Signal Definitions
3.4.16 GPIO Interface Signals
Signal Name Ball No.
GPIO0 D11
GPIO1 D10
N30
GPIO6 D28
GPIO7 C30
GPIO8 C31
GPIO9 C28
GPIO10 B29
GPIO11 AJ8
GPIO12 N29
GPIO13 M29
GPIO14 D9
GPIO15 A8
GPIO16 V31
GPIO17 A10
GPIO18 AG1
GPIO19 C9
GPIO20 A9
N31
GPIO32 M28
GPIO33 L31
GPIO34 L30
GPIO35 L29
GPIO36 L28
GPIO37 K31
GPIO38/IRRX2 K28
GPIO39 J31
GPIO40 Y3
GPIO41 W4
AMD Geode™ SC3200 Processor Data Book
Type Description
I/O GPIO Port 0. Each signal is configured independently as
an input or I/O, with or without static pull-up, and with
either open-drain or totem-pole output type.
A debouncer and an interrupt can be enabled or masked
for each of signals GPIO[00:01] and [06:15] indepen-
dently.
Note: GPIO12, GPIO13, GPIO16 inputs: If GPIOx func-
tion is selected but not used, tie GPIOx low.
I/O GPIO Port 1. Each signal is configured independently as
an input or I/O, with or without static pull-up, and with
either open-drain or totem-pole output type.
A debouncer and an interrupt can be enabled or masked
for each of signals GPIO[32:41] independently.
32581C
Mux
TRDE#
IOCS1#+TFTD12
AB1D+IOCS1#
DTR2#/BOUT2+
IDE_IOR1#+
SDTEST5
RTS2#+IDE_DACK1#
+SDTEST0
CTS2#+IDE_DREQ1
+SDTEST4
DCD2#+IDE_IOW1#+
SDTEST2
DSR2#+IDE_IORDY1
+SDTEST1
RI2#+IRQ15
AB2C
AB2D
IOR#+DOCR#
IOW#+DOCW#
PC_BEEP+
F_DEVSEL#
IOCS0#+TFTDCK
DTR1#/BOUT1
INTC#+IOCHRDY
DOCCS#+TFTD0
AB1C+DOCCS#
LAD0
LAD1
LAD2
LAD3
LDRQ#
LFRAME#
LPCPD#
SERIRQ
IDE_DATA8
IDE_DATA11
