Wireless LAN, Combo, 3G & LTE Module Cables
Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are
not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden-
tification as outlined in the table below.
Module Type
WLAN/WLAN & Bluetooth
Combo
LTE Broadband
3G Broadband
Cable 1 is usually connected to antenna 1 (Main) on the module, and cable 2 to antenna 2 (Aux).
Antenna Cable Cover
Cable Color
Type
WM 1 Black
WM 2 Gray
LTE 1 Black
LTE 2 Gray
3G 1 Black
3G 2 Gray
Wireless LAN, Combo, 3G & LTE Module Cables 2 - 15
Type
Transparent
White
Black
Black
