Omron CX-ONE - INTRODUCTION GUIDE 1 Introduction Manual page 21

Starting CX-
Design
Programmer
Right-click MCH Unit
Point [Start Special
Application]
Select [Start with
Setting Inherited]
Add task, axis, program,
and CAM data
Edit position data,
parameters, program,
and CAM data
Save the project
Setting
Creating Unit
CPU Bus
Configuration
Units/SIOU
Using the MCH Unit
Using the MCH Unit
When using the MCH Unit (CJ1W-MCH71) instead of the NCF Unit, use the following settings.
As with Analog Unit, register the MC Unit to the I/O table.
The MCH resides within the Motion Controller.
Then start CX-Motion-MCH using [Start with Settings Inherited].
When opening a stored project file after starting the dedicated tool, select [Start Only].
If [Start with Setting Inherited] is selected, a new project is created.
Click and save the project to file.
Checking I/O
Programming
Assignment
Start the MCH Unit as registered.
program, and CAM data.
Open the editing screen to edit data by double-clicking
position data, parameter, program, or CAM data on the
project tree.
Saving
Offline Debug
a Project
Click to add task, axis,
