7. Control panel
7.2.6 Log Out
A password can be set to protect the UPS from changes to settings by unauthorised personnel. Choosing a password each
time the UPS settings need changing is necessary to access a private session.
Use the "Log Out" menu to exit the private session when finished.
If you forget the password contact the assistance centre.
7.2.7 Turning the single output phases ON and OFF
When the inverter output is configured as three separate single-phase lines, by very lightly pressing the On/Off key for
less than 500 ms it is possible to gain access to a particular menu where you can choose which of the three phases R,S,T
to turn on or off independently from the others.
7.2.8 Shutting down the UPS Archimod®
ATTENTION
The shutting down procedure described below is to be used only and exclusively if the load applied to the UPS is
off or does not need powering by it.
1. Check there is no need to power the connected loads.
2. Hold down the ON/OFF button on the UPS control panel for at least 2 seconds.
3. When asked "Turn the UPS off?" confirm with the ENTER key.
4. Wait for the shutdown operation to finish. If the UPS needs repairing or maintenance appertaining to the power
modules, battery boxes or "backplanes"
5. Open the output switch.
6. Open the mains disconnecting switches
7. Open the battery disconnecting switches (F B+ and F B-) of the unit and of the Archimod® BATTERY system (if
present).
If you expect to leave the UPS off for a long time, please read carefully and put into practice what is prescribed in paragraph
5.6 concerning storage.
If these operations are done correctly, there will be no voltage in the UPS ARCHIMOD.
