178 | DR 100s | Product Information
Manual collimator technical data
Model
Manufacturer
Collimation
Assembly plan from focus
Coverage of the field at 100cm
SID
Lighting source
Lamp lighting time
Light intensity (IEC 60601-2-54) > 160 lux
Minimum contrast ratio (IEC
60601-2-54)
Focal distance measurement
Maximum radiation leakage
Inherent filtration
Additional filtration
Rotation
Weight
0411D EN 20220627 1040
R108 F
Ralco
Via dei Tigli 13/G
20853 Biassono (MB), Italy
Manual with internal light source, multi-
layer, squared field, laser field to deter-
mine the SID at 1 m.
80 mm (3.14")
minimum 0 cm x 0 cm
maximum 43 cm x 43 cm
Clusters of high-brightness LED power
30 s
4:1
Retractable tape measure (maximum ex-
tension 3 m)
150 kVp - 4mA
2 mm equivalent Al at 75kV
Manual selection
• 0 mm Al
• 1 mm Al + 0.1 mm Cu
• 1 mm Al + 0.2 mm Cu
• 2 mm Al
± 120°
5.5 kg
