Yanmar 4LHA-HTP Operation Manual page 555

Chapter 7 Reduction and Reversing Gear
3. Inspection and Servicing
Adjusting point
t l
t2
t 3 & t 4
t 5 & t 6
Part No.
177095-02150
177074-03410
177075-02150
177074-02350
7-1-19
Thickness, mm (in.)
0.1 (0.0039)
0.3(0.0118)
0.5 (0.0197)
1.0 (0.0394)
0.1 (0.0039)
0.3 (0.0118)
0.5 (0.0197)
1.0 (0.0394)
0.3 (0.0118)
0.4(0.0157)
0.5 (0.0197)
0.1 (0.0039)
0.3 (0.0118)
0.5 (0.0197)
1.0(0.0394)
4LHA Seriei
No. of shims
2
1
2
1
2
1
1
1
4
4
4
n
6
2
2
2
