Page 1: Card For Ipds And Scs/Tne - Scs/Tne Emulation User's Guide Getting Started
Card for IPDS and SCS/TNe - SCS/TNe Emulation User’s Guide Getting Started SCS/TNe in a Thank you for purchasing the Card for IPDS and SCS/TNe. The card provides high quality IBM host connectivity print output. environment With the appropriate print server and host software, your printer or Multifunction Product (MFP) becomes an IBM host workstation printer capable of printing IPDS or SCS documents from an iSeries, AS/400, or mainframe.
Page 2: Equipment Requirements And Specifications
Equipment Supported Products Requirements With the appropriate option card installed, the following printers and Muiltifunction Products (MFPs) are supported: Specifications Lexmark C734, C736 • Lexmark E460dn, E460dw, E462dtn • Lexmark T650, T652 • Lexmark T654 • Lexmark T656dne • Lexmark W850 •...
Page 3 Standard Network for connection to an Ethernet LAN (also • called STD Net). MarkNet internal print server (Ethernet). • Lexmark wireless internal print server. • If you need to update your Standard Network or MarkNet firmware, refer to “Support” on page For further information on requirements and specifications, see the appendix starting on page 277.
Page 4: Support
If you need to update your Standard Network, MarkNet internal print server, or SCS/TNe firmware, go to http://support.lexmark.com. You may also contact your point of purchase or your local Lexmark office. Support: Customer Support...
Page 5: Important Configuration Basics
Important Configuration Basics Introduction SCS/TNe MENU options settings can be changed and saved in three ways: Use the control panel (“Understanding the Control • MPORTANT Unless otherwise noted, the term printer refers to printers and MFPs, and the term Panel” on page 10 - which also contains all basic control panel refers to operator panels and touch information on types of settings).
Page 6: What Are "Idb Options", "Idb Events Etc
All of these descriptions include the available options and their val- ues. What are “IDB On many of the descriptions you may notice the use of terms like Options”, “IDB IDB events, IDB options, IDB values, IDB User Parameters, IDB events etc.? Language, etc.
Page 7 Settings you choose in the SCS print job may override the user MPORTANT Restoring the factory defaults using the printer default settings displayed in the printer operator panel. menu Restore Default option does not affect the SCS/TNe MENU settings. This guide discusses setting up the SCS/TNe Emulation and chang- ing the SCS/TNe Emulation settings.
Page 8: Understanding The Control Panel
Understanding the Control Panel Introduction This chapter introduces the SCS/TNe MENU options as well as illustrating how how the control panel works. Printers and MFPs dif- fer, so both operator panels on printers and touch screens on MFPs are illustrated here. If you are familiar with the use of the control panel, skip this chapter, but we recommend familiarizing yourself with the contents of “Remote Configuration Using a Browser”...
Page 9: Printer Operator Panel
Printer operator Access the SCS/TNe Emulation options and settings from the oper- panel ator panel SCS/TNe MENU. To reach the menu: Accessing the SCS/TNe From a Ready status, press the MENU button . on the menu operator panel. This opens the menu index in the operator panel’s screen.
Page 10: Selecting A New Value As A Setting
When you select an option, you will always be alowed to scroll through the list of values presented. Numerical entries can be done either by scrolling or by using the numeric pad. Several examples of how to use the operator panel to select and store new values are shown below.
Page 11 In this example, you are going to change the Country Code for TN3270. Navigate to TN3270E SETUP. Press the Select button. SCS/TNe MENU COMMON SETUP TN3270E SETUP TN5250E SETUP Navigate to SCS OPTIONS. Press the Select button. TN 3270 SETUP NETWORK SCS OPTIONS TEST OPTIONS...
Page 12 Navigate to MISC SETTINGS. Press the Select button. SCS OPTIONS MISC SETTINGS Cor APO Sett TEST OPTIONS Navigate to the Country Code option. Press the Select button. MISC SETTINGS Format Ctrl Sup Country Code Skip Blank Page Understanding the Operator Panel: Printer operator panel...
Page 13 The displays shows the the currently active setting (in this example English (US). The currently active setting is marked with an asterisk *, and in this example, it just happens to be factory default. If you want to change the setting, for example to Fin/Swe, use the navigation buttons to move down through the list.
Page 14 When the setting is saved, the display will revert to the previous menu level. MISC SETTINGS Format Ctrl Sup Country Code Skip Blank Page If you want to check the value of a setting, press the Select button again. You will see an asterisk * beside Fin/Swe to show it is the current active setting.
Page 15 Changing a Text String The method for changing a text string is actually the same as that for selecting a value, because you select the letters from pre-pro- grammed lists. What is special is that the value you select consists of several fields.
Page 16 Changing a Numerical If you choose a menu item that has a numerical value, you can usu- ally choose between scrolling just as you would to select any value, Setting or using the numerical pad. If the setting has more than one field, navigate as shown in “Chang- ing a Text String”...
Page 17: Mfp Touch Screen
MFP Touch Access the SCS/TNe Emulation options and settings from the oper- Screen ator panel SCS/TNe MENU. To reach the menu: Accessing the SCS/TNe Make sure that the printer is on and the Ready message menu appears. Touch the key icon (Menus) on the operator panel Touch to scroll through the main menus...
Page 18 Several examples of how to use the operator panel to select and store new values are shown below. The section “Selecting a New Value as a Setting” on page 20 shows all details, while the following two sections discuss slight differences. User-selected default settings remain in effect until you save new settings or restore the factory defaults.
Page 19 Now you will see a list of options.Touch to scroll to the desired item. In this example locate and touch Country Code. The currently active setting, in this example English (US), is always presented first. Touch to scroll through the settings until you see the item you need. Touch (Submit) to save changes.
Page 20 Select the "abc 123" tab above the keyboard. If you select any other tab, the LU Name will not be recognized by the host. Use the Keyboard to enter the LU Name. Touch Enter (on some MFPs touch Submit) when you have completed the name.
Page 21 Some numerical values contain more than one field. For example, Menus > SCS/TNE Menu > TN3270e Setup > Network Setup > Server Info > IP Address. For these, use the Keyboard as described in “Changing a Text String” on page Understanding the Operator Panel: MFP Touch Screen...
Page 22: Remote Configuration Using A Browser
Remote Configuration Using a Browser Introduction The Card for IPDS and SCS/TNe includes an http user interface. You can use a browser, such as Microsoft Internet Explorer or Netscape, to remotely configure most SCS/TNe settings. The only requirement is that the printers are attached to a LAN using a Stan- dard Network port or MarkNet internal print server.
Page 23: How To Use The Browser Interface
These new option value settings are saved in the printer and will become active when the next SCS/TNe session is started. If new option value settings are submitted during an SCS/TNe session, the new option value settings will not be used until the current SCS/TNe session ends and a new SCS/TNe session is established.
Page 24 If a session has not been disconnected, check to see if jobs are being received on this session. Wait for the jobs to finish printing or end the session from the host. If no jobs are printing, you may need to end and reset the session at the host.
Page 25 The SCS/TNe emulation will attempt to reconnect to the host. Check to be sure that all sessions have been reconnected. Click on each TNxxxx Connection Status menu item to check the status of each session. If all configured sessions have not been established within 90 seconds, you may need to end and reset the sessions at the host and repeat steps 14 - 16.
Page 26: Installation Setup For Mainframe Users
Installation Setup for Mainframe Users Introduction This chapter applies to LAN-attached Mainframe users printing directly or via an SNA Server. (AS/400 and iSeries users refer to “Installation Setup for AS/400 and iSeries Users” on page 55.) Tasks numbered #A are unique for printing directly from a Main- MPORTANT Tasks may be completed in any order but all tasks frame.
Page 27 Mainframe Direct Users SNA Server Users Task 6A - Verifying the Mainframe Connection Task 6B - Verifying the Mainframe/SNA Server Connection Mainframe Installation Setup: Introduction...
Page 28: Task 1A - Configuring The Host
Task 1A - The Mainframe software must support TCP/IP and extended Telnet Configuring the protocols to print SCS jobs to a LAN attached printer. “Mainframe Host Software” on page 279 lists versions which support these protocols. The printer with the SCS/TNe Emulation is defined to the host like a How to define an LU-1 printer in VTAM is normal LU-1 (SCS) printer.
Page 29 Sample Configuration number 2: PU/LU definitions in VTAM VBUILD TYPE=SWNET PSWPG9 ADDR=C9,MAXDATA=1033,MAXOUT=7, PACING=(1,1),IDBLK=O61,SSCPFM=USSSCS, ISTATUS=ACTIVE,IRETRY=YES,IDNUM=B0008, PASSLIM=7,PUTYPE=2,DISCNT=NO,VPACING=0 LCPG90 LOCADDR=2,MODETAB=MT3274P,USSTAB=USB3274B, DLOGMOD=T3274M2,ISTATUS=ACTIVE LCPG91 LOACADDR=3,MODETAB=MTP3816, DLOGMOD=SCS1,ISTATUS=ACTIVE LCPG92 LOACADDR=4,MODETAB=MTP3816, DLOGMOD=SCS1,ISTATUS=ACTIVE LCPG93 LOACADDR=5,MODETAB=MTPRINT, DLOGMOD=SCS,ISTATUS=ACTIVE Mainframe Installation Setup: Task 1A - Configuring the Host...
Page 30 Sample Configuration Number 3: Local Device - Using VTAM LOCAL LU nodes First create a major node in VTAM to define the VTAM LU's (printer or terminal devices) for telnet sessions as follows: VBUILD TYPE=APPL SC0TCP01APPL AUTH=NVPACE, EAS=1, PARSESS=NO, MODETAB=ISTINCLM, SESSLIM=YES IMLU1 APPL AUTH=NVPACE,EAS=1,PARSESS=NO,...
Page 31 Second, define the VTAM printer member (i.e. listed above) IMLU1 to the host print software being used. The following is an example of a TN printer definition defined in VPS print software: DEST=VPSIMLU1, LUNAME=IMLU1, *LUNAME=SNA047, QBUFSIZE=23476 *ALOGMODE=VPSLU1, *ALOGMODE=VPSCOL, *SEPINFO=HPL The asterisk (*) denotes fields that are not required, and therefore have been commented out.
Page 32: Task 1B - Configuring The Host For Printing Via A Sna Server
Task 1B - The printer with the SCS/TNe Emulation is defined to the host like a Configuring the normal LU-1 (SCS) printer. Host for Printing Two sample configurations are shown below. via a SNA Server How to define an LU-1 printer in VTAM is described in IBM's VTAM documentation.
Page 33 Sample Configuration number 2 - PU/LU definitions in VTAM VBUILD TYPE=SWNET PSWPG9 ADDR=C9,MAXDATA=1033,MAXOUT=7, PACING=(1,1),IDBLK=O61,SSCPFM=USSSCS, ISTATUS=ACTIVE,IRETRY=YES,IDNUM=B0008, PASSLIM=7,PUTYPE=2,DISCNT=NO,VPACING=0 LCPG90 LOCADDR=2,MODETAB=MT3274P,USSTAB=USB3274B, DLOGMOD=T3274M2,ISTATUS=ACTIVE LCPG91 LOACADDR=3,MODETAB=MTP3816, DLOGMOD=SCS1,ISTATUS=ACTIVE LCPG92 LOACADDR=4,MODETAB=MTP3816, DLOGMOD=SCS1,ISTATUS=ACTIVE LCPG93 LOACADDR=5,MODETAB=MTPRINT, DLOGMOD=SCS,ISTATUS=ACTIVE Mainframe Installation Setup: Task 1B - Configuring the Host for Printing via a SNA Server...
Page 34: Task 2A - Configuring A Host For Tn3270E Printing
Task 2A - The printer with the SCS/TNe Emulation is defined to the Telnet Configuring a server in much the same way as a display LU. Host For Instead of the LUGROUP and LUMAP commands, the PRTGROUP and TN3270e PRTMAP commands are used. Printing It is important to observe the one-to-one mapping of display LUs to Refer to your system documentation for further...
