Omron CX-ONE - INTRODUCTION GUIDE 1 Introduction Manual page 26

Starting CX-
Design
Programmer
Saving a CX-Programmer file
From the [File] menu,
select [Save As...]
Saving CX-Designer and
CX-Motion-NCF/MCH files
Setting
Creating Unit
CPU Bus
Configuration
Units/SIOU
Saving a Project
Saving a Project
Unit setting, Unit parameter setting, and programs using the CX-Programmer can be saved all
at once.
Save it with a name. In this example save as "Sample1".
Created data can be saved for CX-Designer and CX-Motion-NCF/MCH.
Save CX-Motion-NCF as "Sample2.mnf" (CX-Motion-MCH as "Sample5.mnh"), and CX-
Designer as "Sample3.ipp".
Saving screen for CX-Motion-NCF
If you run a dedicated Support Software such as CX-Motion-NCF or CX-Designer when CX-
If you run a dedicated Support Software such as CX-Motion-NCF or CX-Designer when CX-
Programmer is started, the same default folder location as that of CX-Programmer is used for
Programmer is started, the same default folder location as that of CX-Programmer is used for
reading and saving files. It allows easier CX-One Support Software file management.
reading and saving files. It allows easier CX-One Support Software file management.
Checking I/O
Programming
Assignment
Saving screen for CX-Designer
Saving
Offline Debug
a Project
Click
