Saving System Configuration - Omron CX-ONE - INTRODUCTION GUIDE 1 Introduction Manual

各種PLC
PLC Network
ネットワーク PLC
Start-Up
Start-Up
の立ち上げ
Move the cursor on the
DeviceNet and right-click
Select [Connect]
Select
[Transfer [Network to PC]]
Select [Connect]
Select
[Transfer [Network to PC]]
Select
[Serial Port] > [NT Link]
Select [Connect]
Select
[Transfer [Network to PC]]
DeviceNet NT Link
Start-Up Start-Up

Saving System Configuration (1)

Saving System Configuration (1)
Save the system configuration for inspection after delivery.
(1) Connect online to a PLC on a network.
The online connection information window is displayed.
(2) Send the network Structure of DeviceNet to the personal computer.
Connect to DeviceNet from the online connection information window. After connection
is established, send the network Structure of DeviceNet to the personal computer.
(3) Send the network configuration of NT Link to the personal computer.
Select the connection menu on the CPU port, then select upper link port and NT Link.
Next, select the transmission menu on the CPU port.
(4) Send the Controller Link network configuration to the personal computer.
Connect to the Controller Link network. After connection is established, send the network
configuration to the personal computer.
Controller
CompoWay
Link
/F Start-Up
Start-Up
Saving Equipment
System Disass'y /
Config. Reass'y
All communications Units and ports of
All communications Units and ports of
a connected PLC are automatically
a connected PLC are automatically
displayed in the online connection
displayed in the online connection
information window. From this window,
information window. From this window,
connect to each network and save the
connect to each network and save the
configuration to a project file.
configuration to a project file.
System Controller
Config. Link
Verification Diagnosis