Page 35 BEGINVTAM PRTGROUP PRINTERS RA3ATPR1..RA3ATPR5 ; printers for specific ; mapping and printer to LU ; association ENDPRTGROUP PRTGROUP PRINTERS RA3ATPR6..RA3ATPR9 ; generic printers ENDPRTGROUP IPGROUP SPECIP 157.184.116.36 ENDIPGROUP PRTMAP PRINTERG SPECIP LUMAP SPECLX SPECIP SPECIFIC PRINTERS; specials ENDVTAM : If you have multiple printers defined in printmap, you can add multiple IP addresses to the IPGROUP and map the Mainframe Installation Setup: Task 2A - Configuring a Host For TN3270e Printing...
Page 36 printer group to the IP group as shown above ( PRTMAP PRINTERG SPECIP : You may also direct a printer device name to the printer IP address using PRTMAP statement as follows: PRTMAP PRT1 xxx.xxx.xxx.xxx (where PRT1 = printer and xxx = printer IP address) Mainframe Installation Setup: Task 2A - Configuring a Host For TN3270e Printing...
Page 37: Task 2B - Configuring An Sna Server For Tn3270E Printing
Task 2B - A number of different vendors provide SNA gateways and routers. Configuring an The procedure in this section shows how to set up a Microsoft SNA SNA Server For Server. It does therefore not apply to all SNA gateways or routers. However, the parameters that are configured should be easy to rec- TN3270e ognize.
Page 38 Fill in the LU Number and the LU Name. The LU Number must match that on the host. If you do not know the LU Number, ask your system administrator. Finish by pressing the |OK| button. Right-click the connection created in the previous step. Choose Assign To >...
Page 39: Task 3 -Configuring A Print Server
Task 3 - SCS/TNe Emulation printing requires a MarkNet internal print server Configuring a or a Standard Network port on the printer. Print Server A. To check the installed print server firmware version From a Ready state touch Menus. MPORTANT The SCS/TNe Emulation can only receive jobs Touch Reports.
Page 40 B. Configuring the Print Server To enable SCS printing, several print server settings may need to be changed. You can make these changes from the printer operator panel. Set NPA Mode to Auto. Select Menus > Network/Ports. Select the print server to be used for SCS printing, for example Standard Network.
Page 41 Set the Job Timeout. This timeout is used by all print servers. Select Menus > Network/Ports. Select the print server to be used for SCS printing, for example Standard Network. Select Standard Network > Std Network Setup > Network Card > Job Timeout. Scroll down to 0. Touch Submit to save.
Page 42 TCP/IP Option Value Description Address Address available from your network administrator. Netmask Netmask for your network. Contact your network administrator. Gateway Address of the IP gateway. Contact your network administrator. Enable DHCP On or Off On, if you use a DHCP server. Off, if you set the IP address another way.
Page 43: Task 4 - Configuring The Scs Settings
Task 4 - Several SCS option values may need to be changed to properly for- Configuring the mat and print SCS jobs that do not contain formatting commands in SCS Settings the job. The following three settings are usually the most important, but there are many other possibilities.
Page 44 B. To select a different SCS country code Select Menus > Option Card Menu > SCS/TNe MENU > TN3270E SETUP > SCS OPTIONS > MISC SETTINGS > Country Code. MISC SETTINGS Option Default Value Recommended Value Comments Country Code (IDB Option 2) English (US) Your preferred country...
Page 45: Task 5 - Configuring The Scs/Tne Emulation
Exit the menu by touching Home. Task 5 - SCS jobs are printed from a LAN connected Mainframe using TCP/ Configuring the IP and the telnet extended (TN3270e) protocol. A single TN3270e SCS/TNe print session can be established with a host. Emulation To configure a TN3270e print session Select Menus >...
Page 46 The table below shows the factory default settings and recommended settings. The option setting values found in the table are described in section “NETWORK SETUP> SERVER INFO Menu: Options Overview” on page SERVER INFO Option Default Value Recommended Value Comments Name / IP Use IP Address Check with your system administrator whether you need to...
Page 47 SERVER INFO Option Default Value Recommended Value Comments LU Name [undefined] Your LU name Check with your system administrator for the correct name. (up to 10 characters) This name must be defined on the host or SNA Server. Please note! Some hosts and servers only recognize upper- case LU Names.
Page 48 To activate the new settings, select Menus > Option Card Menu > SCS/TNe MENU > COMMON SETUP > Reset TN Session. Scroll to Reset TN Ses and touch Submit. Touch Home to exit the menus. Wait approximately one minute. If all values are set correctly, this should allow enough time for the SCS/TNe Emulation and host to communicate and change the Connect Status from Print Inactive to another status (there are examples of...
Page 49: Task 6A - Verifying The Mainframe Connection
Task 6A - Send a job to the printer for which you want to verify the connection. Verifying the If the jobs fails to print correctly, the most common problems can be Mainframe found through one or more of the following actions: Connection Check the TN3270E Connection Status (see page 92) From the Operator Panel: Display the TN3270E Connect...
Page 50 From the main frame host give the following TCP/IP display MPORTANT Powering the printer Off and On does not end command: TCP/IP and Telnet sessions in an orderly manner. D TCPIP,TCPIPNAME,TELNET,CONNECTION,PORT = To power the printer Off properly, select Menus > Option Card Menu >...
Page 51: Task 6B - Verifying The Mainframe/Sna Server Connection
Task 6B - Send a job to the printer for which you want to verify the connection. Verifying the If the jobs fails to print correctly, the most common problems can be Mainframe/SNA found through one or more of the following actions: Server Check the TN3270E Connection Status (see page 92) Connection...
Page 52 Through the http (browser) user interface: Connect to the print server by entering the print server address as the URL. When the print server display appears, click Reports and then Device Setttings. From the main frame host give the following TCP/IP display MPORTANT Powering the printer Off and On does not end command:...
Page 53: Installation Setup For As/400 And Iseries Users
Installation Setup for AS/400 and iSeries Users Introduction This chapter applies to AS/400 and iSeries users. (Mainframe users refer to “Installation Setup for Mainframe Users” on page 28.) The tasks presented describe how to set up the host and the SCS/ TNe Emulation for AS/400 or iSeries printing.
Page 54: Task 1 - Configuring The Host
Task 1 - The host operating system must support TCP/IP and extended Tel- Configuring the net protocols to print SCS jobs to a LAN attached printer. Host Section “AS/400 and iSeries Software” on page 279 lists host soft- ware which supports these protocols. To configure the host check and set the following three system values.
Page 55 System Value Required Value Controls the automatic configuration of virtual devices. QAUTOVRT Must be set to an adequate number of devices Sample commands: DSPSYSVAL QAUTOVRT CHGSYSVAL QAUTOVRT ### Where ### is the number of devices. When these values are properly configured, the host will auto con- figure devices and writers with the information received from the SCS/TNe Emulation.
Page 56: Task 2 - Configuring A Print Server
Task 2 - SCS/TNe emulation printing requires a MarkNet internal print server Configuring a or a Standard Network port on the printer. Print Server A. To check the installed print server firmware version From a Ready state touch Menus. Touch Reports. Scroll until one or more of the following appears.
Page 57 B. Configuring the Print Server MPORTANT The SCS/TNe Emulation can only receive jobs through a single printer server. To enable SCS printing, several print server settings may need to be Moving the selected print server or inserting a changed. You can make these changes from the printer operator new print server may cause a loss of SCS/TNe print capability.
Page 58 Set the Job Timeout. This timeout is used by all print servers. Select Menus > Network/Ports. Select the print server to be used for SCS printing, for example Standard Network. Select Standard Network > Std Network Setup > Network Card > Job Timeout. Scroll down to 0. Touch Submit to save.
Page 59 TCP/IP Option Value Description Address Address available from your network administrator. Netmask Netmask for your network. Contact your network administrator. Gateway Address of the IP gateway. Contact your network administrator. Enable DHCP On or Off On, if you use a DHCP server. Off, if you set the IP address another way.
Page 60: Task 3 - Configuring The Scs Settings
Task 3 - Several SCS option values may need to be changed to properly for- Configuring the mat and print SCS jobs which do not contain formatting commands SCS Settings in the job. The SCS/TNe Emulation comes with European (A4 paper size) fac- tory default settings.
Page 61 Still within MISC SETTINGS, locate Codepage. Scroll to your preferred code page and touch Submit to save it. Option Default Value Recommended Value Comments Codepage (IDB Options 240 and 241) Multi 500 Your preferred code page Still within MISC SETTINGS, locate Lines Per Page. Scroll to the desired Number and touch Submit to save it.
Page 62 Select Menus > Option Card Menu > SCS/TNe MENU >TN5250E SETUP > SCS OPTIONS > PAPER SETTINGS > Page Length. Scroll to the desired value and touch Submit to save it. Option Default Value Recommended Value Comments Page Length (IDB Opt. 82 & 83) 16848 (for A4) 15840 (for Letter).
Page 63 B. To enable Euro support Select Menus > Option Card Menu > SCS/TNe MENU > TN5250E SETUP > SCS OPTIONS > Euro Support. Option Default Value Recommended Value Comments Euro Support (IDB Option 139) Scroll to Yes. Touch Submit to save the setting. Exit the menu by by touching Home.
Page 64: Task 4 - Configuring The Scs/Tne Emulation
Task 4 - SCS jobs are printed from a LAN connected AS/400 or iSeries host Configuring the using TCP/IP and the telnet extended (TN5250e) protocol. Up to SCS/TNe four TN5250e print sessions can be established with a single or multiple hosts. Emulation To configure the SCS/TNe Emulation Select Menus >...
Page 65 You will need to check with your system administrator. The option setting values found in the table are described in section “CONNECTION # > SERVER # INFO Menu: Options Overview” on page 165. Option Default Value Recommended Value Comments Name / IPaddress # Use IP# Check with your system administrator whether you need Address...
Page 66 Option Default Value Recommended Value Comments Device # Name [undefined] Your device name The host will autoconfigure a device and writer with this (up to 10 characters) name if it does not exist. Keep Alive Type None None Leave this at the factory default if the host is configured to send a keep alive signal.
Page 67 Option Default Value Recommended Value Comments Auto Sense # END Yes - but only if the Enable this option to allow the TN5250e emulation to host ends the writer automatically sense if the host has ended the writer unexpectedly in the unexpectedly.
Page 68 Wait approximately one minute. If all values are set correctly, this should allow enough time for the SCS/TNe Emulation and host to communicate and change the Connect # Status from Print Inactive to another status (there are examples of Connect # Status messages on page 92. AS/400 and iSeries Installation Setup: Task 4 - Configuring the SCS/TNe Emulation...
Page 69: Task 5 - Verifying The Host Connection
Task 5 - Send a job to the printer for which you want to verify the connection. Verifying the If the jobs fails to print correctly, the most common problems can be Host Connection found through one or more of the following actions: Check the TN5250E Connection Status (see page 162).
Page 70 Through the http (browser) user interface: Connect to the print server by entering the print server address as the URL. When the print server display appears, click Reports and then Device Setttings. Check the host auto configure settings. See “Task 1 - MPORTANT Powering the printer Off and On does not end Configuring the Host”...
Page 71: Scs/Tne Cancel
SCS/TNe Cancel About Cancel SCS jobs may be canceled at the printer or MFP. Cancel Job only displays when the printer or MFP is processing a print job. Selecting a specific job to cancel is difficult when several small jobs are queued to print from the host.
Page 72: Printer Cancel Job
Printer Cancel Press the Select button on the operator panel while your job is printing The printer will clear the paper path and display a "Stopping" message. In the next menu, press the Select button when the on- screen checkmark is beside the job you want to cancel. There may be only one Print Job shown, as in the example below.
Page 73 The printer will keep you posted on its progress and automatically return to its normal state, which will be BUSY if it is in the process of printing other jobs. Important Configuration Basics: Printer Cancel Job...
Page 74: Mfp Cancel Job
MFP Cancel Job While any job is printing, the Cancel Job icon will be displayed on the printer panel. Touch the icon. In the "Print" column, select the job you want to cancel by touching the print job icon. Touch the Delete Selected Job icon. The screen will display a message to indicate that the job is being deleted.
