LEGRAND Archimod Operating And Maintenance Manual page 80

11. Tables
TABLE 6
Differential Breaker - Differential Current
TABLE 7
Battery current (100% load at the end of discharge) and minimal recommended cable sections
80
®
POWER
20 kVA
40 kVA
60 kVA
80 kVA
100 kVA
120 kVA
POWER
20 kVA
40 kVA
60 kVA
80 kVA
100 kVA
120 kVA
DIFFERENTIAL BREAKER - DIFFERENTIAL CURRENT
BATTERY CURRENT
88 A
176 A
264 A
352 A
440 A
528 A
>= 300 mA
>= 300 mA
>= 300 mA
>= 300 mA
>= 300 mA
>= 300 mA
MINIMUM WIRES SECTION
1 x 25 mm
2
1 x 70 mm
2
2 x 50 mm
2
2 x 70 mm
2
2 x 95 mm
2
3 x 70 mm
2
per pole
per pole
per pole
per pole
per pole
per pole
