Adf Media Pinch Pad Assembly Removal - Lexmark X651de Service Manual

7462

ADF media pinch pad assembly removal

1. Remove the ADF duplex CCD assembly. See
X658)" on page
2. Remove the ADF pinch roll assembly. See
3. Remove the ADF turn guide. See
4. Remove the four screws (A) securing the ADF media pinch pad assembly.
A
5. Remove the ADF media pinch pad assembly.
Service Manual
4-70
4-65. .
"ADF pinch roll assembly removal" on page
"ADF turn guide removal" on page
"ADF duplex CCD assembly removal (X654, X656, and
4-67.