Page 75: Operations Reference - Common Setup
Operations Reference - Common Setup Introduction As indicated in the tree diagram below, the SCS/TNe MENU is divided into three branches. This section describes the COMMON SETUP menu structure and options for the SCS/TNe Emulation From a Ready status, touch Menus. Locate and touch the Option Card Menu.
Page 76 Reset ALL Def • How to access the You will always be able to see the selected value for each option on Menu Settings Page the Menu Settings page. From the Operator Panel: • Select Menus > Reports > Menu Settings Page. Through the http (browser) user interface: •...
Page 77: Menu Options Overview
Menu Options Overview Option name Values Disconnect Ses Do Not Disconn., Disconnect Ses. Reset TN Session Do Not Reset, Reset TN Ses. SCS Debug Trace Disable *, PAR Std. Output, PAR Slot# Output, USB Std. Output, USB Slot# Output Reset ALL Def Do Not Reset, Reset All A description of the COMMON SETUP menu items follows.
Page 78: Disconnect Ses
Disconnect Ses This option disconnects all active TNe sessions on TCP/IP level. The SCS/TNe Emulation will attempt to reconnect when the printer is powered Off and On or when a Reset TN Ses. is performed. See Reset TN Session option below. A Disconnect Ses.
Page 79: Reset Tn Session
Reset TN Session This option disconnects ALL active TNe sessions on TCP/IP level, MPORTANT Powering the printer Off and On does not end restarts the SCS/TNe emulation and reconnects. Use this option TCP/IP and Telnet sessions in an orderly manner. whenever changes have been made to the Network or Server Info To power the printer Off properly, select Menus >...
Page 80: Scs Debug Trace
SCS Debug The trace function traces all input (EBCDIC) and output (ASCII) Trace data. The trace menu option allows you to enable tracing and choose where the trace data should be sent. Because tracing will decrease printing performance, it should only MPORTANT Unless you have a computer running a capture be enabled when needed by service personnel for troubleshooting...
Page 81 Operator panel text Comments Disable * Disable trace. PAR Std. Out Enable the standard parallel port for trace data output. PAR Slot # Out Enable the optional parallel port in slot # for trace data output. # is a number representing the slot in which the optional parallel port card is installed.
Page 82: Reset All Def
Reset ALL Def This option restores ALL SCS/TNe emulation option settings to fac- tory defaults. Operator panel text Comments Do Not Reset Do not restore any settings. This performs the same action as if Back had been pressed in the operator panel.
Page 83: Operations Reference - Tn3270E Setup
Operations Reference - TN3270E SETUP Introduction This section describes the SCS/TNe Emulation TN3270E SETUP menu structure and options. Settings under this menu are used when printing from a Mainframe host. From a Ready status, touch Menus. Locate and touch the Option Card Menu.
Page 84 Tree diagram of the TN3270E SETUP menu structure. Operations - TN3270E SETUP: Introduction...
Page 85 The SCS/TNe Emulation has default settings for most SCS com- mands found in an SCS job. If one or more SCS settings are miss- ing from a job, the SCS/TNe Emulation uses the value specified in the SCS OPTIONS menu for the option. Settings specified in an SCS job override the SCS/TNe Emulation default settings.
Page 86 An Advanced IDB language command line is shown at the end of menu options which may be set by remote configuration. This shows how to remotely set the menu option to the factory default using the Advanced IDB language (cf. “IDB Basics”...
Page 87: Network Setup Menu: Options Overview
NETWORK The NETWORK SETUP menu is a sub-menu directly under the SETUP Menu: TN3270E SETUP menu. Options The following table lists menu options found under the NETWORK Overview SETUP menu. NETWORK SETUP Option name Values Print Active No *, Yes TN3270 Defaults Do Not Restore *, Restore Defaults Connect Status...
Page 88: Print Active
Print Active This Network Setup option controls the activation of the SCS/TNe Emulation for TN3270e communication and printing. Option Value Comments No * SCS printing is disabled for this connection. The printer will not attempt to establish a host connection. SCS printing is enabled for this connection.
Page 89: Tn3270 Defaults
TN3270 Defaults This Network Setup option restores the TN3270e NETWORK SETUP factory default settings and resets all sessions. Option Value Comments Do Not Restore * Do not restore to factory default settings. This performs the same action as if Back had been pressed in the operator panel.
Page 90: Connect Status
Connect Status This Network Setup option displays the connection status with the host. The option cannot be changed by the user. Normally only the primary status is shown. If problems occur, a last response message is appended to the primary status message. The complete status message text may not be displayed.
Page 91 Connect Status: Primary status messages Comments Reconnecting session The Telnet session was disconnected. The SCS/TNe Emulation is attempting to reconnect. Session Disconnected and Halted All active Telnet sessions have been disconnected. Power the printer Off and On or select Menus > Option Card Menu > SCS/ TNe MENU >...
Page 92 Connect Status: Last response messages Comments Lst Rsp:The server cannot satisfy the request The TN server cannot satisfy the request sent by the SCS/TNe Emulation. It could be a request was made for a specific terminal or printer which is not in any of the TN server’s pools of device names. Alternatively, the ASSOCIATE command was used but no partner printers are defined to the TN server.
Page 93: Network Setup> Server Info Menu: Options Overview
NETWORK The SERVER INFO menu is a sub-menu under the NETWORK SETUP> SETUP menu. The following table lists menu options found under SERVER INFO the SERVER INFO menu. Menu: Options Overview NETWORK SETUP > SERVER INFO Option name Values Name / IP Use IP Address *, Use Hostname Address IP Address...
Page 94: Name / Ip Address
Name / IP This Network Setup > Server Info option specifies the kind of Address address the SCS/TNe Emulation uses to contact the host or Telnet server. Option Value Comments Use IP Address * Use the IP address specified with the IP Address option.
Page 95: Ip Address
IP Address This Network Setup > Server Info option specifies the specific IP address of the host to be contacted by the SCS/TNe Emulation. Option Value Comments 0.0.0.0 * Contact your network administrator for the IP address to use. Operations - TN3270E SETUP: NETWORK SETUP > SERVER INFO > IP Address...
Page 96: Hostname
Hostname This Network Setup > Server Info option specifies the name used to identify the host to be contacted by the SCS/TNe Emulation. Option Value Comments [undefined] * Any ASCII text string up to 16 characters. Contact your system administrator for information on the hostname to use.
Page 97: Tn Server Port
TN Server Port This Network Setup > Server Info option specifies the TCP Telnet server port defined on the host. Check with your system administra- tor for the correct Telnet server port to use. Option Value Comments 23 * This is the default port number for Telnet sessions according to RFC 1700.
Page 98: Lu Name
LU Name This Network Setup > Server Info option specifies the LU name assigned to the SCS/TNe Emulation on the host or SNA gateway. Remember also to check the setting of the Device Type option. If a MPORTANT An LU name must be specified in order for the specific LU name is requested, then the name must be defined and SCS/TNe Emulation to connect to the host or available on the host.
Page 99: Device Type
Device Type This Network Setup > Server Info option specifies the device type for the LU Name requested from the host or the SNA gateway by the SCS/TNe Emulation. Check with your system administrator for the correct device type to use. Option Value Comments Specific *...
Page 100: Keep Alive Type
Keep Alive Type This Network Setup > Server Info option specifies the type of keep alive signal sent to the host or SNA gateway server. This signal is sent to the host by the SCS/TNe Emulation to keep the Telnet ses- sion active.
Page 101: Keep Alive Time
Keep Alive Time This Network Setup > Server Info option specifies the time in sec- onds that expires between each keep alive signal sent to the host or SNA gateway server. The Keep Alive Type setting specifies the type of signal sent to the host. Set this option to a value smaller than the session’s inactivity time- out value defined on the host.
Page 102: Scs Options Menu: Options Overview
SCS OPTIONS The SCS OPTIONS menu is a sub-menu directly under the Menu: Options TN3270E SETUP menu. Overview The following table lists menu options and sub-menus found under the SCS OPTIONS menu. SCS OPTIONS Option name Values COR/APO Sett (IDB Option 122) Yes *, No MISC SETTINGS Sub-menu.
Page 103: Cor/Apo Sett (Idb Option 122)
COR/APO Sett This SCS Options option controls whether or not Automatic Print (IDB Option 122) Orientation (APO) is used. APO automatically controls page orientation. When APO is enabled the SCS/TNe Emulation calculates the print area required for print- ing the document. This is based on page formatting commands received from the host.
Page 104: Scs Options > Misc Settings Menu: Options Overview
SCS Options > The MISC SETTINGS menu is a sub-menu under the SCS MISC SETTINGS OPTIONS menu. Menu: Options The following table lists menu options and sub-menus found under Overview the MISC SETTINGS menu. SCS OPTIONS >MISC SETTINGS Option name Values FF Support (IDB Option 5) Always FF *, Always LF, LF &...
Page 105 SCS OPTIONS >MISC SETTINGS Option name Values Max Prt Pos (IDB Option 102) 132 *, range: 1 - 255 LPI (IDB Option 105) 6 *, range: 1 - 255 Line Spacing (IDB Option 106) Single *, Double LPP (IDB Option 107) 64 *, range: 1 - 255 Transparency (IDB Option 167) Intermate *, Axis, Enable MPI feat...
Page 106: Ff Support (Idb Option 5)
FF Support (IDB This SCS Options > MISC Settings option defines if a form feed Option 5) and/or a line feed is generated when the MPL (Maximum Page Length) or BM (Bottom Margin) is reached in the data stream. Option Value IDB Value Always FF * Always LF...
Page 107: Non-Print Char (Idb Option 3)
Non-Print Char This SCS Options > MISC Settings option defines the replacement (IDB Option 3) character to substitute for an unprintable character found in the data stream. Refer to “Appendix B - ASCII Character Table” on page 282 for a complete list of printable characters and their values. Option Value IDB Value ASCII Value 45 *...
Page 108: Csc Characters (Idb Options 8 & 9)
CSC Characters This SCS Options > MISC Settings option defines the Command (IDB Options 8 & String Characters (CSC). The CSC is a unique two-character sequence, which opens the internal IDB editor in the SCS/TNe Emulation. It must be used every time IDB commands are sent to the SCS/TNe Emulation.
Page 109: Idb Delimiter (Idb Option 7)
IDB Delimiter This SCS Options > MISC Settings option defines the delimiter (IDB Option 7) used in the Advanced IDB command language to separate pro- gramming commands. The IDB option value is an ASCII character in the decimal range 32 - 126.
Page 110: Use Ir (Idb Option 21)
Use IR (IDB This SCS Options > MISC Settings option controls Intervention Option 21) Required (IR) reporting to the host. If the option is enabled, IR sig- nals are sent when the printer reports a Paper Out, Paper Jam, goes Off-line etc. Option Value Value Description IDB Value...
Page 111: Format Ctrl Sup (Idb Option 177)
Format Ctrl Sup This SCS Options > MISC Settings option defines the suppression (IDB Option 177) of control codes after Power On. Option Value IDB Value Comments Normal * Standard handling of control codes after Power On. It can be disabled with the <CSC>+M command.
Page 112 Option Value IDB Value Comments Normal’ Standard handling of control codes after Power On. If the <CSC>+M command is used, CR, LF, NL and FF codes from the host are suppressed and the auto-NL function is disabled. No Codes’ CR, LF, NL and FF codes from the host are suppressed.
Page 113 If Option 177 = 3 or 4: All host generated CR, LF, NL and FF control codes are suppressed and the auto-NL function is disabled. Control codes can only be sent to the printer with one of the transparent commands. : The effect of the <CSC>+M command is reset per job.
Page 114: Country Code (Idb Option 2)
Country Code (IDB Option 2) This SCS Options > MISC Settings option defines the character set. Option Value IDB Value Comments Aus/Ger Austrian/German Aus/Ger (alt) Austrian/German Alternate Belgian Belgian Brazilian Brazilian Can Bilin Canadian bilingual Can French Canadian French Dan/Nor Danish/Norwegian Dan/Nor (alt) Danish/Norwegian Alternate...
