Idle Time Out
MTU Size
Clone MAC Address
After finishing all the settings here, please click OK to activate them.
3 G U S B M o d e m
3 G U S B M o d e m
If your router connects to a 3G modem and you want to access Internet via 3G modem, choose
3G as connection type and type the required information in this web page.
SIM PIN code
Modem Initial String1/2
APN Name
Modem Dial String
PPP Username
Set the timeout for breaking down the Internet after passing
through the time without any action. When you choose Connect
on Demand, you have to type value here.
It means Max Transmit Unit for packet. The default
setting is 1442.
It is available when the box of Enable is checked. Click Clone
MAC Address. The result will be displayed in the field of
MAC Address.
Type PIN code of the SIM card that will be used to access
Internet.
Such value is used to initialize USB modem. Please use the
default value. If you have any question, please contact to your
ISP.
APN means Access Point Name which is provided and
required by some ISPs.
Such value is used to dial through USB mode. Please use the
default value. If you have any question, please contact to your
ISP.
Type the PPP username (optional).
