32581C
Table 2-2. SC3200 Memory Controller Registers (Continued)
Bit
Description
GX_BASE+8408h-840Bh
31:16
RSVD (Reserved). Write as 0070h
15
RSVD (Reserved). Write as 0.
14
SODIMM_MOD_BNK (SODIMM Module Banks - Banks 0 and 1). Selects number of module banks installed per SODIMM
for SODIMM:
0: 1 Module bank (Bank 0 only)
1: 2 Module banks (Bank 0 and 1)
13
RSVD (Reserved). Write as 0.
12
SODIMM_COMP_BNK (SODIMM Component Banks - Banks 0 and 1). Selects the number of component banks per
module bank for SODIMM:
0: 2 Component banks
1: 4 Component banks
Banks 0 and 1 must have the same number of component banks.
11
RSVD (Reserved). Write as 0.
10:8
SODIMM_SZ (SODIMM Size - Banks 0 and 1). Selects the size of SODIMM:
000: 4 MB
001: 8 MB
This size is the total of both banks 0 and 1. Also, banks 0 and 1 must be the same size.
7
RSVD (Reserved). Write as 0.
6:4
SODIMM_PG_SZ (SODIMM Page Size - Banks 0 and 1). Selects the page size of SODIMM:
000: 1 KB
001: 2 KB
Both banks 0 and 1 must have the same page size.
3:0
RSVD (Reserved). Write as 0.
GX_BASE+840Ch-840Fh
31
RSVD (Reserved). Write as 0.
30:28
LTMODE (CAS Latency). CAS latency is the delay, in SDRAM clock cycles, between the registration of a read command
and the availability of the first piece of output data. This parameter significantly affects system performance. Optimal setting
should be used. If an SODIMM is used, BIOS can interrogate EEPROM across the ACCESS.bus interface to determine this
value:
000: Reserved
001: Reserved
This field will not take effect until SDRAMPRG (bit 0 of MC_MEM_CNTRL1) transitions from 0 to 1.
27:24
RC (RFSH to RFSH/ACT Command Period, tRC). Minimum number of SDRAM clock between RFSH and RFSH/ACT
commands:
0000: Reserved
0001: 2 CLK
0010: 3 CLK
0011: 4 CLK
23:20
RAS (ACT to PRE Command Period, tRAS). Minimum number of SDRAM clocks between ACT and PRE commands:
0000: Reserved
0001: 2 CLK
0010: 3 CLK
0011: 4 CLK
19
RSVD (Reserved). Write as 0.
18:16
RP (PRE to ACT Command Period, tRP). Minimum number of SDRAM clocks between PRE and ACT commands:
000: Reserved
001: 1 CLK
15
RSVD (Reserved). Write as 0.
14:12
RCD (Delay Time ACT to READ/WRT Command, tRCD). Minimum number of SDRAM clock between ACT and READ/
WRT commands. This parameter significantly affects system performance. Optimal setting should be used:
000: Reserved
001: 1 CLK
20
MC_BANK_CFG (R/W)
010: 16 MB
100: 64 MB
011: 32 MB
101: 128 MB
010: 4 KB
1xx: 16 KB
011: 8 KB
111: SODIMM not installed
MC_SYNC_TIM1 (R/W)
010: 2 CLK
100: 4 CLK
011: 3 CLK
101: 5 CLK
0100: 5 CLK
1000: 9 CLK
0101: 6 CLK
1001: 10 CLK
0110: 7 CLK
1010: 11 CLK
0111: 8 CLK
1011: 12 CLK
0100: 5 CLK
1000: 9 CLK
0101: 6 CLK
1001: 10 CLK
0110: 7 CLK
1010: 11 CLK
0111: 8 CLK
1011: 12 CLK
010: 2 CLK
100: 4 CLK
011: 3 CLK
101: 5 CLK
010: 2 CLK
100: 4 CLK
011: 3 CLK
101: 5 CLK
110: 256 MB
111: 512 MB
110: 6 CLK
111: 7 CLK
1100: 13 CLK
1101: 14 CLK
1110: 15 CLK
1111: 16 CLK
1100: 13 CLK
1101: 14 CLK
1110: 15 CLK
1111: 16 CLK
110: 6 CLK
111: 7 CLK
110: 6 CLK
111: 7 CLK
AMD Geode™ SC3200 Processor Data Book
Architecture Overview
Reset Value: 41104110h
Reset Value: 2A733225h