Page 115 Option Value IDB Value Comments Portugal Portuguese Portugal (alt) Portuguese Alternate Spanish Spanish Spanish Speak. 19 Spanish speaking Spanish (alt) Spanish Alternate Ger/Fre (Swiss) 21 Swiss German/Swiss French Jap/Eng Japanese/English Spa/Text proc. Spanish data/text processing : If the SCS options are restored to non-US factory defaults, the default value of this option changes to English (UK).
Page 116: Skip Blank Page (Idb Option 32)
Skip Blank Page This SCS Options > MISC Settings option controls whether or not (IDB Option 32) blank pages are printed. With this option enabled, pages containing only a CR, NL, LF or FF are skipped. Option Value IDB Value Do Not Skip * Skip Advanced IDB language to set factory default:...
Page 117: Cpi (Idb Option 100)
CPI (IDB Option This SCS Options > MISC Settings option defines the number of 100) characters per inch. Option Value IDB Value 10 CPI * 12 CPI 15 CPI 16.7 CPI Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 100:10:EXIT Operations - TN3270E SETUP: MISC SETTINGS >...
Page 118: Max Prt Pos (Idb Option 102)
Max Prt Pos (IDB This SCS Options > MISC Settings option defines the maximum Option 102) number of characters per line. Option Value IDB Value 132 * [1..255] Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 102:132:EXIT Operations - TN3270E SETUP: MISC SETTINGS > Max Prt Pos (IDB Option 102)
Page 119: Lpi (Idb Option 105)
LPI (IDB Option This SCS Options > MISC Settings option defines the number of 105) lines per inch. Option Value IDB Value 6 * [1..255] Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 105:6:EXIT Operations - TN3270E SETUP: MISC SETTINGS > LPI (IDB Option 105)
Page 120: Line Spacing (Idb Option 106)
Line Spacing This SCS Options > MISC Settings option defines the line spacing. (IDB Option 106) Option Value IDB Value Single * Double Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 106:0:EXIT Operations - TN3270E SETUP: MISC SETTINGS > Line Spacing (IDB Option 106)
Page 121: Lpp (Idb Option 107)
LPP (IDB Option This SCS Options > MISC Settings option defines the number of 107) lines per page. : If the SCS options are restored to non-US factory defaults, the default value of this option changes to 66. See the SCS3270 Defaults option.
Page 122: Transparency (Idb Option 167)
Transparency This SCS Options > MISC Settings option selects the transpar- (IDB Option 167) ency mode. Option Value IDB Value Intermate * Axis Enable MPI feat Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 167:0:EXIT Operations - TN3270E SETUP: MISC SETTINGS > Transparency (IDB Option 167)
Page 123: Form Strings (Idb Option 168)
Form Strings This SCS Options > MISC Settings option defines the lead in char- (IDB Option 168) acter for the Formatted String Utility. The lead in character is an ASCII character in the decimal range 0 - MPORTANT Avoid using a character between 0 - 9 (ASCII 49 255.
Page 124: Ibm Trn Code (Idb Option 169 Bit 1)
IBM Trn Code This SCS Options > MISC Settings option defines how transparent (IDB Option 169 data is translated. bit 1) Option Value IDB bit option value Comments Normal * Transparent data is translated from EBCDIC to ASCII. Data outside the range 40H - FEH is printed as a hyphen.
Page 125: Leadin Sequence (Idb Option 169 Bit2)
Leadin This SCS Options > MISC Settings option defines the kind of lead Sequence (IDB in sequence used. Option 169 bit2) Option Value IDB bit option value Comments Normal * Normal user defined trans- parent handling. Without ’&%’ User defined transparent lead in characters are used without the pass through sequence.
Page 126: Euro Support (Idb Event 191)
Euro Support This SCS Options > MISC Settings option controls Euro character (IDB Event 191) print support. Option Value Comments No * Disable Euro Support. Enable Euro Support. The ASCII character 186d (0xBAh) is converted to the Euro ASCII character 213d (0xD5h) in symbol set 13U. Operations - TN3270E SETUP: MISC SETTINGS >...
Page 127: Scs Options> Misc Settings > Bold Print Menu - Options Overview
SCS Options> The BOLD PRINT menu is a sub-menu under the MISC SETTINGS MISC SETTINGS menu. > BOLD PRINT The following table lists menu options found under the BOLD Menu - Options PRINT menu. Overview SCS OPTIONS > MISC SETTINGS> BOLD PRINT Option name Values Bold On CR (IDB Option 22 bit 1)
Page 128: Bold On Cr (Idb Option 22 Bit 1)
Bold On CR (IDB This SCS Options > MISC Settings > BOLD PRINT option defines Option 22 bit 1) whether or not bold printing is enabled on a carriage return (CR). Option Value IDB bit option value Yes * Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 22:7:EXIT Operations - TN3270E SETUP: MISC SETTINGS >...
Page 129: Bold On Bs (Idb Option 22 Bit 2)
Bold On BS (IDB This SCS Options > MISC Settings > BOLD PRINT option defines Option 22 bit 2) whether or not bold printing is enabled on a backspace (BS). Option Value IDB bit option value Yes * Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 22:7:EXIT Operations - TN3270E SETUP: MISC SETTINGS >...
Page 130: Bold On Multi Bs (Idb Opt. 22 Bit 3)
Bold On Multi This SCS Options > MISC Settings > BOLD PRINT option defines BS (IDB Opt. 22 whether or not bold printing is enabled on multiple backspaces. bit 3) Option Value IDB bit option value Yes * Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 22:7:EXIT Operations - TN3270E SETUP: MISC SETTINGS >...
Page 131: Scs Options > Paper Settings Menu: Options Overview
SCS Options > The PAPER SETTINGS menu is a sub-menu under the SCS PAPER OPTIONS menu. The following table lists menu options found under SETTINGS the PAPER SETTINGS menu. Menu: Options Overview Option name Values Left Margin (IDB Option 103) 1 *, range: 1 - 255 Right Margin (IDB Option 104) 132 *, range: 1 - 255...
Page 132 A description of each PAPER SETTINGS menu option follows. Operations - TN3270E SETUP: SCS Options > PAPER SETTINGS Menu: Options Overview...
Page 133: Left Margin (Idb Option 103)
Left Margin (IDB This SCS Options > Paper Settings option defines the left margin Option 103) position in characters. The character width depends on the setting of the CPI (IDB Option 100) option. Option Value IDB Value 1 * [1..255] Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 103:1:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 134: Right Margin (Idb Option 104)
Right Margin This SCS Options > Paper Settings option defines the right margin (IDB Option 104) position in characters. The character width depends on the setting of the CPI (IDB Option 100) option. Option Value IDB Value 132 * [1..255] Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 104:132:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 135: Top Margin (Idb Option 108)
Top Margin (IDB This SCS Options > Paper Settings option defines line number Option 108) position of the top margin. The line height depends on the setting of LPI (IDB Option 105) option. Option Value IDB Value 1 * [1..255] Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 108:1:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 136: Bottom Margin (Idb Option 109)
Bottom Margin This SCS Options > Paper Settings option defines the line number (IDB Option 109) position of the bottom margin. The line height depends on the set- ting of the LPI (IDB Option 105) option. : If the SCS options are restored to non-US factory defaults, the default value of this option changes to 66.
Page 137: Source Input (Idb Option 113)
Source Input This SCS Options > Paper Settings option selects the input (IDB Option 113) source. Option Value IDB Value Comments Prtr Setting Feed paper from the paper source selected in the printer PAPER MENU Paper Source menu. Tray 1 * Paper is fed from Tray 1 Tray 2 Paper is fed from Tray 2...
Page 138: Tray 1 Orient (Idb Option 123)
Tray 1 Orient This SCS Options > Paper Settings option selects the page orien- (IDB Option 123) tation for source input tray 1. Option Value IDB Value Portrait Landscape COR * Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 123:2:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 139: Tray 2 Orient (Idb Option 124)
Tray 2 Orient This SCS Options > Paper Settings option selects the page orien- (IDB Option 124) tation for source input tray 2. Option Value IDB Value Portrait Landscape COR * Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 124:2:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 140: Tray 3 Orient (Idb Option 125)
Tray 3 Orient This SCS Options > Paper Settings option selects the page orien- (IDB Option 125) tation for source input tray 3. Option Value IDB Value Portrait * Landscape Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 125:0:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 141: Tray 4 Orient (Idb Option 126)
Tray 4 Orient This SCS Options > Paper Settings option selects the page orien- (IDB Option 126) tation for source input tray 4. Option Value IDB Value Portrait * Landscape Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 126:0:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 142: Tray 5 Orient (Idb Option 127)
Tray 5 Orient This SCS Options > Paper Settings option selects the page orien- (IDB Option 127) tation for source input tray 5. Option Value IDB Value Portrait * Landscape Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 127:0:EXIT Operations - TN3270E SETUP: SCS Options >...
Page 143: Tray1 Paper Size (Idb Option 90)
Tray1 Paper Size This SCS Options > Paper Settings option specifies the paper size (IDB Option 90) to be used when Source Input (IDB Option 113) Tray 1 is selected and the APO/COR function has been activated. This paper size is used to determine the print area for rotations of job text.
Page 144: Tray2 Paper Size (Idb Option 91)
Tray2 Paper Size This SCS Options > Paper Settings option specifies the paper size (IDB Option 91) to be used when Source Input (IDB Option 113) Tray 2 is selected and the APO/COR function has been activated. This paper size is used to determine the print area for rotations of job text.
Page 145: Tray3 Paper Size (Idb Option 92)
Tray3 Paper Size This SCS Options > Paper Settings option specifies the paper size (IDB Option 92) to be used when Source Input (IDB Option 113) Tray 3 is selected and the APO/COR function has been activated. This paper size is used to determine the print area for rotations of job text.
Page 146: Tray4 Paper Size (Idb Option 93)
Tray4 Paper Size This SCS Options > Paper Settings option specifies the paper size (IDB Option 93) to be used when Source Input (IDB Option 113) Tray 4 is selected and the APO/COR function has been activated. This paper size is used to determine the print area for rotations of job text.
Page 147: Tray5 Paper Size (Idb Option 94)
Tray5 Paper Size This SCS Options > Paper Settings option specifies the paper size (IDB Option 94) to be used when Source Input (IDB Option 113) Tray 5 is selected and the APO/COR function has been activated. This paper size is used to determine the print area for rotations of job text.
Page 148: Test Options Menu: Options Overview
TEST OPTIONS The TEST OPTIONS menu is a sub-menu directly under the Menu: Options TN3270E SETUP menu. Overview The following table lists menu options found under the TEST OPTIONS menu. Option name Values SCS3270 Hex Dump Normal Mode *, Hex Dump-Mode Print 3270 IDB Do Not Print *, Print SCS3270 Defaults...
Page 149: Scs3270 Hex Dump
SCS3270 Hex This Test option enables hex tracing for diagnosing print job prob- Dump lems. When hex dump mode is selected, all data sent to the printer is printed in hexadecimal and character representation. Control codes are not executed. SCS Debug Trace option overrides this option.
Page 150: Print 3270 Idb
Print 3270 IDB This Test option prints a tabular report of the current IDB settings using option numbers. Print this report when asked by technical support representatives. Option Value Comments Do Not Print * Do not print the IDB settings. This performs the same action as if Back had been pressed in the operator panel.
Page 151: Scs3270 Defaults
SCS3270 This Test option restores the TN3270e SCS OPTIONS setting to Defaults their factory default settings. Other printer emulation defaults are unchanged. The restored settings become active on the next SCS job. Option Value Comments Do Not Restore * Do not restore any settings. This performs the same action as if Back had been pressed in the operator panel.
Page 152 Affected option US-Default Non-US-Default Tray2 Paper Size (IDB Option 91) Letter Tray3 Paper Size (IDB Option 92) Letter Tray4 Paper Size (IDB Option 93) Letter Tray5 Paper Size (IDB Option 94) Letter FF Support (IDB Option 5) Always FF Always FF COR/APO Sett (IDB Option 122) Operations - TN3270E SETUP: TEST OPTIONS >...
Page 153: Operations Reference - Tn5250E Setup
Operations Reference - TN5250E SETUP Introduction This section describes the SCS/TNe Emulation TN5250E SETUP menu structure and options. Settings under this menu are used when printing from an AS/400 or iSeries host. From a Ready status, touch Menus. Locate and touch the Option Card Menu.
