User Guide
b. The IP Address for each IOM will appear at the end of each resulting line. Each IP Address
is labeled for either IOM A or IOM B and occurs after the last comma as seen bolded in the
following example.
Step 3 : Verify the IOM SAS Address that matches each SCSI device that is linked to each IOM using
sg_vpd page 83h.
a. Issue the following command:
sg_vpd <dev> -p0x83
b. Identify and match the IOM SAS address and sg device for both IOMs from the output. Each
address appears bolded in the example below.
Addressed logical unit:
Step 4 : Build the sg_senddiag command using the information recorded in earlier steps.
a. Use the example of the sg_senddiag command shown in the image above to complete the
specific sg_senddiag command for IOM A. Replace letters a through d with the information
recorded in previous steps.
sg_senddiag Command
sg_senddiag <a> --pf --raw=04,00,00,90,<b>,<c>,00,00,<d>
a. SCSI device (<dev>): device associated with IOM A
b. Enable Zoning: 61
c. Zoning Configuration: configuration 01, 02, or 03
d. IOM SAS Address: SAS Address associated with IOM A
Note: For scsi<dev>, type the number of the SCSI device recorded in the
previous step.
designator type: NAA,
0x5000ccab0300003c
Target port:
designator type: NAA,
transport: Serial Attached SCSI Protocol (SPL-4)
0x5000ccab0300003c
designator type: Relative target port,
transport: Serial Attached SCSI Protocol (SPL-4)
Relative target port: 0x1
Target device that contains addressed lu:
designator type: NAA,
transport: Serial Attached SCSI Protocol (SPL-4)
0x5000ccab0300003c
Note: For information on preconfigured zoning configurations, see:
Predefined Zoning Configurations (page
code set: Binary
code set: Binary
code set: Binary
code set: Binary
221).
4. Management
4.7 Zoning
235
