Measurements Input X
Note: press "ENTER" to change the X value and consequently vary the phase of which you are reading the data.
Measurements
Batteries
Measurements Misc.
Alarms
Note: press the "ARROW UP" and "ARROW DOWN" keys to scroll the list of alarms.
Power Active power absorbed by the UPS by the mains on phase X [W]
Appar. Power Apparent power absorbed by the UPS by the mains on phase X VA]
Vrms Effective voltage in input to the UPS on phase X [V RMS]
Effective voltage in input to the UPS on phase X,
Bypass Vrms
for the bypass line [V RMS]
Effective line voltage between the phases in input to the UPS
Linked Vrms
for the bypass line [V RMS]
Irms Effective current absorbed by the UPS by the mains on phase X [A RMS]
Peak I Value Peak current absorbed by the UPS by the mains on phase X [A]
Frequency of the voltage sinusoid in input to the UPS
Frequency
on phase X for the bypass line [Hz]
Crest I Factor Crest factor applied by the UPS to the mains on phase X
Power Factor Power factor applied by the UPS to the mains on phase X
Voltage Voltage measured at the ends of the batteries [V]
Current supplied by the batteries (negative if the batteries are being
Current
charged) [A]
Residual Capac. Battery charged status, expressed as a percentage [0-100%]
Working status of the battery charger:
- Batt. in Standby;
- Running down;
- Autonomy reserve;
- End of autonomy;
- Charging – f1;
Chg Status
- Charging – f2;
- Charging – maint.;
- Batt. being tested;
- Battery equalisation;
- BATTERIES FAILED;
- Max. Battery time;
Tot autonomy Total autonomy the UPS would have with batteries charged 100%
Res. autonomy Residual autonomy of the UPS
End of aut V Battery threshold voltage for end of autonomy [V]
No. run downs Total number of times the batteries have been completely run down
Use Total number of hours the UPS has been running on battery [h]
Day and time the last calibration was made;
Cal.
Factory setting if no calibration has been done yet
No. Calibrations Total Number of calibrations made
Internal Temp. Temperature inside the UPS [°C]
H.V. Bus Pos. Voltage on the DC BUS positive [V]
H.V. Bus neg. Voltage on the DC BUS negative [V]
Alarm Register. See chapter 8.