Page 154 Tree diagram of the TN5250E SETUP menu structure. Operations - TN5250E SETUP: Introduction...
Page 155 The SCS/TNe Emulation has default settings for most SCS com- mands found in an SCS job. If one or more SCS settings are miss- ing from a job, the SCS/TNe Emulation uses the value specified in the SCS OPTIONS menu for the option. Settings specified in an SCS job override the SCS/TNe Emulation default settings.
Page 156 A User IDB command is shown at the end of menu options which may be set by remote configuration. Following this are two com- mand lines, one for the User IDB language and another for the Advanced IDB language. These show how to remotely set the menu option to the factory default or how to perform the described action (cf.
Page 157: Connection # Menu: Options Overview
CONNECTION # The SCS/TNe Emulation supports four concurrent TN5250E ses- Menu: Options sions. Each session has its own unique set of network settings. Overview These are located in the CONNECTION#1 - CONNECTION#4 menus. The SCS OPTIONS (pp.177 ff) menu settings are common to all four sessions.
Page 158: Print # Active
Print # Active This Connection# option controls the activation of the SCS/TNe Emulation for TN5250E communication and printing. Option Value Comments No * SCS printing is disabled for this connection. The printer will not attempt to establish a host connection. SCS printing is enabled for this connection.
Page 159: Tn5250## Default
TN5250## This Connection# option restores the TN5250E CONNECTION #1, Default #2, #3, or #4 factory default settings and resets all sessions. Option Value Comments Do Not Restore * Do not restore to factory default settings. This performs the same action as if Back had been pressed in the operator panel.
Page 160: Connect # Status
Connect # This Connection# option displays the connection status with the Status host. The option cannot be changed by the user. The first part of the line shows the primary status message of the connection followed by a last response message received from the host.
Page 161 Connect # Status: Primary status messages Comments Session Disconnected and Halted All active Telnet sessions have been disconnected. Power the printer Off and On or select Menus > Option Card Menu > SCS/ TNe MENU > COMMON SETUP > Reset TN Session > Reset TN Ses.
Page 162 Connect # Status: Last response messages Comments Lst Rsp:8902:Device not available The requested device is not available on the system. It has probably been assigned to another Telnet session. Lst Rsp:8903:Device not valid for session Check with system operator. Lst Rsp:8906:Session initiation failed Check with system operator.
Page 163: Connection # > Server # Info Menu: Options Overview
Connect # Status: Last response messages Comments Lst Rsp:8935:Session rejected Check with system operator. Lst Rsp:8936:Security failure on session Check with system operator. Lst Rsp:8937:Automatic sign-on rejected Check with system operator. Lst Rsp:8940:Automatic config. failed Check with system operator. Lst Rsp:I904:Source at incompatible release Check with system operator.
Page 164: Name / Ipaddress
Connection# > SERVER # INFO Option name Values Keep Alive Time 45 *, range: 1 - 32000 [seconds] MSGQ # Name QSYSOPR *, ASCII name with up to 10 characters. MSGQ # Lib *LIBL *, ASCII name with up to 10 characters. IR # Reply Normal *, Offline, No Reply Auto Sense # END...
Page 165: Ip # Address
IP # Address This Connection# > Server# Info option specifies the specific IP address of the host to be contacted by the SCS/TNe Emulation. Option Value Comments 0.0.0.0 * Contact your network administrator for the IP address to use. Operations - TN5250E SETUP: CONNECTION # > SERVER # INFO > IP # Address...
Page 166: Hostname
Hostname # This Connection# > Server# Info option specifies the name used to identify the host to be contacted by the SCS/TNe Emulation. Option Value Comments [undefined] * Any ASCII text string up to 16 characters. Contact your system administrator for information on the hostname to use.
Page 167: Server # Tn Port
Server # TN Port This Connection# > Server# Info option specifies the TCP Telnet server port defined on the host. Check with your system administra- tor for the correct Telnet server port to use. Option Value Comments 23 * This is the default port number for Telnet sessions according to RFC 1700.
Page 168: Device # Name
Device # Name This Connection# > Server# Info option specifies the device and writer name associated with the SCS/TNe Emulation on the host. A device and writer will be auto configured with this name if it does not already exist. Option Value Comments [undefined] *...
Page 169: Keep Alive Type
Keep Alive Type This Connection# > Server# Info option specifies the type of keep alive signal sent to the host. This signal is sent by the SCS/TNe Emulation to keep the Telnet session active. The option is normally left at its default setting. Keep Alive Time setting determines how often this signal is MPORTANT...
Page 170: Keep Alive Time
Keep Alive Time This Connection# > Server# Info option specifies the time in sec- onds that expires between each keep alive signal sent to the host. Keep Alive Type setting specifies the type of signal sent to the host. If the Keep Alive Type signal setting is set to None, this option value Set this option to as big a value as possible.
Page 171: Msgq # Name
MSGQ # Name This Connection# > Server# Info option specifies the message queue name on the host to which Intervention Required conditions are reported. The message queue name must already exist on the host. It will not be auto created. The MSGQ # Lib option may be used to set the message queue library.
Page 172: Msgq # Lib
MSGQ # Lib This Connection# > Server# Info option specifies the message queue library for the message queue specified in the MSGQ # Name option. The message queue library must already exist on the host. It will not be auto created. Leave this option at the default if you do not know the library name.
Page 173: Ir # Reply
IR # Reply This Connection# > Server# Info option controls the reporting of Intervention Required Replies to the host. Option Value Comments Normal * Use normal IR replies, i.e. send paper jam as paper jam, paper out as paper out etc. Offline Only send IR replies as offline messages without specifying what kind of IR has occurred.
Page 174: Auto Sense # End
Auto Sense # This Connection# > Server# Info option controls whether or not the SCS/TNe Emulation senses automatically if the host has ended the Writer. This may be necessary due to the host’s management of the print queue when more than one job is in the same queue. Option Value Comments No *...
Page 175: Scs Options Menu: Options Overview
SCS OPTIONS The SCS OPTIONS menu is a sub-menu directly under the Menu: Options TN5250E SETUP menu. Overview One set of TN5250E SCS OPTIONS menu values are saved. All four TN5250E connections use the same SCS OPTIONS val- ues. The following table lists menu options and sub-menus found under the SCS OPTIONS menu.
Page 176 SCS OPTIONS Option name Values CSC CHARACTERS Sub-menu. See SCS OPTIONS > CSC CHARACTERS Menu: Options Overview (page 192) and SCS OPTIONS > CSC CHARACTERS Menu: Options Overview (page COR/APO SETTINGS Sub-menu. See SCS OPTIONS > COR/APO SETTINGS Menu: Options Overview (page 198) and Def Page Ori 1 (IDB Option 121) (page 199).
Page 177: Overlay Call (Idb Option 28)
Overlay Call This SCS Options option defines if an overlay call (predefined (IDB Option 28) string) is printed on the top of each page. The overlay may contain a call to an electronic form, a macro, or the string stated by the command itself.
Page 178 Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 28:0:EXIT Operations - TN5250E SETUP: SCS OPTIONS > Overlay Call (IDB Option 28)
Page 179: Prop Font Move (Idb Option 118)
Prop Font Move This SCS Options option controls whether or not the SCS/TNe (IDB Option 118) Emulation uses proportional font handling. The individual character width values of the printer's native fonts must correspond to the width value which the host expects the char- acters to have.
Page 180 User IDB language to set factory default: &%IDB_EDIT: PRPFNTMOV OFF:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 118:0:EXIT Operations - TN5250E SETUP: SCS OPTIONS > Prop Font Move (IDB Option 118)
Page 181: Compress Cpi (Idb Option 128)
Compress CPI This SCS Options option defines the compression of the horizontal (IDB Option 128) character spacing. The command is used to compensate for the reduced printable area of the printer. The option makes it possible to print 80 characters on a line using 10 CPI, 96 characters on a line using 12 CPI and 120 characters on a line using 15 CPI.
Page 182 User IDB command: COMCPI <parameter>: Parameter: OFF, ON User IDB language to set factory default: &%IDB_EDIT: COMCPI OFF:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 128:0:EXIT Operations - TN5250E SETUP: SCS OPTIONS > Compress CPI (IDB Option 128)
Page 183: Move Hor/Ver (Idb Option 158)
Move Hor/Ver This SCS Options option determines how horizontal and vertical (IDB Option 158) moves are performed. Refer to the IDB options 211 - 213 if escape sequences (ESC) are used for horizontal movement and to option 238 if spaces (SP) are used. Option Value IDB Value User IDB parameter...
Page 184 Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 158:1:EXIT Operations - TN5250E SETUP: SCS OPTIONS > Move Hor/Ver (IDB Option 158)
Page 185: Format Ctrl Sup (Idb Option 177)
Format Ctrl Sup This SCS Options option is used for enabling and disabling the (IDB Option 177) "Auto newline" feature of the SCS/TNe Emulation. If the printout is incorrectly double spaced, disabling it will in most cases solve the problem. Option Value IDB Value User IDB parameter...
Page 186: Download Font (Idb Option 244)
Download Font This SCS Options option extends the fonts available to the SCS/ (IDB Option 244) TNe Emulation by loading additional fonts into the printer memory. Enabled means that these fonts will be downloaded to the printer’s memory at Power On. The additional fonts are listed in the table below.
Page 187 User IDB command: Not supported Parameter: Not supported User IDB language to set factory default: Not supported Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 244:0:EXIT Operations - TN5250E SETUP: SCS OPTIONS > Download Font (IDB Option 244)
Page 188: Euro Support (Idb Option 139)
Euro Support This SCS Options option controls Euro character printing. If the (IDB Option 139) option is set to Yes, the normal code pages are re-mapped to code pages containing the Euro character. This means that the interna- tional currency symbol is replaced with the Euro character in the EBCDIC code pages.
Page 189 In order to be able to print the Euro character a font supporting the character also has to be selected and available in the printer. See Download Font (IDB Option 244) option on page and the Font (IDB Options 242 and 243) option on page 215.
Page 190: Scs Options > Csc Characters Menu: Options Overview
SCS OPTIONS > The CSC CHARACTERS menu is a sub-menu directly under the SCS OPTIONS menu. CHARACTERS The following table lists menu options found under the CSC CHAR- Menu: Options ACTERS menu. Overview SCS OPTIONS > CSC Characters Option name Values IDB First Char (IDB Option 8) &...
Page 191: Idb First Char (Idb Option 8)
IDB First Char This SCS Options > CSC Characters option defines the first char- (IDB Option 8) acter in the CSC (Command String Characters) sequence. The CSC is a unique two-character sequence, which opens the internal IDB editor in the SCS/TNe Emulation. It must be used every time IDB commands are sent to the SCS/TNe Emulation.
Page 192 User IDB language to set factory default: Not supported Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 8:38:EXIT Operations - TN5250E SETUP: SCS OPTIONS > IDB First Char (IDB Option 8)
Page 193: Idb Second Char (Idb Option 9)
IDB Second This SCS Options > CSC Characters option defines the second Char (IDB character in the CSC (Command String Characters) sequence. The Option 9) CSC is a unique two-character sequence, which opens the internal IDB editor in the SCS/TNe Emulation. It must be used every time IDB commands are sent to the SCS/TNe Emulation.
Page 194 User IDB language to set factory default: Not supported Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 9:37:EXIT Operations - TN5250E SETUP: SCS OPTIONS > IDB Second Char (IDB Option 9)
Page 195: Idb Delimiter (Idb Option 7)
IDB Delimiter This SCS Options > CSC Characters option defines the delimiter (IDB Option 7) used in the User IDB and Advanced IDB command languages to separate programming commands. The IDB option value is an ASCII character in the decimal range 33 - 126.
Page 196: Scs Options > Cor/Apo Settings Menu: Options Overview
SCS OPTIONS > The COR/APO SETTINGS menu is a sub-menu directly under the COR/APO SCS OPTIONS menu. SETTINGS The following table lists menu options found under the COR/APO Menu: Options SETTINGS menu. Overview SCS Options > COR/APO Settings Option name Values Def Page Ori 1 (IDB Option 121) Portrait *, Prtr Setting, Landscape...
