Omron CX-ONE - INTRODUCTION GUIDE 1 Introduction Manual page 30

Online Debug on Reading
a Machine
Right-click NCF Unit
Point [Start Special
Application]
Click [Start Only]
Click
Select "Sample2.mnf"
Click
Double-click NCF Unit
Online
Connection
Project
to PLC
Then data is sent at the same time to NCF Unit and the servo driver connected to NCF Unit.
[Data to be sent]
NCF Unit: Common parameters, axis parameters
Servo Driver: Servo parameters
From CX-Programmer, display the I/O Table,
then start CX-Motion-NCF by [Start Only].
Open a saved project and transfer all NCF Unit and servo driver parameters.
Double-click NCF Unit.
Transferring
Program
to a
Debug
Machine
To prevent a servo driver operation using a ladder
program, you must set the PLC to PROGRAM mode.
Click
If it does not go online, click
and check the communications
setting between the personal
computer and PLC.
