Managing and Displaying Ethernet CFM Information

Command
Step 11
ip sla schedule operation-number [ageout seconds]
[life {forever | seconds}] [recurring] [start-time
{hh:mm {:ss} [month day | day month] | pending |
now | after hh:mm:ss}]
Step 12 end
Step 13 show ip sla configuration [operation-number]
Step 14 copy running-config startup-config
To remove an IP SLAs operation, enter the no ip sla operation-number global configuration command.
Managing and Displaying Ethernet CFM Information
You can use the privileged EXEC commands in these tables to clear Ethernet CFM information.
Table 32-1 Clearing CFM Information
Command
clear ethernet cfm ais domain domain-name
mpid id {vlan vlan-id | port}
clear ethernet cfm ais link-status interface
interface-id
clear ethernet cfm error
You can use the privileged EXEC commands in
Cisco ME 3800X and 3600X Switch Software Configuration Guide
32-20
Purpose
Schedule the time parameters for the IP SLAs operation.
operation-number—Enter the IP SLAs operation
•
number.
• (Optional) ageout seconds—Enter the number of
seconds to keep the operation in memory when it is not
actively collecting information. The range is 0 to
2073600 seconds. The default is 0 seconds.
• (Optional) life—Set the operation to run indefinitely
(forever) or for a specific number of seconds. The
range is from 0 to 2147483647. The default is 3600
seconds (1 hour)
• (Optional) recurring—Set the probe to be
automatically scheduled every day.
• (Optional) start-time—Enter the time for the
operation to begin collecting information:
To start at a specific time, enter the hour, minute,
–
second (in 24-hour notation), and day of the
month.
– Enter pending to select no information collection
until a start time is selected.
Enter now to start the operation immediately.
–
– Enter after hh:mm:ss to show that the operation
should start after the entered time has elapsed.
Return to privileged EXEC mode.
Show the configured IP SLAs operation.
(Optional) Save your entries in the configuration file.
Purpose
Clear MEPs with matching domain and VLAN ID out of AIS defect
condition.
Clear a SMEP out of AIS defect condition.
Clear all CFM error conditions, including AIS.
Table 32-2
Chapter 32 Configuring Ethernet OAM, CFM, and E-LMI
to display Ethernet CFM information.
