Main Power Switch Removal - Lexmark MS911 Service Manual

5
Disconnect the two cables (B), and then remove the screw (C).
6
Release the retainer, and then remove the switch.

Main power switch removal

1
Remove the top front door. See
2
Remove the bottom front door. See
3
Remove the waste toner door mount. See
4
Remove the screw (A), and then move away the switch.
5
Disconnect the four cables, and remove the switch.
B
"Top front door removal" on page
"Bottom front door removal" on page
"Waste toner door mount removal" on page
A
Repair information
277
C
273.
274.
275.
