Comtech EF Data CDM-600 Installation And Operation Manual page 230

CDM-600 Satellite Modem
ODU Operation
D.2.9 (ODU,ENABLE,1:1,CSAT#1,CONFIG)
(ODU,ENABLE,1:1,CSAT#2,CONFIG)
(ODU,ENABLE,STANDALONE CSAT,CONFIG)
RX: FREQ=3600.0 MHz
Use the [←] or [→] arrow keys to select the parameter to edit. Use the [↑] or [↓] keys to
edit the parameter, then press ENTER to implement, or CLEAR.
The user may edit the RX Frequency, the RX Attenuation or the Mute setting. The Slope
parameters are edited in another menu, so use the [←] or [→] keys to select Slope and
press ENTER.
D.2.10 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RX)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RX)
(ODU,ENABLE,STANDALONE CSAT,CONFIG,RX) SLOPE
RX SLOPE:
Use the [←] or [→] keys to select the parameter to edit. Use the [↑] or [↓] keys to edit
the parameter, then press ENTER to implement, or CLEAR.
The slope mode may be either CALIBRATED or MANUAL. If MANUAL is selected,
the slope may be edited.
ATT=18.00 dB
MUTE=UNMUTED
MODE=MANUAL (MANUAL,CAL)
SLOPE=0.2 (0.0 - 1.0)
D–6
RECEIVER
RECEIVER
RECEIVER
SLOPE
SLOPE
SLOPE
Revision 7
MN/CDM600.IOM
