sure that that IP address has been bound with the MAC address (IP BindMAC). on/off/any It means to enable or disable the function of WOL from WAN. on: enable off: disable Vigor2760 Series User’s Guide...
Page 619 WoL packet. ip address - It means the WAN IP address. mask - It means the mask of the IP address. > wol fromWan on > wol fromWan_Setting 1 192.168.1.45 255.255.255.0 > Vigor2760 Series User’s Guide...

Draytek vigor2760 series User Manual

Quick Links

Related Manuals for Draytek vigor2760 series

Summary of Contents for Draytek vigor2760 series
