5. Unpacking

5.1 Visual Inspection
When the UPS is delivered, examine the packaging and product carefully to see if any damage was done during transport.
In particular check the integrity of the indicators on the external "Shock Watch" labels.
If either possible or ascertained damage is found report it immediately to:
- the carrier;
- the LEGRAND® Technical Assistance Centre.
Make sure that the unit received corresponds to the material specified on the delivery document.
The UPS Archimod® packaging protects the equipment against mechanical and environmental damages.
For greater protection it is also wrapped in a transparent film.
5.1.1 Controllo apparecchiatura e corredo di fornitura
The equipment and relative accessories supplied (as agreed with the manufacturer) must be in perfect condition.
Before it is shipped the equipment is checked carefully; however, it is always advisable to check it is complete and in order
when receiving it.
Make sure that:
• The shipping data (consignee's address, number of packs, order number, etc.) are the same as those written on the
delivery documents;
• Check that the Archimod® UPS technical data on the label affixed to the UPS correspond to the material purchased,
described in the delivery documentation.
• The technical-legal documentation that comes with the equipment includes the user manual for the specific type of
UPS to install together with the CE Declaration of Conformity.
In the case of defects and/or material missing, send a report immediately to the Manufacturer and wait for his instructions
before commissioning the equipment.
5.2 Positioning limits
The UPS must be placed observing the following conditions:
• humidity and temperature must be within the prescribed limits;
• the fire protection regulations must be observed;
• wiring must be of easy execution;
• the front and rear must be accessible for assistance or routine maintenance;
• the flow of cooling air must be guaranteed;
• the air conditioned system must be adequately sized
• there must be no corrosive/explosive gases;
• the premises must be free from vibrations;
• the clearance at the back and sides must guarantee adequate circulation of the cooling air.
• It must be possible to size the support used for the equipment to ensure it will withstand its weight.
ATTENTION
The minimum rear clearance of the UPS must be at least 200 mm to guarantee correct ventilation. Bear in mind that
you need to be able to reach the back of the UPS for manoeuvring the battery fuse holder disconnector switches
and for maintenance.
To better protect the batteries bear in mind that the average life of the batteries is strongly influenced by the environmental
operating temperature.
Place the unit on premises where the temperature ranges between +18°C (64.4°F) and +23°C (73.4°F) which will guarantee
a very long battery life.
Before commencing installation, make sure there is enough lighting on the equipment so that each single detail can be
seen easily.
Use artificial lighting if natural lighting is not enough for the aforementioned requirements.
If maintenance work has to be done on parts that are insufficiently illuminated, it is compulsory to use portable lighting,
being careful not to create shadows that will prevent or reduce visibility on the point you are working on or on the
surrounding areas.
Archimod®
27
