7. Control panel
Batteries
(*) Disponibile solo in "Service Mode"
ATTENTION
Set the total KB value and Capacity correctly for the batteries being used. If set incorrectly there is the danger of
damaging the batteries.
Operator
(*) Only available with the password chosen
58
®
Threshold Values
Battery Charger
Restart
Total KBs
Capacity (*)
Language
Buzzer
Keyboard Beep
Shutting down block (*)
Panel
Display Backlighting
Display Contrast
Password change
Password level
Setting the start time of the end of battery
Aut end warning
autonomy warning
Setting the maximum time of the UPS
running on battery [sec].
Max. Battery time When this battery time is up the UPS shuts
down.
Set OFF to disable to function.
If enabled, it enables battery charging with
Charge in Standby
the UPS off.
Enables or disables restarting of the unit
Restart Enabling when mains power returns after
the batteries have run down completely
Minimum percentage of autonomy
Minimum autonomy
for restarting
Sets the total number of KBs installed (1 KB = 3 battery boxes)
Necessary for the UPS to supply correct autonomy values on the basis
of the load applied and for correct battery charging.
Sets the capacity value of the batteries in the UPS [Ah]
Sets the display language
Enables/disables all acoustic signals
Enables/disables the acoustic signalling when the keys are pressed
If enabled a password is required to shut the UPS down
Sets display backlighting
- Fixed: always lit
- Timed: lighting turns off if the keyboard is not used for 1 minute
- Disables: lighting always off
Sets display contrast
Sets a password that prevents access to UPS settings
The default setting is in the USER item
