Displaying Ethernet OAM Protocol Information

Command
Step 8
ethernet oam link-monitor high threshold action
error-disable-interface
Step 9 exit
Step 10 interface interface-id
Step 11
source-template template-name
Step 12 end
Step 13 show ethernet oam status [interface interface-id]
Step 14 copy running-config startup-config
The switch does not support monitoring egress frames with CRC errors. The ethernet oam link-monitor
transmit-crc {threshold {high {high-frames | none} | low {low-frames}} | window milliseconds}
command is visible on the switch and you can enter it, but it is not supported. Use the no form of each
command to remove the option from the template. Use the no source-template template-name to remove
the source template association.
Displaying Ethernet OAM Protocol Information
You can use the privileged EXEC commands in
information.
Table 32-4 Displaying Ethernet OAM Protocol Information
Command
show ethernet oam discovery [interface interface-id] Displays discovery information for all Ethernet OAM interfaces or
show ethernet oam statistics [interface interface-id] Displays detailed information about Ethernet OAM packets.
show ethernet oam status [interface interface-id]
show ethernet oam summary

Understanding E-LMI

Ethernet Local Management Interface (E-LMI) is a protocol between the customer-edge (CE) device and
the provider-edge (PE) device. It runs only on the PE-to-CE UNI link and notifies the CE device of
connectivity status and configuration parameters of Ethernet services available on the CE port. E-LMI
interoperates with an OAM protocol, such as CFM, that runs within the provider network to collect OAM
status. CFM runs at the provider maintenance level (UPE to UPE with up MEPs at the UNI).
Cisco ME 3800X and 3600X Switch Software Configuration Guide
32-32
Chapter 32
Purpose
(Optional) Configure the switch to put an interface in an
error disabled state when a high threshold for an error is
exceeded.
Return to global configuration mode.
Define an Ethernet OAM interface, and enter interface
configuration mode.
Associate the template to apply the configured options to
the interface.
Return to privileged EXEC mode.
Verify the configuration.
(Optional) Save your entries in the configuration file.
Table 32-4
Purpose
the specified interface.
Displays Ethernet OAM configuration for all interfaces or the
specified interface.
Displays active Ethernet OAM sessions on the switch.
Configuring Ethernet OAM, CFM, and E-LMI
to display Ethernet OAM protocol
OL-23400-01
