Draytek Vigor2130 Series User Manual page 162

Rx Low
Rx Normal
Rx Medium
Rx High
Rx Drops
Rx CRC/Alignment
Rx Undersize
Rx Oversize
Rx Fragments
Rx Jabber
Rx Filtered
Tx Packets
Tx Octets
Tx Unicast
Tx Multicast
Tx Broadcast
Tx Pause
Tx 64 Bytes
Tx 65-127 Bytes
Tx 128-255 Bytes
Tx 256-511 Bytes
Tx 512-1023 Bytes
Tx 1024- 1526 Bytes
Tx 1527 Bytes:
Tx Low
Tx Normal
Tx Medium
Display the low queue counter of the packet received.
Display the normal queue counter of the packet received.
Display the medium queue counter of the packet received.
Display the high queue counter of the packet received.
Display the number of frames dropped due to the lack of
receiving buffer.
Display the number of Alignment errors packets received.
Display the number of short frames (<64 Bytes) with valid
CRC.
Display the number of long frames (according to max_length
register) with valid CRC.
Display the number of short frames (< 64 bytes) with invalid
CRC.
Display the number of long frames (according to max_length
register) with invalid CRC.
Display the filtered number of the packet received.
Display the the counting number of the packet transmitted.
Display the total transmitted bytes.
Display the show the counting number of the transmitted
unicast packet.
Display the show the counting number of the transmitted
multicast packet.
Display the counting number of the transmitted broadcast
packet.
Show the counting number of the transmitted pause packet.
Display the number of 64-byte frames in good and bad packets
transmitted.
Display the number of 65 ~ 127-byte frames in good and bad
packets transmitted.
Display the number of 128 ~ 255-byte frames in good and bad
packets transmitted.
Display the number of 256 ~ 511-byte frames in good and bad
packets transmitted.
Display the number of 512 ~ 1023-byte frames in good and bad
packets transmitted.
Display the number of 1024 ~ 1522-byt frames in good and bad
packets transmitted.
Display the number of 1527-byte frames in good and bad
packets transmitted.
Display the low queue counter of the packet transmitted.
Display the normal queue counter of the packet transmitted.
Display the medium queue counter of the packet received.
