Draytek Vigor2130 Series User Manual page 192

Auto-reconnect Delay
Keepalive
Keepalive_interval
Prefixlen
If_prefix
After passing the time set here, the client will retry to
connect in case of failure or keepalive timeout.
0 means not retry.
Yes – Keep the connection between TSPC and tunnel
broker always on. TSPC will send ping packet to make
sure the connection between both ends is normal.
No - The client will not send keepalives.
Type the time for the interval between two keepalive
messages transferring from the client to the broker.
Type the required prefix length for the client network.
Display LAN interface name.
interface that will be configured with the first 64 of
the received prefix from the broker and the router
advertisement daemon is started to advertise that
prefix on the if_prefix interface.
184
The name of the OS
Vigor2130 Series User's Guide
