Bin Side Cover Removal - Lexmark MS911 Service Manual

3
Remove the screw (A), and then remove the cover.
4
Disconnect the cable (B), and then remove the two screws (C). Release the latches (D), and then open the case.
5
Remove the fan.

Bin side cover removal

1
Remove the left cover. See
2
Remove the standard bin base. See
B
"Left cover removal" on page
"Standard bin base removal" on page
Repair information
330
A
C
D
223.
329.