Page 197: Def Page Ori 1 (Idb Option 121)
Def Page Ori 1 This SCS Options > COR/APO Settings option defines the page (IDB Option 121) orientation for paper tray 1. The option setting is only used when the APO/COR (Automatic Page Orientation / Computer Output Reduc- tion) function is disabled with the COR Action 1 (IDB Option 123) option.
Page 198: Def Page Ori 2 (Idb Option 122)
Def Page Ori 2 This SCS Options > COR/APO Settings option defines the page (IDB Option 122) orientation for paper tray 2 and above. The option setting is only used when the APO/COR (Automatic Page Orientation / Computer Output Reduction) function is disabled with the COR Action 2 (IDB Option 124) option.
Page 199: Cor Action 1 (Idb Option 123)
COR Action 1 This SCS Options > COR/APO Settings option defines how the (IDB Option 123) APO/COR function (Automatic Page Orientation/Computer Output Reduction) works for paper tray 1. With this option it is possible to disable the APO/COR function so that the page orientation change only can be made manually.
Page 200 When the Disable STO function is selected, all STO commands in the data stream are ignored, i.e. all text orientation commands. Option Value IDB Value User IDB parameter Disable Enable APO Enable Auto COR * 2 Disable STO STODIS User IDB command: CORDRW 1 <parameter>: Parameter: OFF, APO, COR, STODIS...
Page 201: Cor Action 2 (Idb Option 124)
COR Action 2 This SCS Options > COR/APO Settings option defines how the (IDB Option 124) APO/COR function (Automatic Page Orientation/Computer Output Reduction) works for paper tray 2 and above. With this option it is possible to disable the APO/COR function so that the page orientation change only can be made manually.
Page 202 When the Disable STO function is selected, all STO commands in the data stream are ignored, i.e. all text orientation commands. Option Value IDB Value User IDB parameter Disable Enable APO Enable Auto COR * 2 Disable STO STODIS User IDB command: CORDRW 2 <parameter>: Parameter: OFF, APO, COR, STODIS...
Page 203: Ppm Quality Dis (Idb Opt.126)
PPM Quality Dis This SCS Options > COR/APO Settings option controls the text (IDB Opt.126) mode used in the APO/COR function. In the APO/COR function, the print quality parameter is used (text mode on/off) to disable/enable computer output reduction mode. To print in computer output reduction mode, the print quality must be set to Data Processing (Text mode off).
Page 204 Option Value IDB Value User IDB parameter Comments Off * Normal IBM interpretation Ignore the system TEXT parameter Enable APO Observe TEXT parameter in APO as well User IDB command: TXTMOD <parameter>: Parameter: OFF, ON, APO User IDB language to set factory default: &%IDB_EDIT: TXTMOD OFF:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 126:0:EXIT...
Page 205: Cor Lsi Reduc (Idb Option 127)
COR LSI Reduc This SCS Options > COR/APO Settings option defines the line (IDB Option 127) spacing in Computer Output Reduction mode. The spacing is nor- mally set to 70% of the normal line spacing (100%). Option Value IDB Value User IDB parameter 70% * [1..100] User IDB command:...
Page 206: Scs Options > Misc Settings Menu: Options Overview
SCS OPTIONS > The MISC SETTINGS menu is a sub-menu under the SCS MISC SETTINGS OPTIONS menu. Menu: Options The following table lists menu options and sub-menus found under Overview the MISC SETTINGS menu. SCS OPTIONS>MISC SETTINGS Option name Values Country Code (IDB Option 2) International *, Belgium, Brazil, Can/Fre, Den/Nor, English (UK), Fin/Swe, France, Ger/Aus, Italy, Jap (Latin), Latin America, Portugal, Spain, USA/...
Page 207 SCS OPTIONS>MISC SETTINGS Option name Values Lines Per Page (IDB Option 107) 68 *, range: 1 - 255 Top Margin (IDB Option 108) 1 *, range: 1 - 255 Source Input (IDB Option 113) Tray 1 *, Tray 2, Tray 3, Tray 4, Tray 5 Forms Media (IDB Option 114) Prtr Setting *, Paper Media, Envelope Med Output Bin (IDB Option 115)
Page 208: Country Code (Idb Option 2)
Country Code This SCS Options > Misc Settings option defines the character (IDB Option 2) set. Country definition by Country Code was commonly used on System 36 and 38, and applications migrated from these systems. The International country code forms the basis for all country codes.
Page 209 Option Value IDB Value User IDB parameter Spain Latin America English (UK) User IDB command: DEFCNTCOD <parameter>: Parameter: 0 - 15 User IDB language to set factory default: &%IDB_EDIT: DEFCNTCOD 0:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 2:0:EXIT Operations - TN5250E SETUP: SCS OPTIONS >...
Page 210: Codepage (Idb Options 240 And 241)
Codepage (IDB This SCS Options > Misc Settings option defines the code page to Options 240 and be used. Country definition by "Code Page" is commonly used by 241) AS/400 and iSeries computers. If Euro Support has been enabled with the Euro Support (IDB Option 139) option, code pages 37, 273, 277, 278, 280, 284, 285,...
Page 211 Option Value IDB Values (Option 240 and 241) User IDB parameter OCR 340 84 + 1 Multi 500 * 244 + 1 Iceland 871 103 + 3 Code pages with Euro support below this line Turkey 1023 255 + 3 1023 USA/Can 1140 116 + 4...
Page 212 Parameter: 37 - 1149 as listed above User IDB language to set factory default: &%IDB_EDIT: DEFCODPAG 500:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 240:244: OPTION 241:1:EXIT Operations - TN5250E SETUP: SCS OPTIONS > MISC SETTINGS > Codepage (IDB Options 240 and...
Page 213: Font (Idb Options 242 And 243)
Font (IDB This SCS Options > Misc Settings option selects the current font Options 242 and using the Font ID. This option setting is usually overwritten by the 243) first control buffer from the system. Fonts in shaded rows may be loaded into printer memory. See the Download Font (IDB Option 244) option.
Page 214 Option Value (Font ID) Font Name IDB Value (Option 242 and 243) User IDB parameter Boldface It 155 + 0 Boldface 159 + 0 Essay 160 + 0 Essay Bold 163 + 0 Document 175 + 0 Got.Text 13 204 + 0 Prestige 15 221 + 0 Gothic 15...
Page 215 Option Value (Font ID) Font Name IDB Value (Option 242 and 243) User IDB parameter 1056 Son.Ser.It 10 32 + 4 1056 1351 Son.Ser. 12 71 + 5 1351 1653 Son.Ser.Bld 16 117 + 6 1653 2103 Son.Ser.Bld 24 35 + 8 2103 User IDB command: DEFFNT <parameter>:...
Page 216: Cpi (Idb Option 100)
CPI (IDB Option This SCS Options > Misc Settings option selects the CPI (charac- 100) ters per inch). Option Value IDB Value User IDB parameter 5 CPI 10 CPI * 12 CPI 15 CPI 16.7 CPI User IDB command: DEFCPI <parameter>: Parameter: 5, 10, 12, 15, 16 User IDB language to set factory default:...
Page 217: Max Print Pos (Idb Option 102)
Max Print Pos This SCS Options > Misc Settings option defines the maximum (IDB Option 102) horizontal print position. Option Value IDB Value User IDB parameter 80 * [1..254] User IDB command: DEFMPP <parameter>: Parameter: 1 - 254 User IDB language to set factory default: &%IDB_EDIT: DEFMPP 80:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 102:80:EXIT...
Page 218: Left Margin (Idb Option 103)
Left Margin (IDB This SCS Options > Misc Settings option defines the left margin in Option 103) characters. The character width depends on the setting of the (IDB Option 100) option. Option Value IDB Value User IDB parameter 1 * [1..255] User IDB command: DEFLFTMRG <parameter>: Parameter:...
Page 219: Right Margin (Idb Option 104)
Right Margin This SCS Options > Misc Settingsoption defines the right margin (IDB Option 104) in characters. The character width depends on the setting of the (IDB Option 100) option. Option Value IDB Value User IDB parameter 1 * [1..255] User IDB command: DEFRGTMRG <parameter>: Parameter:...
Page 220: Lpi (Idb Option 105)
LPI (IDB Option This SCS Options > Misc Settings option selects the number of 105) lines per inch (LPI). Option Value IDB Value User IDB parameter 3 LPI 4 LPI 6 LPI * 8 LPI 9 LPI User IDB command: DEFLPI <parameter>: Parameter: 3, 4, 6, 8, 9...
Page 221: Lines Per Page (Idb Option 107)
Lines Per Page This SCS Options > Misc Settings option defines the number of (IDB Option 107) lines per page. Option Value IDB Value User IDB parameter 68 * [1..255] User IDB command: DEFLPP <parameter>: Parameter: 0 - 255 User IDB language to set factory default: &%IDB_EDIT: DEFLPP 68:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 107:68:EXIT...
Page 222: Top Margin (Idb Option 108)
Top Margin (IDB This SCS Options > Misc Settings option defines the top margin in Option 108) lines. The line height depends on the setting of the LPI (IDB Option 105) option. Option Value IDB Value User IDB parameter 1 * [1..255] User IDB command: DEFTOPMRG <parameter>: Parameter:...
Page 223: Source Input (Idb Option 113)
Source Input This SCS Options > Misc Settings option selects the paper source (IDB Option 113) input tray. This setting will trigger definitions made by the Source Drawer ( ) command. SRCDRW The parameter values 6 - 8 cannot be selected via the operator panel.
Page 224: Forms Media (Idb Option 114)
Forms Media This SCS Options > Misc Settings option selects the paper tray. (IDB Option 114) The setting will trigger definitions made by the Select Media ( SLT- ) command. Option Value IDB Value User IDB parameter Prtr Setting * Paper Media Envelope Med User IDB command:...
Page 225: Output Bin (Idb Option 115)
Output Bin (IDB This SCS Options > Misc Settings option selects the paper output Option 115) bin. The setting will trigger definitions made by the Destination Drawer ( ) command. DSTDRW Option Value IDB Value User IDB parameter Prtr Setting * Output Bin 1 Output Bin 2 Output Bin 3...
Page 226: Simplex/Duplex (Idb Option 116)
Simplex/Duplex This SCS Options > Misc Settings option selects simplex or (IDB Option 116) duplex as the print setting. The setting will trigger definitions made by the Select Simplex/Duplex Printing ( ) command. The SLTSIMDUP tumble setting is used for pages connected or bound at the top. : The Duplex and Duplex (Tumble) settings display only on printers with duplex support.
Page 227 Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 116:0:EXIT Operations - TN5250E SETUP: SCS OPTIONS > MISC SETTINGS > Simplex/Duplex (IDB Option 116)
Page 228: Non-Print Char (Idb Option 3)
Non-Print Char This SCS Options > Misc Settings option defines the replacement (IDB Option 3) character to substitute for an unprintable character found in the data stream. The character is printed when the host sends an unprintable character or a character not supported by the SCS/TNe Emulation. Refer to “Appendix B - ASCII Character Table”...
Page 229: Scs Options > Paper Settings Menu: Options Overview
SCS OPTIONS > The PAPER SETTINGS menu is a sub-menu under the SCS PAPER OPTIONS menu. SETTINGS The following table lists menu options found under the PAPER SET- Menu: Options TINGS menu. Overview SCS Options > Paper Settings Option name Values Left Margin COR (IDB Opt.
Page 230: Left Margin Cor (Idb Opt. 78 & 79)
Left Margin COR This SCS options > Paper Settings option defines the offset to be (IDB Opt. 78 & added to the left margin when printing in Computer Output Reduc- tion mode (COR). COR is a feature that allows data processing reports to fit on A4 size paper.
Page 231 The option values for option 78 and 79 are calculated using the for- mulas below. × Marg. inch 1440 Reduce to nearest whole number. ---------------------------------------------- - × × Round off to Marg. inch 1440 – 256 Value stored in option 79 nearest whole number.
