Printhead Assembly Removal - Lexmark X651de Service Manual

7462
4. Remove the print cartridge ID connector assembly.
5. Disconnect the connection (B) from the print cartridge ID connector assembly.

Printhead assembly removal

WARNING: When replacing the printhead assembly, ensure that the printhead skew is properly adjusted, or
print quality issues will occur. See
1. Remove the laser cover. See
page 4-103
2. Remove the six screws (A) securing the metal cover to the machine.
A
3. Remove the metal cover.
Service Manual
4-32
B
"Polygon printhead mechanical registration adjustment" on page
"Laser cover removal (models X651, X652, X654, and X656)" on
or
"Laser cover removal (model X658)" on page
A
4-101.
Previous
Next
Go Back
4-2.
