134 | DR 100s | Advanced Operation

Replacing the battery of the wireless exposure button

When the battery status indictor on the holder of the wireless exposure button
lights up orange, the battery must be replaced immediately.
Replace the battery of the wireless exposure button while the DR 100s is
switched off.
1. Rotate the end cap 90° in the counterclockwise direction.
2. Pull out the end cap.
3. Slide the battery cover in the direction of the end cap.
4. Lift up and remove the battery cover.
5. Replace the battery.
Only use a battery type CR123A (Lithium primary battery 3 VDC). Using
an unspecified battery can result in failure or fire.
6. Close the cover by following the above procedure in the reverse order.
The battery status indictor on the holder of the wireless exposure button is not
lighting up.
Related Links
Wireless exposure button
0411D EN 20220627 1040
4
3
1
2
on page 42