Page 232: Top Margin Cor (Idb Opt. 80 & 81)
Top Margin COR This SCS options > Paper Settings option defines the offset to be (IDB Opt. 80 & added to the top margin when printing in Computer Output Reduc- tion mode (COR). COR is a feature that allows data processing reports to fit on A4 size paper.
Page 233 The option values for option 80 and 81 are calculated using the for- mulas below. × Marg. inch 1440 Reduce to nearest whole number. ---------------------------------------------- - × × Round off to Marg. inch 1440 – 256 Value stored in option 81 nearest whole number.
Page 234: Left Margin Lan (Idb Opt. 86 & 87)
Left Margin Lan This SCS options > Paper Settings option defines the offset to be (IDB Opt. 86 & added to the left margin when printing in Landscape mode. 1 inch = 1440. Option Value (1/1440 inch) IDB Values (Option 86 and 87) User IDB parameter 0 * [0..2880] 0 + 0 User IDB command:...
Page 235 The option values for option 86 and 87 are calculated using the for- mulas below. × Marg. inch 1440 Reduce to nearest whole number. ---------------------------------------------- - × × Round off to Marg. inch 1440 – 256 Value stored in option 87 nearest whole number.
Page 236: Top Margin Lan (Idb Opt. 88 & 89)
Top Margin Lan This SCS options > Paper Settings option defines the offset to be (IDB Opt. 88 & added to the top margin when printing in Landscape mode. 1 inch = 1440. Option Value (1/1440 inch) IDB Values (Option 88 and 89) User IDB parameter 147 * [0..2880] 147 + 0 0.10...
Page 237 The option values for option 88 and 89 are calculated using the for- mulas below. × Marg. inch 1440 Reduce to nearest whole number. ---------------------------------------------- - × × Round off to Marg. inch 1440 – 256 Value stored in option 89 nearest whole number.
Page 238: Page Length (Idb Opt. 82 & 83)
Page Length This SCS options > Paper Settings option defines the page length (IDB Opt. 82 & used by the APO/COR (Automatic Page Orientation function/Com- puter Output Reduction) to calculate page orientation. Option Value (1/1440 inch) IDB Values (Option 82 and 83) User IDB parameter 16848 * [1..65535] 208 + 65 11.70...
Page 239 Parameter 2: Value in inches [0.00 .. 45.51] or centimeters [0.00 .. 115.60] with 2 decimals User IDB language to set factory default: &%IDB_EDIT: PAGLNG I 11.70:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 82:208: OPTION 83:65:EXIT The option values for option 82 and 83 are calculated using the for- mulas below.
Page 240: Page Width (Idb Opt.84 & 85)
Page Width (IDB This SCS options > Paper Settings option defines the page width Opt.84 & 85) used by the APO/COR (Automatic Page Orientation function/Com- puter Output Reduction) to calculate page orientation. Option Value (1/1440 inch) IDB Values (Option 84 and 85) User IDB parameter 11908 * [1..65535] 132 + 46 8.27...
Page 241 Parameter 2: Value in inches [0.00 .. 45.51] or centimeters [0.00 .. 115.60] with 2 decimals User IDB language to set factory default: &%IDB_EDIT: PAGWDT I 8.27:EXIT Advanced IDB language to set factory default: &%IDB_EDIT: OPTION 84:132: OPTION 85:46:EXIT The option values for option 84 and 85 are calculated using the for- mulas below.
Page 242: Test Options Menu: Options Overview
TEST OPTIONS The TEST OPTIONS menu is a sub-menu directly under the Menu: Options TN5250E SETUP menu. Overview The following table lists menu options found under the TEST OPTIONS menu. Option name Values SCS5250 Hex Normal Mode *, Hex Dump-Mode Dump Print 5250 IDB Do Not Print *, Print...
Page 243: Scs5250 Hex Dump
SCS5250 Hex This Test option enables hex tracing for diagnosing print job prob- Dump lems. When hex dump mode is selected, all data sent to the printer is printed in hexadecimal and character representation. Control codes are not executed. SCS Debug Trace option overrides this option.
Page 244: Print 5250 Idb
Print 5250 IDB This Test option prints a report listing the current IDB settings. Print this report when asked by technical support representatives. Option Value Comments Do Not Print Do not print the IDB settings. This performs the same action as if Back had been pressed in the operator panel.
Page 245: Scs5250 Defaults
SCS5250 This Test option restores the TN5250E SCS OPTIONS settings to Defaults their factory default values. Option Value Comments Do Not Restore * Do not restore any settings. This performs the same action as if Back had been pressed in the operator panel.
Page 246: Idb Basics
IDB Basics Introduction On-line programming of the SCS options received through the SCS emulation expands the possibilities for adapting the SCS/TNe Emu- lation to existing applications. The SCS options are programmed using the IDB language. IDB is short for Intermate Data Base and refers to the SCS/TNe Emula- tion’s storage of all SCS protocol conversion tables.
Page 247 In addition, the TN5250E users have a second language available. This is the User IDB Language, which is somewhat easier to use. However, the User IDB Language is only available for working on approximately 20 of the most common IDB options. Working with the other options requires the use of the Advanced IDB Language.
Page 248: Other References
Other Sample IDB command strings, which set the options to their default References settings, are written after each option description in chapter “Opera- tions Reference - TN3270E SETUP” on page 85 and in chapter “Operations Reference - TN5250E SETUP” on page 155.
Page 249: Idb Languages Usage
IDB Languages Usage The two IDB languages work in similar ways. The differences lie in the syntax. When an option is altered with one of the IDB command languages, the configuration data is sent as text to the SCS/TNe Emulation. Rules for configuration data Send the data to the SCS/TNe Emulation device using a word processing system (eg OfficeVision) or simply by typing...
Page 250 Syntax The commands used for entering and leaving configuration mode are common to the two languages. Enter configuration mode by sending the command: &%IDB_EDIT: and leave configuration mode, by sending the trailer string: EXIT This causes the changed options to be saved. The new option set- tings are active on the next SCS job.
Page 251 Programming examples Advanced IDB (TN3270E + TN5250E) User IDB (TN5250E) Valid &%IDB_EDIT:<lf><ff> &%IDB_EDIT:<lf><ff> OPTION 2:2:<LF> DEFCODPAG 37:<lf> OPTION 100:10:EXIT PRTEMUL 5219:CORDRW 2 COR:EXIT &%IDB_EDIT:OPTION 2:13: &%IDB_EDIT:DEFCNTCOD 13: OPTION 103:5:EXIT DEFLFTMRG 5:EXIT Invalid &%IDB_EDIT<ff>: &%IDB_EDIT<ff>: OPTION 2:2:EXIT DEFCODPAG 37:EXIT &%IDB_EDIT:OPTION2:2:EXIT &%IDB_EDIT:DEFCODPAGE37:EXIT &%IDB_EDIT:OPTION 2:2EXIT &%IDB_EDIT:DEFCODPAG 37EXIT &%idb_edit:OPTION 2:2:EXIT...
Page 252: Idb Configuration File Management
This approach is perhaps the most convenient as the contents of all Configuration IDB options and events are viewed and edited on a PC screen. After File the editing is done, it is possible to save the settings in a file. The resulting IDB Configuration File can then be downloaded to one or Management more printers containing an SCS/TNe Emulation providing easy,...
Page 253: Retrieving The Idb Configuration File
Retrieving the IDB The IDB settings controlling how SCS jobs print can be retrieved via FTP. The name of the file is fixed and cannot be changed. Configuration File The procedure below uses a Microsoft FTP client. To retrieve the IDB settings file Start a FTP session.
Page 254 End the FTP session. IDB Basics: Retrieving the IDB Configuration File...
Page 255: Editing The Idb Configuration File
Editing the IDB The utility program used for editing the IDB configuration file is DOS based and is available on the internet site with manual updates Configuration File listed in “Support” on page 4. Look for the following files. Protocol File Comments TN3270E...
Page 256: Storing The Idb Configuration File
Storing the IDB When the IDB configuration file has been edited it can be down- loaded to the SCS/TNe Emulation. Configuration File The download file name is fixed. Downloading a file with a different name will result in an unreadable printout. No IDB settings will be changed.
Page 257 Store the IDB configuration file. (TN3270E users) put c:\tn3270e.idb (TN5250E users) put c:\tn5250e.idb This stores the file from a PC’s root directory. End the FTP session. The downloaded IDB settings are active on the next SCS job. IDB Basics: Storing the IDB Configuration File...
Page 258: Additional Tn5250E Printer Commands Using Idb
Additional TN5250e Printer Commands Using IDB Introduction The IDB commands described here provide additional commands for controlling the printer. This chapter presents the syntax for creating these commands, which must be sent from the AS/400 or iSeries in order to be recog- nized, i.e.
Page 259: Input Data String Syntax
Input Data String The input data string ( ) following some printer commands <data> Syntax can contain three parts: Text, decimal numbers, and hexadecimal numbers. Text: Text has to be put in quotation marks. "This is a text" Decimal: Decimal numbers are entered normally. Use commas to separate.
Page 260: Initializing - Power On Initialize
Initializing - Before working with the additional commands, you need to familiar- Power On ize yourself with the Power On Initialization. This is used to set up Initialize the printer each time it is powered On. With the Power On events, it is possible to set up four strings of 1024 bytes each which are sent to the printer at power On.
Page 261 The command corresponds to event 0 - 3. Command: POWON <parameter> <data>: Delete command POWON DEL <no.>: Parameter: Definition number 1 - 4 Example: POWON 3 "Power initialize 3": POWON DEL 3: The rest of this chapter is devoted to a run-through of the com- mands you can work with.
Page 262: Paper Handling > Source Drawer
Paper Handling This is triggered by the AS/400 or iSeries command (Page Pre- > Source Drawer sentation Media) when a specific input tray is selected. It can also be triggered by the command at Power On. See section DEFSRCDRW “Source Input (IDB Option 113)” on page 225.
Page 263: Paper Handling > Destination Drawer
Paper Handling This is triggered by the AS/400 or iSeries command (Page Pre- > Destination sentation Media) when a certain output drawer (bin) is selected. It Drawer can also be triggered by the command at Power On. DEFDSTDRW See section “Output Bin (IDB Option 115)”...
Page 264: Paper Handling > Select Paper / Envelope Media
Paper Handling This is triggered by the AS/400 or iSeries command (Page Pre- > Select Paper / sentation Media) when printing on paper or envelopes is selected. It Envelope Media can also be triggered by the command at Power On. DEFFRMSEL See section “Forms Media (IDB Option 114)”...
Page 265: Paper Handling > Select Paper Feed
Paper Handling This is triggered by the AS/400 or iSeries command (Set Print SPSU > Select Paper Setup) when a certain kind of paper feed is selected. Feed The command corresponds to event 64 - 65. Command: SLTPAPFED <parameter> <data>: Delete command SLTPAPFED DEL <feed>: Parameter:...
Page 266: Paper Handling > Select Simplex/Duplex Printing
Paper Handling This is used when simplex or duplex printing is selected. The com- > Select mand can only be used if the printer supports duplex printing. Simplex/Duplex It is triggered by the AS/400 or iSeries command (Page Presen- Printing tation Media) when simplex or duplex printing is selected.
Page 267: Code Page 259 > Before/After
Code Page 259 > Code page 259 is a character set which only contains symbols and Before/After signs. Most of the symbols and signs are not contained in the nor- mal character set of the printer which means that they cannot be used from AS/400 or iSeries.
Page 268 Parameter: Before code page 259 selection After code page 259 selection Example: COD259 BEF "Command": COD259 DEL AFT: TN5250e Printer Commands Using IDB: Code Page 259 > Before/After...
Page 269: Miscellaneous > Overlay Command
Miscellaneous When overlay call is enabled with the command, command OVLCAL > Overlay 1 or 2 is executed at the top of each page immediately before the Command first printable character. See section “Overlay Call (IDB Option 28)” on page 179.
Page 270: Miscellaneous > Before / After Formfeed
Miscellaneous Command: > Before / After BEFAFTFED <parameter> <data>: Formfeed Delete command BEFAFTFED DEL <parameter>: Parameter: Before formfeed After formfeed Example: BEFAFTFED BEF "Command": BEDAFTFED DEF AFT: TN5250e Printer Commands Using IDB: Miscellaneous > Before / After Formfeed...
