X-ray group (32 kW configuration)

Table 38: X-ray specifications
Nominal power (IEC 60601-1)
kV values
mA values @115/230Vac
mAs values @115/230Vac
Exposure times @115/230Vac
Table 39: Accuracy (IEC 60601-2-54)
kV
mA @115/230Vac
mAs
Time
Table 40: Equivalent filtration @75 kV
Filtration
Collimator
Total filtration
Additional filtration of DAP meter (optional)
Total filtration with DAP meter (optional)
DR 100s | Product Information | 183
32 kW @ 100 kV, 320 mA
40 - 125 kV at steps of 1 kV
70 - 320 mA
(automatically associated to kV)
0.1 - 320 mAs
(with increases of 12.5%)
0.001 - 3 s (DR mode)
0.001 - 10 s (CR mode)
(according to mAs)
±5%
±20%
±(10% + 0.2 mAs)
±(10% + 0.1 ms)
1.4 mm Al
2 mm Al
3.4 mm Al
0.3 mm Al
3.7 mm Al
