ALARMS
MESSAGE
INVERTER FAILURE
BOOSTER FAILURE
BATTERY CHARGER FAILURE
OVERHEATING
OVERLOAD
HVBUS RUNAWAY
EXC. IN OUTPUT DC LEVEL
EXCESS.BATTERY VOLTAGE
PM ➝ CM COMMUNICATION FAILED
BATTERY CONNECTION FAILURE
MAINS CONNECTION FAILURE
H.V.BUS CONNECTION FAILURE
CM ➝ PM COMMUNICATION FAILURE
OVERLOAD
LOAD NOT PROTECTED
MAINTENANCE REQUIRED
CHECK THE BATTERIES
CAN NETWORK REFERENCE ERROR
CM MALFUNCTIONING ON CAN NETWORK
BACKFEED
MEANING
Failure occurred in the Inverter circuit.
Failure occurred in the Booster /PFC circuit.
Failure occurred in the Battery Charger circuit.
Overheating. Check the UPS ventilation system.
Overload. Check the load level connected to the UPS.
Anomalous high voltage on the DC BUS.
Excessive DC voltage in output.
Battery voltage too high.
Failure of the communication system with the Power Modules.
Error in connecting the battery to the Power Module.
Check the connection and the battery fuse inside the Power Module.
Error in connecting the mains to the Power Module.
Check the connection and the mains fuse inside the Power Module.
Error in connecting the D.C. Bus to the Power Module.
Check the connection and the D.C. bus fuse inside the Power Module.
Failure of the communication system with the Power Modules.
Overload
Load not protected by the UPS
Have specialized personnel carry out the routine check on the UPS.
Have specialized personnel check the batteries.
Synchronisation error between the commands.
Communication error between commands
Backfeed error detected
