144 | DR 100s | Advanced Operation
Copying the configuration of the RFID reader to another DR
100s system
Only users who have a Windows administrator account can perform this task.
The configuration of the RFID reader can be copied to other systems.
1. On the NX workstation, go to the Main Menu.
2. Click the Show Desktop action button.
The Windows desktop is shown.
3. Go to the Windows Start menu > Agfa and click RFID Config Tool.
The RFID Configuration Tool dialog is displayed.
4. Select the tab Configure Settings.
5. Click Export Card List and save the file to a USB flash drive.
6. Close the RFID Configuration Tool.
7. On the other DR 100s system, open the RFID Configurtion Tool.
8. Select the tab Configure Settings.
9. Click Import Card List and select the file from the USB flash drive.
10. Click Send to Device.
11. Close the RFID Configuration Tool.
0411D EN 20220627 1040
Note: A configuration can only be copied if the windows
usernames and password are the same on both systems.
