CDM-600 Satellite Modem
Front Panel Operation
6.3.3

INFORMATION

INFO: ALL ID FORMAT TX RX CLOCKS
DROP
Select information to view using the [←][→] arrow keys, then press ENTER.
Note: INFO screens display information on the current configuration of the modem
without risking inadvertent changes.
INFO:ALL
This menu permits the user to view the configuration of the unit, in a step-by-step process
by scrolling through each menu in succession. Press ENTER to continue through all the
configurations.
Note that the user may only view the configurations – no editing is possible.
Press CLEAR to discontinue.
INFO: ID
MODEM CIRCUIT ID:
----A TEST MESSAGE TO SHOW CIRCUIT ID---
This displays the user-defined Circuit ID string (40 characters), which is entered via the
UTILITY, ID screen. To return to the previous menu, press ENTER.
INFO: MODE
INFO:
An example of a Mode Information screen is shown above.
INSERT REMOTE
ALL = START
(STOP, START)
MODE: TX = G.703B: DROP
RX = G.703B: INSERT (B8ZS)
ALARM-MASK
6–32
MN/CDM600.IOM
EDMAC
MISC
(B8ZS)
Revision 7
