Before you use the Vigor router, please get acquainted with the LED indicators and connectors
first.
1 . 2 . 1 F o r V i g o
1 . 2 . 1 F o r V i g o
a t o r s a n d C o n
a t o r s a n d C o n
r 2 1 3 0
r 2 1 3 0
LED
ACT
(Activity)
HPA
WAN
LAN1/2/3/4
USB1/2
VPN
QoS
DoS
Interface
WAN
LAN (1-4)
USB
n e c t o r s
n e c t o r s
Status
Blinking
Off
On
Off
On
Blinking
On
Off
Blinking
On
Blinking
On
On
On
Blinking
Description
Connector for accessing the Internet.
Connectors for local networked devices.
Connector for USB storage device (Pen
Driver/Mobile HD) or printer or 3G backup.
2
Explanation
The router is powered on and running
normally.
The router is powered off.
Hardware NAT is enabled.
Hardware NAT is disabled.
The WAN port is connected.
It will blink while transmitting data.
The port is connected.
The port is disconnected.
The data is transmitting.
A USB device is connected and active.
The data is transmitting.
The VPN tunnel is active.
The QoS function is active.
The DoS/DDoS function is active.
It will blink while detecting an attack.
Vigor2130 Series User's Guide
