Title page
Nortel Communication Server 1000
Nortel Communication Server 1000 Release 5.0
Communication Server 1000E Upgrade
Option 11C Chassis to Communication Server 1000E
Document Number: NN43041-465
Document Release: Standard 01.04
Date: July 2007
Year Publish FCC TM
Copyright © 2007 Nortel Networks. All rights reserved.
Produced in Canada
The information in this document is subject to change without notice. The statements, configurations, technical
data, and recommendations in this document are believed to be accurate and reliable, but are presented
without express or implied warranty. Users must take full responsibility for their applications of any products
specified in this document. The information in this document is proprietary to Nortel Networks.
Nortel, Nortel (Logo), the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
All other trademarks are the property of their respective owners.
