Configuring IP Multicast Routing
Go to this URL to see SSM mapping configuration examples:
http://www.cisco.com/en/US/docs/ios/12_3t/12_3t2/feature/guide/gtssmma.html
Configuring DNS-Based SSM Mapping
To configure DNS-based SSM mapping, you need to create a DNS server zone or add records to an
existing zone. If the routers that are using DNS-based SSM mapping are also using DNS for other
purposes, you should use a normally configured DNS server. If DNS-based SSM mapping is the only
DNS implementation being used on the router, you can configure a false DNS setup with an empty root
zone or a root zone that points back to itself.
Beginning in privileged EXEC mode, follow these steps to configure DNS-based SSM mapping:
Command
Step 1
configure terminal
Step 2
ip igmp ssm-map enable
Step 3
ip igmp ssm-map query dns
Step 4
ip domain multicast domain-prefix
Step 5
ip name-server server-address1
[server-address2... server-address6]
Step 6 Repeat Step 5 to configure additional
DNS servers for redundancy, if required.
Step 7
end
Step 8
show running-config
Step 9
copy running-config startup-config
Cisco ME 3800X and 3600X Switch Software Configuration Guide
33-20
Purpose
Enter global configuration mode.
Enable SSM mapping for groups in a configured SSM range.
(Optional) Enable DNS-based SSM mapping.
By default, the ip igmp ssm-map command enables DNS-based SSM
mapping. Only the no form of this command is saved to the running
configuration.
Use this command to re-enable DNS-based SSM mapping if
Note
DNS-based SSM mapping is disabled.
(Optional) Change the domain prefix used by the switch for DNS-based
SSM mapping.
By default, the switch uses the ip-addr.arpa domain prefix.
Specify the address of one or more name servers to use for name and
address resolution.
—
Return to privileged EXEC mode.
Verify your entries.
(Optional) Save your entries in the configuration file.
