Displaying CNS Configuration

Command
Step 5
cns image retry {number}
Step 6
cns image server {ip-address} status {ip-address}
Step 7
end
This example shows how to upgrade a switch from a server with the address of 172.20.249.20:
Note
Switch(config)> configure terminal
Switch(config)# ip host cns-dsbu.cisco.com 172.20.249.20
Switch(config)# cns trusted-server all-agents cns-dsbu.cisco.com
Switch(config)# no cns aaa enable cns event 172.20.249.20 22022
Switch(config)# cns image retry 1
Switch(config)# cns image server http://172.20.249.20:80/cns/HttpMsgDispatcher status
http://172.20.249.20:80/cns/HttpMsgDispatcher
Switch(config)# end
You can check the status of the image download by using the show cns image status user EXEC
command.
Displaying CNS Configuration
You can use the privileged EXEC commands in
Table 4-2 Displaying CNS Configuration
Command
show cns config connections
show cns config outstanding
show cns config stats
show cns event connections
show cns event stats
show cns event subject
Cisco ME 3800X and 3600X Switch Software Configuration Guide
4-14
Purpose
Displays the status of the CNS Cisco IOS agent connections.
Displays information about incremental (partial) CNS configurations that have started but
are not yet completed.
Displays statistics about the Cisco IOS agent.
Displays the status of the CNS event agent connections.
Displays statistics about the CNS event agent.
Displays a list of event agent subjects that are subscribed to by applications.
Chapter 4 Configuring Cisco IOS Configuration Engine
Purpose
Specify the number of times to retry and download the
image.
Download the image from the server to the switch.
Return to privileged EXEC mode.
Table 4-2 to display CNS configuration information.
OL-23400-01