Page 271: Miscellaneous > Before Portrait/Landscape Selection
Miscellaneous This command corresponds to events 147 and 148. Event 147 is > Before triggered after event 69. Event 148 is triggered after event 70. Portrait/ Event 69 and 70 are always triggered. Events 147 and 148 provide Landscape additional triggering capacity if triggering of event 69 or 70 is insuffi- Selection cient.
Page 272: Miscellaneous > Idbdump/Hexdump Subtitle
Miscellaneous This is used as an extra headline when printing IDB and hex dumps > IDBdump/ The command is executed on the top of the first page. It may be Hexdump used for stating specific information on the front page. This could be Subtitle information describing which IDB profile is used, printer type, or company name.
Page 273: Miscellaneous> Move To Uppermost Line
Miscellaneous This is used if a movement upwards is needed in order to reduce > Move to the top margin. The string is only sent if the print position is placed Uppermost at line 1 and no characters have been printed. The contents of the string could be PCL codes like: Line Top margin setting to uppermost line.
Page 274: Warranty
Warranty included with The limited warranty you received with your printer gives warranty the printer terms and conditions. For warranty information, refer to your printer documentation. Warranty: included with the printer...
Page 275: Specifications, Requirements, Features
Appendix A - Specifications, Requirements, Features Product The SCS/TNe Emulation is an option which is installed in the printer Description optional firmware connector; the Card also provides IPDS emulation (see separate documentation). With the Card and a Standard Network or a MarkNet internal print server (Ethernet), the printer becomes an IBM AS/400, iSeries, or Mainframe host workstation printer capable of printing SCS docu- ments received over a LAN connection.
Page 276: Compatibility
Compatibility IBM Printer Emulations 3270 SCS: IBM 3287/3812 in LU1 mode • 5250 SCS: IBM 3812-01 • Compatible Print Servers Standard Network for connection to an Ethernet LAN. • MarkNet internal print server (Ethernet) • Appendix - Specifications, Requirements, Features: Compatibility...
Page 277: Print Platforms
Print Platforms Mainframe Software IBM Communications Server for OS/390 V2R5 or greater • IBM Communications Server for MVS with TCP/IP for MVS • V3R2 or greater IBM Communications Server for VM/ESA V2R4, TCP/IP func- • tion level 310 or greater IBM Communications Server for VTAM V4R4 or greater •...
Page 278: Features List: 3270 Scs
Features List: Features supported are dependent upon host software for selection 3270 SCS and use. SCS (LU1) data stream • 5 bin paper input • EBCDIC character conversion • Text string conversion • IBM and 3rd party ASCII transparency modes •...
Page 279: Features List: 5250 Scs
Features List: Features supported are dependent upon host software for selection 5250 SCS and use. SCS and SCS/DCA L2 data streams • 5 bin paper input and duplex • Computer Output Reduction (COR) / Automatic Page Orienta- • tion (APO) IBM font selection using FGID or CPI •...
Page 280: Ascii Character Table
Appendix B - ASCII Character Table Printable The table shows all ASCII printable characters. Characters ASCII Decimal Hex ASCII Decimal Hex ASCII Decimal Hex ASCII Decimal space " < & > ’ Appendix - ASCII Character Table: Printable Characters...
Page 281 ASCII Decimal Hex ASCII Decimal Hex ASCII Decimal Hex ASCII Decimal ‘ Appendix - ASCII Character Table: Printable Characters...
Page 282: Special Tn3270E Idb Commands
Appendix C - Special TN3270e IDB Commands How to Print an From a Ready status in the operator panel press the MENU IDB Report button. Use the navigation buttons: Option Card Menu > SCS/TNe MENU > TN3270E SETUP > TEST OPTIONS > SCS IDB Dump >...
Page 283: List Of Commands
List of Larger numbers indicate higher precedence. Commands Precedence Command Comments Enter hex-dump mode (small format) <CSC>HEXDUMP Enter hex-dump mode (large format) <CSC>HEXDUMP_FULL Enter IDB edit mode <CSC>IDB_EDIT Dump IDB (small format) <CSC>IDB_PRINT Dump IDB (large format) <CSC>IDB_PRINT_FULL Reserved, active if option 31 = 0 <CSC>L{xx} Reserved, active if option 31 = 0 <CSC>W{xx}...
Page 284 Precedence Command Comments Double CSC (prints <CSC>) <CSC><CSC> Single transparent character <CSC>{XY} Refer to the chapter on Understanding the Control Panel (page 10) if necessary. Appendix - TN3270e IDB Commands: List of Commands...
Page 285: Cor/Apo Logic (Tn5250E)
Appendix D - COR/APO Logic (TN5250e) Introduction The SCS/TNe Emulation (TN5250e) can rotate the printout from portrait to landscape based on menu option settings. The distinction is between control of text, orientated according to a set text orientation command (STO) in the data stream (the FCB - format control buffer) and control of the text orientation from the text orientation automatic of the SCS/TNe Emulation.
Page 286: Details
is assumed that no STO commands are present in the data stream from the system. The STO commands always take priority over the automatic controls of the printer. Details The following points refer to the flowchart in the end of this appen- dix.
Page 287 PAGLNG = A4 PAGWDT = A4 If the page format stated in the FCB is within (or equal to) the page size settings of the option settings, PAGLNG PAGWDT the page size is "valid". In that case the printout will be in landscape provided the page length is smaller than the width, otherwise it will be in portrait.
Page 288 10 pitch fonts are reduced to 13 pitch (font type stated • in font table position no. 51) 12 pitch fonts are reduced to 15 pitch (font type stated • in font table position no. 52) 15 pitch fonts are reduced to 20 pitch (font type stated •...
Page 289 The previously mentioned "screen dump" will use the default printer profile on the AS/400 or iSeries for the device. On the AS/400 or iSeries it is possible to affect the system print parameters in the FCB by changing the printer file containing default settings for the device. This is done by either changing the existing system printer file ) or creating your own printer QSYSPRT...
Page 290: Flowchart
Example: Disable COR and set Portrait as default orientation for drawer 2 only. CORDRW 2 = OFF ORTDRW 2 = POR Flowchart See next page. Appendix - COR/APO Logic (TN5250e): Flowchart...
Page 291 Page Orientation Logic Flowchart Appendix - COR/APO Logic (TN5250e): Flowchart...
Page 292: Special Tn5250E Idb Commands
Appendix E - Special TN5250e IDB Commands How to Print an From a Ready status in the operator panel press the MENU IDB Report button. Use the navigation buttons: Option Card Menu > SCS/TNe MENU > TN5250E SETUP > TEST OPTIONS > Print IDB Dump >...
Page 293: List Of Commands
List of Larger numbers indicate higher precedence. Commands Precedence Command Comments Enter IDB edit mode <CSC>IDB_EDIT Dump IDB (small format) <CSC>IDB_PRINT Dump IDB (large format) <CSC>IDB_PRINT_FULL Enter Intermate transparent mode <CSC>/... Suppress format control codes <CSC>+<CSC> Standard handling of format control <CSC>-<CSC>...
Page 294: Managing The Scs Tn5250E Font Table
Appendix F - Managing the SCS TN5250e Font Table Introduction The SCS/TNe Emulation has a programmable font table, which con- tains the conversion between the IBM font IDs (sent from the sys- tem) to the internal fonts used in the printer. The font table has a limit of 50 fonts + 3 fonts used for COR (Computer Output Reduc- tion).
Page 295 The SCS/TNe Emulation has six PCL soft fonts emulating IBM fonts. The font FGIDs are 3 (OCR-B), 155 (Boldface Italic), 159 (Boldface), 163 (Essay Bold), 160 (Essay) and 175 (Document) which may be loaded into printer memory at Power On. The font table is prepared for using these fonts.
Page 296: The "Font" Programming Command
The "Font" This command corresponds to the advanced IDB language FONT Programming command. Command Command: PRGFNT <Ibmfont> <Spacing> <String>: PRGFNT DEL <IBMfont>: : Try to avoid deleting the first 7 fonts listed in the status printout ( ), as these &%IDB_STATUS fonts represent the substitution font IDs set by the...
Page 297 Parameters: <Ibmfont> 0-65535 This value indicates the IBM font sent from the sys- tem. Note that the IBM font numbers are divided into the groups below. pitch area IBM fonts 10 pitch: 1-65 12 pitch: 66-153 proportional: 154-200 13 pitch: 201-210 15 pitch: 211-239...
Page 298 <String> This can contain all characters and has a maximum length of 255 characters. It has to be programmed the same way as printer command input data. The <String> parameter is optional. No string definition will delete the definition of an existing font. : Please notice that the SCS/TNe Emulation always sends a character spacing command after the entire font command.
Page 299 Selection of "P" causes the printer to handle the character spacing. If "P" is selected in connection with programming of a font in the IBM proportional spaced area (154-200), the SCS/TNe Emulation prepares itself for sup- port for downloaded IBM PS fonts. This ensures correct spacing of downloaded pro- portional spaced fonts.
Page 300 The downloaded font 10175 is sent when IBM font ID 160 (Essay) is sent from the system. Font ID 160 is within the "proportional spaced" font area, and font 10175 is expected to be 100% IBM compatible as to the character spacing: PRGFNT 160 P /1B,"(s1p12.72v0s0b202T": Delete all previous font definitions in order to make room for new font definitions:...
Page 301: Set Substituted Font Id
Set Substituted If a font ID sent from the system is not found in the font table, the Font ID font is substituted with a similar font defined in a special area of the font table. The first 7 font positions listed in the status printout ) represent the substitution fonts for the following &%IDB_STATUS areas.
Page 302 Parameter: 1 - 249 Example: SETSUBFNT 86 : Font 86 needs to be present in the font table prior to this command. The entire font definition (incl. string before/after etc.) is transferred to font table position 3. For instance, if IBM font 67 was the font previously stated in position 3, this is moved to another position in the font table.
Page 303: Edition Notice
User’s Guide The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL, INC. AND KODAK PROVIDE THIS PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Page 304 Ricoh Co., Ltd in the United States, other coun- tries, or both. Lexmark and Lexmark with diamond design, MarkNet and MarkVi- sion are trademarks of Lexmark International, Inc. registered in the United States and/or other countries. Intermate is a trademark of Kodak.
Page 305: Table Of Contents
Table of Contents Card for IPDS and SCS/TNe - SCS/TNe Emulation User’s Guide Getting Started ..............................1 SCS/TNe in a LAN environment ..........................1 Documentation Overview ............................1 Equipment Requirements and Specifications ......................2 Support ................................4 Customer Support ..................................4 Important Configuration Basics ........................5 Introduction ................................
Page 306 Installation Setup for Mainframe Users ......................26 Introduction ................................26 Task 1A - Configuring the Host ..........................28 Task 1B - Configuring the Host for Printing via a SNA Server ................32 Task 2A - Configuring a Host For TN3270e Printing ....................34 Task 2B - Configuring an SNA Server For TN3270e Printing .................
Page 307 Reset ALL Def ................................. 82 Operations Reference - TN3270E SETUP ....................83 Introduction ................................83 NETWORK SETUP Menu: Options Overview ......................87 Print Active ................................88 TN3270 Defaults ..............................89 Connect Status ................................ 90 NETWORK SETUP> SERVER INFO Menu: Options Overview ................93 Name / IP Address ..............................
Page 308 Line Spacing (IDB Option 106) ..........................120 LPP (IDB Option 107) ............................121 Transparency (IDB Option 167) ..........................122 Form Strings (IDB Option 168) ..........................123 IBM Trn Code (IDB Option 169 bit 1) ........................124 Leadin Sequence (IDB Option 169 bit2) ....................... 125 Euro Support (IDB Event 191) ..........................
Page 309 Operations Reference - TN5250E SETUP ....................153 Introduction ................................153 CONNECTION # Menu: Options Overview ......................157 Print # Active ................................. 158 TN5250## Default ..............................159 Connect # Status ..............................160 CONNECTION # > SERVER # INFO Menu: Options Overview ................163 Name / IPaddress # ..............................
